- Page 1 BREVA PRO Installation Instructions Use and Care Information Instructions d'installation Utilisez et d'entretien Instrucciones de instalación Información de uso y cuidado BREV308SS600 BREV368SS600 BREV48SS1200...
-
Page 2: Table Of Contents
Mounting on the wall Installation for Mounting Under the Cabinet Connecting house power Operating the controls CFM adjustment < 295CFM CFM adjustment < 395CFM Faber cloud app Remote control Cleaning stainless steel Caring for filters Replacing the activated charcoal filter Replacing bulbs... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS BEFORE YOU START INSTALLING THIS Range Hood WARNING: - TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. - Page 4 3. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. 4. Ducted fans must always be vented to the outdoors. ALL WALL AND FLOOR OPENINGS WHERE THE Range Hood IS INSTALLED MUST BE SEALED.
- Page 5 ELECTRICAL REQUIREMENTS A 120 volt, 60 Hz AC-only electrical supply is required on a separate 15 amp fused circuit. A time-delay fuse or circuit breaker is recommended. The fuse must be sized per local codes in accordance with the electrical rating of this unit as specified on the serial/rating plate located inside the unit near the field wiring compartment.
-
Page 6: Range Hood Dimensions
RANGE HOOD DIMENSIONS BREVA30... - Page 7 BREVA36...
- Page 8 BREVA48...
-
Page 9: Installation Height Requirements
INSTALLATION HEIGHT REQUIREMENTS MIN. 24" OVER ELECTRIC / MIN. 30" OVER GAS Min.24" Min.30" TOOLS NEEDED TOOL Tape Measure Pencil Electric Drill with 5/16" Drill Bit Phillips Screwdriver Metal sheers Work gloves... -
Page 10: Parts
PARTS BREVA 30 PARTS INCLUDED REF. PART Hood body Grease rails Grease filters Damper Spacer Motor REF PART Pozi Screws (1/8" x 3/8") Pozi Screws (3/16" x 1/8") Pozi Screws (Screws 3/16" x 1 15/16") Pozi Screws (Screws 3/16" x 1 3/4") Wall bracket PARTS NEEDED PART... - Page 11 ACCESSORIES AVAILABLE ACCESSORY SKU# TELESCOPIC PRO CHIMNEY 30 TELEPRO30 TELESCOPIC BACKSPLASH 30 BACK 30 DUCTLESS KIT 30 DUCTGRT304 CHARCOAL FILTER FILTER6 FIXED WIRING BOX WIREBOX2 REMOTE CONTROL REMCTRL2...
- Page 12 PARTS BREVA 36 PARTS INCLUDED REF. PART Hood body Grease rails Grease filters Damper Ducting plate Motor REF PART Pozi Screws (1/8" x 3/8") Pozi Screws (3/16" x 1/8") Pozi Screws (Screws 3/16" x 1 15/16") Pozi Screws (Screws 3/16" x 1 3/4") Wall bracket PARTS NEEDED PART...
- Page 13 ACCESSORIES AVAILABLE ACCESSORY SKU# TELESCOPIC PRO CHIMNEY 36 TELEPRO36 TELESCOPIC BACKSPLASH 36 BACK 36 DUCTLESS KIT 36 DUCTGRT364 CHARCOAL FILTER FILTER6 FIXED WIRING BOX WIREBOX2 REMOTE CONTROL REMCTRL2 SECOND Motor KIT IB600PR IMPORTANT: With the second motor kit #IB600PR the recirculating installations is not possible..
- Page 14 PARTS BREVA 48 PARTS INCLUDED REF. PART Hood body Grease rails Grease filters Damper Ducting plate Motor REF PART Pozi Screws (1/8" x 3/8") Pozi Screws (3/16" x 1/8") Pozi Screws (Screws 3/16" x 1 15/16") Pozi Screws (Screws 3/16" x 1 3/4") Wall bracket PARTS NEEDED PART...
- Page 15 ACCESSORIES AVAILABLE ACCESSORY SKU# TELESCOPIC PRO CHIMNEY 48 TELEPRO48 TELESCOPIC BACKSPLASH 48 BACK 48 FIXED WIRING BOX WIREBOX2 REMOTE CONTROL REMCTRL2...
-
Page 16: Attach The Motor
ATTACH THE MOTOR BREVA 30 Remove the 4 screws inside the hood on the Motor support panel. Remove the Motor support panel. - Page 17 Attach the Motor onto the support panel with the 4 screws as shown. IMPORTANT: Please note the direction of the motor in the drawing.
- Page 18 ATTACH THE MOTOR BREVA 36 Remove the 2 screws inside the hood on the Motor support panel. Slide the metal clips to the left and right to unlock the Motor support as shown below. Remove the Motor support panel by sliding the panel down and towards you away from the brackets.
