MD 5850
Dokument tittel:
Dokument nummer:
Filnavn/Path:
Revisjon nummer:
Forfattet/revidert dato:
Forfattet/revidert av:
Sjekket av:
Godkjent dato:
Godkjent av:
Revisjonshistorie
Rev.2: Han-Modular connector pos. C pin 9 and 11 signals exchanged to correspond with I/O Filter Schematic.
Rev.3: Changed pflash instruction for serial flashing.
Rev.4: MVME168P preparations and flashing added.
®
Q-Free
ASA
Installation Manual
Installation Manual for MD 5850 MultiReader
645-054-1999
Arkiv/.../645-054-1999.doc
1
2
06.09.99
29.10.99
ES
ES
STo
STo
21.09.99
29.10.99
STo
STo
645-054-1999 rev.4
3
4
15.06.00
01.08.01
STo
FV
ES
STo
15.06.00
01.08.01
STo
STo
0 of 20
Advertisement
Table of Contents
Related Manuals for Q-FREE MD 5850 MultiReader
Summary of Contents for Q-FREE MD 5850 MultiReader
- Page 1 MD 5850 Installation Manual Dokument tittel: Installation Manual for MD 5850 MultiReader Dokument nummer: 645-054-1999 Filnavn/Path: Arkiv/…/645-054-1999.doc Revisjon nummer: Forfattet/revidert dato: 06.09.99 29.10.99 15.06.00 01.08.01 Forfattet/revidert av: Sjekket av: Godkjent dato: 21.09.99 29.10.99 15.06.00 01.08.01 Godkjent av: Revisjonshistorie Rev.2: Han-Modular connector pos. C pin 9 and 11 signals exchanged to correspond with I/O Filter Schematic.
- Page 2 MD 5850 Installation Manual Installation Manual MD 5850 MultiReader This equipment complies with part 15 of the FCC rules. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment. ® Q-Free 645-054-1999 rev.4...
-
Page 3: Table Of Contents
TEST WITH TEST TAGS AND INSTRUMENTS............18 Downlink signal test ......................18 7.1.1 Test Tag measurements........................ 18 7.1.2 Measuring the MultiReader footprint with a test tag..............18 7.1.3 Spectrum Analyser measurement....................19 ® Q-Free 645-054-1999 rev.4 2 of 20... - Page 4 The spectrum analyser settings should be:..................19 7.1.5 Measurement of the MultiReader footprint with a Spectrum Analyser........19 Uplink signal test ........................20 7.2.1 MultiReader without level detection..................... 20 7.2.2 MultiReader with level detection....................20 APPENDIX A ........................20 ® Q-Free 645-054-1999 rev.4 3 of 20...
-
Page 5: Introduction
An optional Universal mounting bracket may be delivered as shown in fig.2.1.1. This chapter is a guide to the mechanical and wiring installation of the MD 5850 MultiReader. The instructions in this manual are based upon the use of the stainless steel 2-piece universal bracket made by MD, MD part no. -
Page 6: Installation Site
An angle below 45° will reduce the communication zone length. This must be considered when the vehicles are passing at a high speed. 5. 5 -6.0m above lane surface 45° Figure 2.3.1 Side view of MR mounted hanging from concrete superstructure ® Q-Free 645-054-1999 rev.4 5 of 20... -
Page 7: Square Tube From Customers Construction
200mm square pattern. The bracket can therefore be inverted on the MR in order to accept different angles of the square tube. 2.5 Square tube sideways angles The Uni-bracket also provides for sideways adjustment. ® Q-Free 645-054-1999 rev.4 6 of 20... -
Page 8: Multireader Cable Interface
POWER SUPPLY & PIN A +VDC PIN B +VDC PIN C -VDC PIN D -VDC PIN E PIN F PIN G PIN H PIN I +VDC PIN J -VDC Fig.3.2.1 Circular Chassis Connector pin configuration. ® Q-Free 645-054-1999 rev.4 7 of 20... -
