Mouser Electronics MCQ37AI Quick Reference Manual

30 31 1 2 3 4 5 6 7
29
CPU
SODIMM1
SODIMM2
28 27
DC In 12V Power Connector CPU FAN/ 风扇
No. Pin Define
1 No.
3 1 1 GND
1
2 GND
2
4 2
3 +12V
3
4
4 +12V
4
System Panel Header/ 前面板 SATA Connector/SATA 接口
7 1
No. Pin Define
1 HDD LED+
1 2
2 Power LED+
3 HDD LED-
4 Power LED-
1 7
5 GND
9 10 6 Power Button+
7 Reset Button
Battery Cable Connector
8 Power Button-
9 No Connect
10 No Pin
2 1
USB 3.0 Header
11 20
10 1
No. Pin Define No. Pin Define
1 Power 11 IntA_P2_D+
2 IntA_P1_SSRX- 12 IntA_P2_D-
3 IntA_P1_SSRX+ 13 GND
4 GND 14 IntA_P2_SSTX+
5 IntA_P1_SSTX- 15 IntA_P2_SSTX-
6 IntA_P1_SSTX+ 16 GND
7 GND 17 IntA_P2_SSRX+
8 IntA_P1_D- 18 IntA_P2_SSRX-
9 IntA_P1_D+ 19 Power
10 NC 20 No Pin
Embedded Display Port connector
1 19
2 20
No. Pin Define No. Pin Define
1 GND 11 eDP_1+
2 GND 12 eDPAUX-
3 eDP_0- 13 GND
4 eDP_3- 14 ePDAUX+
5 eDP_0+ 15 eDP_2-
6 eDP_3+ 16 GND
7 GND 17 eDP_2+
8 -eDPSW 18 eDP_HDP_C
9 eDP_1- 19 VCC_LVDS
10 GND 20 VCC3_LVDS
NOTE!
Please ensure pin 8 is connected to Ground.
PN:
MCQ37AI Quick Reference Guide/ 快速测试参考指南
8
9
10
11
12
13
14
15
16
17
18
19
20
21 22
23
267 25 24
Front Audio Connector/ 前置音频
No. Pin Define No. Pin Define
Pin Define
1 9 1 MIC_L 6 GND
GND
2 GND 7 FAUDIO_JD
+12V
3 MIC_R 8 No Connect
Sense
4 -ACZ_DET 9 HPOUT_L
2 10
Speed Control
5 HPOUT_R 10 GND
Hard Drive Power Connector
No. Pin Define
No. Pin Define
1 GND 1 +12V
2 TXP 4 1 2 GND
3 GND
3 TXN
4 VCC
4 GND
5 RXN
6 RXP
Back Light Brightness Control Connector
7 GND
No. Pin Define
1
1 VCC_LVDS
2 PWM_OUT
3 EN_BKLT
No. Pin Define
4 GND
1 Battery+
5
5 +12V_LVDS
2 GND
USB 2.0 Header Serial Port Cable Connector
No. Pin Define
No. Pin Define
1 NRXD-
1 Power (5V)
10 9
10 9 2 NDCD-
2 Power (5V)
3 NDTRD-
3 USB DX-
4 NTXD-
4 USB DY-
5 NDSR-
5 USB DX+
6 GND
6 USB DY+
2 1
7 NCTS-
7 GND
8 NRTS-
8 GND
2 1
9 No Connect
9 No Pin
10 RI-
10 No Connect
Jumper Settings/ 跳线设置
1
Enable
Clear CMOS
CLR_CMOS
Default
No. Code Description
1 AUDIO Audio Connectors
2 USB3_LAN2 GbE Eternet LAN Port #2 (top)/USB 3.0 Port (bottom)
3 USB3_LAN1 GbE Eternet LAN Port #1 (top)/USB 3.0/3.1 Port (bottom)
4 EDP Embedded Display Port Connector
5 HDMI_DP DisplayPort Connector (top)/HDMI Port (Bottom)
6 BATTERY Battery Cable Connector
7 VGA_COM1 Serial Port (top) / VGA Port (bottom)
8 DC_IN1 DC In Power Connector
9 DC_IN2 DC In 12V Power Connector
10 JCOM11 5V/12V/RI Signal Select Jumper for Serial Port #2
11 JCOM12 RS232/RS422/RS485 Select Jumper for Serial Port #2
JRS11/JRS12/
JRS13/JRS14
(Left to Right)
12 BKL Back Light Brightness Control Connector
13 COM2 Serial Port Cable Connector #2
32
14 M2E M.2 slot (PCIe Gen2 x1, Support NGFF-2230, E-Key)
15 SYS_FAN System Fan Connector
