- Page 1 16–100 SOKÓŁKA, POLAND UL. KRESOWA 62 OPERATING MANUAL PARTS CATALOGUE MANURE SPREADER N280 N280/1 N280/2 Edition no. 01 Year of issue: 2012 The original operating manual language is Polish.
- Page 2 DECLARATION OF CONFORMITY FOR THE MACHINE „METAL-FACH” Sp. z o.o. ul. Kresowa 62 16-100 SOKÓŁKA which acts as the manufacturer declares under sole responsibility that the following machine: Manure spreader type/model N280-....year of manufacture: ........serial number: ........... this declaration concerns, meets the following requirements:...
-
Page 3: Table Of Contents
CONTENTS: INTRODUCTION .......................... 5 SAFETY INSTRUCTIONS ......................6 2.1. RESIDUAL RISKS ......................... 7 2.2. NOISE AND VIBRATION ..................... 8 INFORMATION AND WARNING SIGNS .................. 8 INTENDED USE .......................... 14 OPERATION OF SPREADERS ....................14 5.1. C ................14 OUpLINg ThE SpREADER wITh ThE TRACTOR 5.1.1. - Page 4 Nameplate...
-
Page 5: Introduction
The N280 spreader conforms to the traffic code regulations regarding the traffic of machines with the maximum speed of 30 km/h on public roads. The machine also conforms to the safety requirements of the valid... -
Page 6: Safety Instructions
2. SAFETY INSTRUCTIONS Always turn off the tractor engine, remove the ignition key and engage the parking brake before leaving the driver's seat. Should any failure occur, always turn off the tractor engine. Do not turn on the conveyor when the adapter is off. Prior to starting your work, first lift the body gate, engage the adapter, run it at the full PTO speed and then turn on the floor conveyor drive. -
Page 7: Residual Risks
2.1. RESIDUAL RISKS The N280 spreader has been designed and produced in accordance to the state of technology and safety requirements valid for its year of manufacture. The manufacturer of this spreader has taken every effort in its design, production and labelling to eliminate all hazards related to operation, servicing and maintenance. -
Page 8: Noise And Vibration
2.2. NOISE AND VIBRATION The operator is inside the tractor cab when the machine is working. The equivalent sound pressure emission level A (LpA) is 75.0 ± 1 dB. The peak sound pressure value C (LCpeak) is 82.0 ± 1 dB. Machine sound power –... - Page 9 540 RPM Do not remain between the machine and the tractor PTO rotational speed: 540 RPM. when the engine is running. (1x) (1x) Do not approach the working machine. Maintain a safe distance from the tow bar when it is being lifted or lowered.
- Page 10 Brake release sign. Keep a safe distance from power lines. (1x) (1x) Load capacity 6 t Information label – manufacturer's logo. Information label (2x) (1x) A4VS ADAPTER WEIGHT 470 kg Information label – machine symbol. Description of the adapter weight. (2x) (2x) Warning sign.
- Page 11 Warning of being caught by the PTO drive-shaft. Do not ride on ladder steps or the tow bar. (1x) (2x) Tighten the wheel nuts after couple of kilometres and then repeat periodically Information on wheel tightening Danger of hands crushing. (2x) (2x) Danger of hand being caught by moving elements of...
- Page 13 Fig. 1. Locations of the information and warning signs...
-
Page 14: Intended Use
4. INTENDED USE The N280 spreaders are intended for spreading of manure, peat, compost, etc. and transportation of crops within farms and on public roads. The machines are self-dumping and coupled with farming tractors only by the lower hitch. Spreaders are equipped with gates and facilitate transport of loose bulk loads by preventing its spillage from the load body. - Page 15 – see fig. 2 item 1. The support wheel stabilizes the spreader when it is loaded or not. Fig. 2 N280 spreader's support wheel. Do not disassemble the support or rest the machine on makeshift supports. Do not leave agricultural equipment on slopes or any other terrain inclinations without...