- Page 19 Attach the Motor onto the support panel with the 4 screws as shown. IMPORTANT: Please note the direction of the motor in the drawing.
- Page 20 ATTACH THE MOTOR BREVA 48 Remove the 2 screws inside the hood on the Motor support panel. Slide the metal clips to the left and right to unlock the Motor support as shown below. Remove the Motor support panel by sliding the panel down and towards you away from the brackets.
- Page 21 Attach the 4 screws as shown onto the support panel and attach the 2 Motors. Attach definitly the 2 Motors onto the support panel with Others 4 screws as shown. IMPORTANT: Please note the direction of the motor in the drawing.
-
Page 22: Venting Method
VENTING METHOD REAR OR TOP VENTED Breva 30 Breva 48 Breva 36 8" 10" Vertical Horizontal Go to Pg.23 Rear Go to Pg.26... -
Page 23: Mount The Motor Into The Hood
MOUNT THE MOTOR INTO THE HOOD BREVA 30 Top position Damper Attach the with 4 screws IMPORTANT - Attach the 4 previously removed screws to lock the motor in place. - Page 24 BREVA 36 Top position Ducting plate is fix with 4 screws, remove these 4 screws and use it to Damper attach the over the Ducting plate. Slide the Motor support plate with attached Motor into the metal brackets until the clips engage the Motor. IMPORTANT - Attach the 2 previously removed screws to lock the motor in place.
- Page 25 BREVA 48 Top position Damper Attach the with 4 screws Slide the Motor support plate with attached Motor into the metal brackets until the clips engage the Motor. IMPORTANT - Attach the 2 previously removed screws to lock the motor in place.
- Page 26 BREVA 30 Ducting to the back Unscrew and remove the duct plate on the back of the hood Attach the plate removed previously on the top and now the open plate is on the back.
- Page 27 Remove the flaps from the damper and attach the damper to the back of the hood with 4 screws. Attach the closed metal plate to the top with 4 screws Attach the 4 previously removed screws to lock the motor in place.
- Page 28 BREVA 36 Ducting to the back Unscrew and remove the two duct plates on the top and back of the hood Swap the location of the two plates, so that the closed metal plate is now on top and the open plate is on the back...
- Page 29 Remove the flaps from the damper and attach the open plate and the damper to the back of the hood with 4 screws. Attach the closed metal plate to the top with 4 screws...
- Page 30 Place the Motor support plate (with Motor) onto the back wall of hood by sliding the top in first and then the bottom. Attach the 2 screws previously removed.
- Page 31 BREVA 48 Ducting to the back Unscrew and remove the duct plates on the back of the hood Swap the location of the two plates, so that the closed metal plate is now on top and the open plate is on the back...
- Page 32 Remove the flaps from the damper and attach the open plate and the damper to the back of the hood with 4 screws. Attach the closed metal plate to the top with 4 screws...
- Page 33 Place the Motor support plate (with Motor) onto the back wall of hood by sliding the top in first and then the bottom. Attach the 2 screws previously removed.
- Page 34 MOUNT THE SPACER (ONLY FOR BREVA 30) Attach the spacer with a screw Attach the cap...
-
Page 35: Recirculation Instructions
RECIRCULATION INSTRUCTIONS - ONLY FOR BREVA30 AND BREVA36 For recirculating installations, Charcoal Filters are necessary. Remove all grease filters and set aside. Attach one charcoal filter to each end of the Motor. Each charcoal filter attaches to the grid on the side of the Motor. Rotate the filter clockwise to install and counterclockwise to remove (FIGURE 3C). -
Page 36: Connect The Motor Cable
CONNECT THE MOTOR CABLE Connect the Motor cable to the control box inside the hood body. IMPORTANT: please note the correct direction of the pins in the connector. Be sure to line up the same shaped pins. Failure to do so could damage the product. - Page 37 BREVA 48...
-
Page 38: Mounting On The Wall
MOUNTING ON THE WALL Draw a vertical line on the supporting wall as high as practical, at the center of the area in which the hood will be installed. Draw a horizontal line at where the bottom edge of the hood will be located as indicated in the figure that is a minimum of 24"- 30"... - Page 39 Hang the hood body onto the wall brackets Use a level to insure the hood is even on the wall, use a screwdriver to adjust the brackets as shown. Fully tighten the bracket once level.
- Page 40 Attach 4 safety screws to the back of hood into the wall. Follow the steps indicated below to finish. Mark the wall where indicated. Drill directly into ø 5/16" holes at all the center points marked. Insert the purchased Wall brackets in the holes. Using the remaining screws to anchor the hood in the holes.