16 GPIO_CNT GPIO Connector
17 TPM TPM Module Connector
18 SATA_3 SATA 3 6Gb/s Connector #3
19 SATA_PWR1 SATA #3 Hard Drive Power Connector
20 SATA_PWR2 SATA #3 Hard Drive Power Connector
21 SATA2 SATA 3 6Gb/s Connector #2
22 SATA0 SATA 3 6Gb/s Connector #0
23 CASE_OPEN Case Open Intrusion Alert Header
24 SYS_PANEL Front Panel Header
25 FUSB2_2 USB 2.0 Connector #2
26 FUSB2_1 USB 2.0 Connector #1
27 FUSB3 USB 3.0 Connector
28 CPU_FAN CPU Fan Connector
29 PCIEX16 PCI Express x16 Slot
30 SPK_OUT Audio Amplifie Connector
31 FP_AUDIO Front Audio Connector
32 M2_M M.2 slot (PCIe Gen3 x4, Support NGFF-2210, M-Key)
Audio Amplifie Connector
No. Pin Define
1 Speaker Out L+
4 1 2 Speaker Out L-
3 Speaker Out R-
4 Speaker Out R+
GPIO Connector
1 11
2 12
No. Pin Define No. Pin Define
1 SOGPO1 7 SOGPO4
2 SOGPI1 8 SOGPI4
3 SOGPO2 9 SMB_CLK
4 SOGI2 10 SMB_DATA
5 SOGPO3 11 VCC
6 SOGPI3 12 GND
TPM Connector/
可信平台模块
2 14
1 13
No. Pin Define No. Pin Define
1 CLK_24M_TPM 8 NC
2 P_3V3_AUX 9 LPC_LAD_2
3 RST_PLTRST 10 KEY
4 P3V3 11 LPC_LAD_3
5 LPC_LAD_0 12 GND
6 IRQ_SERIAL 13 LPC_FRAME_N
7 LPC_LAD_1 14 GND
No. Desription
1 5V/12V/RI Signal Select Jumper for Serial Port Header#1
(JCOM11)
6 5
Pin No. Definition
1-2 Close: 5V (Power COM)
1 VCC
2 1
2 RI1-/5V/12V
6 5
3-4 Close: RI (Stand COM)
3 NRI1-
2
2 1
6 5 4 RI1-/5V/12V
5-6 Close: 12V (power COM)
5 +12V
2 1
6 RI1-/5V/12V
2 RS232/RS422/RS485 Select Jumper for Serial Port Header#1
(JRS11/JRS12/JRS13/JRS14 )
Pin No. Definition
2 6
1-2 Close: RS232 1 RXD232
1 5
2 RXD2
3 RXD422
2 6
3-4 Close: RS422
1 5
4 RXD2
5 RXD485
2 6
5-6 Close: RS485
6 RXD2
1 5
1
The HDMI connector is HDCP compliant and supports Dolby True HD and DTS HD
Master Audio formats. It also supports up to 192KHz/24bit 8-channel LPCM audio
output. You can use this port to connect your HDMI-supported monitor. The
maximum supported resolution is 4096x2160@24Hz or 2560x1600@60Hz, but the
actual resolutions supported are dependent on the monitor being used.
M.2 Module
2
1
Speed LED Link/Activity LED
1
2
TPM Module
Memory Population Configuration/ 安装内存
1-2 Close: RS422/RS485
2-3Close: RS232 (Default setting)
DIMM Per Channel
DIMM Capacity (GB)
Rear I/O Connector/ 后面板接口
6 7
2
4
8
8
9
3
5
No. Desription
1 DC In Power Connector
2 Serial Port
3 VGA Port
4 DisplayPort Connector
5 HDMI Port
6 GbE Eternet LAN Port #1
7 GbE Eternet LAN Port #2
8 USB 3.0 Port x 3
9 USB 3.1 Port
10 Line In
11 Line Out
12 Mic In
10/100/1000 LAN LED:
State Description
Yellow On 1Gbps data rate
Green On 100Mbps data rate
Off
10Mbps data rate
Installing CPU/ 安装 CPU
2
1
2
Memory
DDR4
Type
Voltage (V) 1.2V
Connector UDIMM
Speed (MT/s) 2666 2400
Channels 1,2
1,2
2,4,6,8
10
11
12