-
Page 16: Adapter Drive
Overload Machine Rated torque Rated length Shaft designation output clutches Type N280 1745 1600 N280/1 N280/2 1500 The shaft must bear the "CE" marking. Use only the shafts that are equipped with complete guards. Do not use the telescopic jointed shafts with damaged guards. -
Page 17: Commissioning And Running-In
5.1.2. Commissioning and running-in Do the following before commissioning the spreader: read and understand the operating instructions in full; assemble the machine in accordance with the intended work; check the tightness of all threaded connections and the tension of chains; supply lubricants at the lubrication points;... -
Page 18: Load Body Gate Control
5.3. Load body gate control The load body gate is lifted and lowered hydraulically by the secondary hydraulic system of the tractor. 5.4. Floor conveyor 5.4.1. Hydraulic drive of the floor conveyor The floor conveyor system of the spreader is hydraulically driven by the transmission gearbox powered by the hydraulic motor, which in turn is driven by the pressurised hydraulic oil from the tractor's hydraulic system. -
Page 19: Anure Dosing
5.4.2. Manure dosing The floor conveyor output for the manure with a specific gravity of 950 kg/m Setting Conveyor output kg/s 14.3 25.7 38.4 50.1 64.7 76.8 99.5 The manure dosing (at the specific gravity of 950 kg/m ), depending on the floor conveyor shift speed and the actual service speed is presented in the following table: Setting no. -
Page 20: Adjustment Of Conveyor Chain Tension
Note: Take extra caution when performing the adjustment. Turn off the tractor engine, remove the ignition key and engage the parking brake of the tractor. 5.5. Adjustment of conveyor chain tension The conveyor chains are adjusted by the stretcher screws (see fig. 4 item 1) located on the stringers of the spreader's top frame. -
Page 21: Spreading Adapter
Fig. 5. Correcting the tensioners setting. 5.6. Spreading adapter The adapter consists of a frame on which four worm drums driven by the telescopic jointed shaft, the drive shafts and the transmission gearbox installed in the adapter frame. The drive is transmitted from the tractor PTO. The adapter frame is connected to the spreader frame by six or eight M14 bolts (depending on version). -
Page 22: Brakes Adjustment
The vertical adapters and the attachment must be handled with the use of a lifting device with the minimum capacity of 1200 kg. 5.7. Brakes adjustment 5.7.1. Parking brake adjustment The parking brake is adjusted by setting the initial cable tension by making a loop of a suitable length on both cable ends. -
Page 23: Adjustment Of The Land Wheels Clearance
5.8. Adjustment of the land wheels clearance When the new spreader has made the first 100 km and after every next 1000-1500 km of its operation, check the clearance of the land wheel bearings and adjust it if necessary. Fig. 7. Checking the clearance of the land wheel bearings. Check the clearance of the land wheel bearingss as follows: Couple the spreader with the tractor on the lower hitch and engage the tractor parking brake. -
Page 24: Neumatic System Servicing
Caution! The hydraulic oil must be replaced in accordance with the operating manual of the coupled tractor, but at least every two years. 6.2. Pneumatic system servicing Periodically check the pneumatic system tightness. Thoroughly inspect every connection. Check the leak- tightness of the system at the rated pressure of approx. -
Page 25: Lubrication
6.4. Lubrication Lubrication of the spreader systems in accordance with the lubrication schedule ensures better performance and protects from premature wear. Follow these rules when lubricating: before attempting to lubricate, thoroughly clean all grease nipples and areas around the lubrication points from mud and dust;... -
Page 26: Technical Characteristics
7. TECHNICAL CHARACTERISTICS Symbol: N280 N280/1 N280/2 Load capacity [kg]: 6,000 8,000 10,000 Overall length [mm]: 7477 7977 Overall width [mm]: 2850 Overall height [mm]: 3110 3220 3210 4120 4620 Loading space: length [mm]: width [mm]: 1960 height [mm]: 1000... -
Page 27: Maintenance, Care And Storage
8. MAINTENANCE, CARE AND STORAGE When the work season is over, do the following: wash the spreader; repair all paint coat decrements; lubricate all lubrication points; protect all quick-release couplings of the hydraulic system from contamination (e.g. by wrapping in foil); check all threaded and pin connections (re-tighten or repair as required);... -
Page 28: Equipment
10. EQUIPMENT Item Details Drawing No. or standard N280, N280/1, N280/2 Wheel chocks Telescopic jointed shaft 6R-602-7-BA-K601 8R-802-3-DA-C803 Operating Instructions, warranty card Make sure that all accessories are present upon purchasing the spreader. Warning: Item 3 is supplied in a plastic bag. -
Page 29: Use
1-hitch, 2-support, 3-land wheel, 4-axle, 5-adapter, 6-adapter power system, 7-adapter jointed shaft, 8-joint guard, 9-top frame, 10-opening side walls, 11-rear wall, 12-bolt, 13-ladder, 14-front mesh. The N280 spreader is a machine adapted for coupling with the tractor's upper transport hitch. The machine consists of the following main assemblies: hitch system (1);... - Page 30 The manure spreader is intended for transport and spreading of loose manure. The manure spreader design includes the load body with side panels and a chain conveyor which moves on the floor. The rear end of the load body is closed by a articulated rear end wall with rubber seals along its bottom edge. The end wall is installed on guides and actuated or positioned by hydraulic actuators.
- Page 31 16–100 SOKÓŁKA, POLAND UL. KRESOWA 62 WARRANTY CARD MANURE SPREADER N280 The warranty service is provided on behalf of the manufacturer by: ............................... filled out by the seller Date of manufacture ........Date of sale ........... Serial number ..........Signature of the Seller ........
- Page 32 Service Service call Date of Description of completed service actions Service Item technician date completion and replaced parts stamp name...