- Page 41 Attach the two grease rails Attach the grease filters by inserting the front of the filter into the hood and pushing forward. Insert the back of the filter into the grease rails.
-
Page 42: Installation For Mounting Under The Cabinet
INSTALLATION FOR MOUNTING UNDER THE CABINET SKIP THIS STEP IF USING WALL MOUNTING METHOD IMPORTANT: Soffit or cabinet framing must be capable of supporting 100 lbs. for 30" and 36" models and 150 lbs. for 48" models. When necessary the hood may be installed so that it is supported by the sof- fit or cabinet. - Page 43 TOP DIMENSION BREVA36 TOP DIMENSION BREVA48...
- Page 44 Lift the hood to the cabinet. Attach the Hood Body with 4 screws from the bottom.
- Page 45 Secure the hood with 4 safety screws on the back wall. Mark the wall where indicated. Drill directly into ø 5/16" holes at all the center points marked. Insert the purchased Wall brackets in the holes. Using the four screws to anchor the hood in the holes.
-
Page 46: Connecting House Power
The power cord shall be accessible for inspection after installation. ELECTRICAL INSTALLATION WITH OPTIONAL WIRING BOX For permanent wiring, use only the Direct Connect Wiring Box accessory sku WIREBOX2, manufactured by Faber. Direct Connect Wiring Box Accessory sku # WIREBOX2... -
Page 47: Operating The Controls
OPERATING THE CONTROLS FOR BEST RESULTS Start the Range Hood several minutes before cooking to develop proper airflow. Allow the Range Hood to operate for several minutes after cooking is complete to clear all smoke and odors from the kitchen. B - POWER D - SPEED 3 F - LED... - Page 48 BUTTON FUNCTION INDICATOR E - INTENSIVE LEVEL 1 - A quick press will operate intensive speed level 1 for 6 minutes. INTENSIVE LEVEL 2 - A 2 - second press will operate intensive speed level 2 for 6 minutes. At the end of the 6 minutes the hood returns to the speed that was set before.
- Page 49 Enter or End the Wi-Fi set-up procedure. Before starting the procedure use the Faber Set Up is in Cloud App to register with the IOT Faber progress system. Then follow the instructions to add a new device and register your home wireless router.
-
Page 50: Cfm Adjustment < 295Cfm
Attention: When the under 295 CFM adjustment is completed, it is no longer possible to change this setting to the original CFM level. ATTENTION: For a correct functioning of the FABER CLOUD APP, when this procedure is completed disconnect the plug from the power supply... -
Page 51: Cfm Adjustment < 395Cfm
Attention: When the under 395 CFM adjustment is completed, it is no longer possible to change this setting to the original CFM level. ATTENTION: For a correct functioning of the FABER CLOUD APP, when this procedure is completed disconnect the plug from the power supply... -
Page 52: Faber Cloud App
FABER CLOUD APP Faber Cloud App Your range hood is compatible with the Faber Cloud app. All you need is a Internet connected Wi-Fi network that is within range of the range hood. You can control all the functions of your range hood from anywhere using a mobile device or your Amazon Alexa or Google Home smart speaker. -
Page 53: Remote Control
REMOTE CONTROL(Optional) The remote control replicates the functions of the control panel the hood. # REMCTRL2 CLEANING STAINLESS STEEL Cleaning Exterior surfaces: Please note, abrasives and scouring agents can scratch range hood finishes and should not be used to clean finished surfaces. Stainless Steel finish cleaning instructions: Clean exterior surfaces with a commercially available stainless steel cleaner. -
Page 54: Caring For Filters
CARING FOR FILTERS CLEANING METAL GREASE FILTERS The metal grease filters can be cleaned in hot detergent solution or washed in the dishwasher. They should be cleaned every 2 months use, or more fre- quently if use is particularly heavy. Remove the filter by pushing towards the back of the unit and at the same time pulling downward. -
Page 55: Replacing The Activated Charcoal Filter
4. Replace, taking care to ensure that the handle faces forwards. CAUTION: When used in recirculation mode, to Reduce the Risk of Fire and Shock use only conversion kit Model # FILTER6 REPLACING BULBS LED lights must be replaced by Faber factory authorized service. -
Page 56: Wiring Diagram
WIRING DIAGRAM... -
Page 57: Warranty
All issues with installed products are considered warranty claims and not subject to the Return Policy. Franke reserves the right to inspect any Franke / Faber product reported to be defective pursuant to a Warranty claim and the original installation prior to providing a replacement product and/or component. - Page 58 To make an installed product warranty claim please contact Franke at the provided contact information below. All warranty claims must include the following for processing: 1. Proof of purchase from Franke or Faber Authorized Retailer 2. Original purchaser’s name, address (included city, state, zip), email address and phone number 3.