Page 9: Han-Modular Connector
IRSGND (RS232) PIN 9 IOA5 PIN 10 - ITX (RS422) PIN 10 IOB5 PIN 11 IRXD (RS232) PIN 11 IOA6 PIN 12 - IRX (RS422) PIN 12 IOB6 Fig.3.3.1 Han-Modular Connector pin configuration. ® Q-Free 645-054-1999 rev.4 8 of 20... -
Page 10: Han-Modular Connector Assembly Parts
09 14 016 0301 Female 20 10 125 4221 09 16 000 9905 Fibre contacts for DIN 41 626 part 3 09 30 016 0301 09 15 000 6191 09 62 000 5008 ® Q-Free 645-054-1999 rev.4 9 of 20... -
Page 11: Installation Tools (Preferred)
MD 5850 Installation Manual 3.5 Installation tools (preferred) ® Q-Free 645-054-1999 rev.4 10 of 20... -
Page 12: External Cable Interface
MultiReader. The maximum length of data transmission on twisted pairs depends of the cable category. Category 5 is recommended. NB! The TX at the connector side is coupled to the RX at the ® Q-Free 645-054-1999 rev.4 11 of 20... -
Page 13: Han-Modular Connector
Open the READER by unscrewing the four bolts on the back of the READER. • Loosen the CPU-card by unscrewing two screws on the front of the CPU-card. • Take out the CPU-card. Fig.5.1.1 CPU-card. ® Q-Free 645-054-1999 rev.4 12 of 20... -
Page 14: Loading The Software And Flashing
Auto negate RTS* when Recv FIFO full [Y,N] = N? XON/XOFF Protocol [Y,N] = Y? XON = $11=^Q? XOFF = $13=^S? Baud Rate [110,300,600,1200,2400,4800,9600,19200,38400] = 38400? . OK to proceed (y/n)? y Update Non-Volatile RAM (Y/N)? N ® Q-Free 645-054-1999 rev.4 13 of 20... -
Page 15: Closing Up
• Now turn on the power and check that the software boots before you close the box. There might be some Errors at this point, but you should have the prompt. • Fasten the CPU-screws, close the box and fasten the bolts. pflash 10008 10ffff ffa00000 for sw older than 1999. ® Q-Free 645-054-1999 rev.4 14 of 20... -
Page 16: Make New Startup File
• From prompt type in the startup script. The script is unique for each software. • Contact Q-Free if you don’t know which script to use. • The startup file could have any name but must be the same as set in “bootChange”... -
Page 17: Test With Application Sw
TPC’s CPU board. If the serial port 1/console port is used, the communication cable should be a 0- modem cable. Connect the cable between the PC’s serial port (9pin) and the 25pin console port on CPU board. ® Q-Free 645-054-1999 rev.4 16 of 20... -
Page 18: Testmode
CS2 is usually not read from the Tag unless the housekeeping application (EID0) is read. Below we see the CS1 field is unknown and therefore the ContractSerialNumber is missing. The Country and Issuer parameters are however read from the VST. ® Q-Free 645-054-1999 rev.4 17 of 20... -
Page 19: Test With Test Tags And Instruments
LED’s shut down. Put a mark (6) here. Start from centre and move sideways to the other direction. Use the same procedure as above. Put two marks (7 and 8) here. ® Q-Free 645-054-1999 rev.4 18 of 20... -
Page 20: Spectrum Analyser Measurement
3 dB form the maximum level. • Guiding measurements: Maximum length of - 3 dB zone: > 2 m Maximum width of -3 dB zone: > 2 m ® Q-Free 645-054-1999 rev.4 19 of 20... - Page 21 The MultiReader HW is prepared for this feature but it is not implemented in the application SW yet. APPENDIX A Fig.A.1 MultiReader 220VAC & Data Interface for Han-Modular connector (Part no. 014N0MR1). ® Q-Free 645-054-1999 rev.4 20 of 20...
