Summary of Contents for MINJCODE MJ3670
-
Page 2: Table Of Contents
C C ontents Function Settings Output Mode Setting Data Transmission Mode Setting Communication Mode Setting USB Interface Type Setting And Output Type Setting Inventory Mode Setting Vibration Setting Battery Display Beep Setting Sleep Setting GS Character Conversion Letter Case Conversion Keyboard Language Setting 2.4G Setting Bluetooth Setting... - Page 3 Technical Parameter： Mfr P/N MJ3670 Type 2.4G ，Bluetooth，USB wired Wireless Transmission Range Inside 15m, outside 30m Storage Capacity Approx 2MB, can store approx 100,000 barcodes Battery Capacity 3.7v 360mAh Charging Power DC 5V 1000mA Standby ≥ 10mA Operating Current ≥ 150mA...
- Page 4 I I ndicator And Buzzer Status Description Indicator light description Green light--> Charging indicator Every time the code is successfully scanned, it flashes rapidly once When USB or 2.4G and Bluetooth HID are not connected, it will be off When the USB or 2.4G or Bluetooth is connected, it is always on When entering 2.4G or Bluetooth HID pairing, then flashing constantly When entering Bluetooth SPP/BLE pairing, it will be slow flashing Buzzer Description...
-
Page 5: Communication Mode Setting
Software Version Number Restore factory defaults Note: With an asterisk (*) for the parameters after restoring the factory O O utput method Notes.: Simultaneous output mode: USB and 2.4G or Bluetooth are output at the same time (determined by the Simultaneous output mode USB priority output(*) communication mode), where... -
Page 6: Setting
Transferable keyboard function keys Direct ASCII transfer I I nventory Mode Clear all data Upload all data Upload statistics Electricity Display battery Vibration mode setting Vibrate mode off Vibrate mode on(*) Sound settings Sound volume setting Quiet High volume Volume Medium Low volume # #... -
Page 7: Gs Character Conversion
Sleep after 30 minutes Sleep after 10 minutes Sleep after 5 minutes Note: You can long press the button until you hear the first ring for about 8 seconds, release the button to enter the hibernation G G S character conversion Convert to | No conversion(*) Convert to <GS>... - Page 8 Hungary Denmark Norway Japan 2 2 .4G Setting Remark. Set 2.4G mode, it will automatically enter into 2.4G receiver mode and connect the last paired receiver by default. 2.4Ghz Mode(*) 2.4G Pairing 1. To enter 2.4G pairing, there are two ways. (1) scan the pairing receiver setting code to enter 2.4G pairing mode.
-
Page 9: Bluetooth Setting
2. To exit Bluetooth HID pairing. (1) When Bluetooth pairing is on, it will prompt once and end the pairing. (2) Double click the button twice to exit, and will be prompted once. (3) Wait for 1 minute, Bluetooth is not paired on, then automatically exit, and will prompt three times. Note: When you exit pairing, if no new device is connected, the old device that was last paired before is automatically connected by default. -
Page 10: Program Pdate
1.1. Scan the setup code "Bluetooth name ASCII definition" 2.2. Scan the content you want to add in order, please find the ASCII code table 3.3. finally scan the setting code "Save data and exit". Note: The longest Bluetooth name can be set to 24 bytes. Bluetooth name ASCII definition Setting tutorial: You can refer to the tutorial of adding prefix and suffix. - Page 11 Save and end settings H H ide pre-character settings Steps： (1) Scan the setting code "Hide previous character". (2) Set the number of digits to be hidden from the first digit, and use two data codes to represent the decimal number XX. (3) Set the number of bits (including its own data) to be hidden from the first few digits of the parity, and use two data codes to represent the decimal number YY (4) Finally, scan the setting code "Save data and exit".
-
Page 12: Data Code Table
characters DEFGH. so that the output barcode is "ABCDIJKLMN". (1) Scan setting code "Hide previous character" (2) The location of character 'H' is bit 7, so "XX" is '0', '7'. Find the data code table and scan the data code table '0' and '7' in turn. (3) Hide "DEFGH"... - Page 13 1. Scan the setting code "Add Suffix" 2. In the original barcode, the suffix content "12345" is added after the character 'E', and the location of the original barcode content 'E' is the penultimate 10th character, so the data code "XX" is "1" and "0", find the data code table and scan the barcode corresponding to the data code in order.
-
Page 14: Ascii Code Table
Hide 10 position behind Hide 11 position behind Hide 12 position behind Hide 15 position behind Hide 13 position behind Hide 14 position behind D D ata Code Table ASCII Code Table Null SOH(start of headline) STX (start of text) - Page 15 " &...
- Page 16 < >...
- Page 18 Caps Lock Function keys F1 Function keys F2 Function keys F3 Function keys F4 Function keys F5 Function keys F7 Function keys F6 Function keys F8 Function keys F9 Function keys F10 PrintScreen Function keys F11 Function keys F12 Pause Insert Scroll Lock PageUp...
- Page 19 9(keypad) 7(keypad) 8(keypad) 0(keypad) .(keypad) A A dd Ctrl, Shift, Alt, GUI function keys Note: There is pressed, there must be released, pressed and released must be used in pairs, otherwise there will be data not uploaded and the computer inexplicably lock screen and other hotkey problems L-Shift Press L-Ctrl Press L-Alt Press...
- Page 20 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
