NewTek TriCaster Mini Quick Start Manual page 3

Front
8
10
I/O 4K
™
Connections Set Up | Front Panel
6. NDI Output Connector
®
• Connect network cable from
the Spark Plus
Source Connector (5) on unit
7. HDMI Input Connector
• Connect HDMI cable from video
12
source to the Spark Plus
8. Microphone Connector
• Connect microphone input
9. Headphone Connector
• Connect headphones for audio
monitoring
9
10. Audio L-R In Connectors
11
• Connect line level audio source
11. Audio L-R Out Connectors
• Connect line level audio output
12. Power Switch
• Press to turn on power to the unit
