Whalen Bayside CSC58FT-3 Manual

Foosball table
Hide thumbs Also See for Bayside CSC58FT-3:

Advertisement

Quick Links

品項 / 商品編號1515048
MODEL / 型號 / MODELO: CSC58FT-3
Foosball Table
手足球桌
Mesa de futbolito
Customer Service: 1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 am - 4:30 pm, Monday to Friday
(Phone number is not valid in Mexico, toll-free in U.S.A. and Canada only)
Or visit our website www.baysidefurnishings.com
For customer service outside of North America,
please e-mail your request to parts@baysidefurnishings.com
客服專線:1-877-494-2536(提供英語、法語及西班牙語服務)
太平洋標準時間:週一至週五,上午8:30至下午4:30
(此電話號碼於墨西哥無效,只限美國與加拿大免付費使用)
或可連結我們的網站 www.baysidefurnishings.com
北美以外地區若需聯絡客服時,
請將您的需求以電子郵件寄送至 parts@baysidefurnishings.com
Servicio al cliente: 1-877-494-2536 (inglés, francés y español)
Hora estándar del Pacífico, E.U.A.: lunes a viernes, de 8:30 am a 4:30 pm
(Teléfono no válido en México, número gratuito en E.U.A. y Canadá solamente)
o visite nuestra página de internet: www.baysidefurnishings.com
Para servicio al cliente fuera de Norteamérica, por favor envíe su solicitud por
correo electrónico a parts@baysidefurnishings.com
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
內含重要說明,請保留以供日後參考使用:請詳閱。
IMPORTANTE: CONSERVE PARA FUTURA REFERENCIA. LEA CUIDADOSAMENTE.
Date / 日期 / Fecha: 2021-07-15
Rev. / 修訂版 / Rev. 0001-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bayside CSC58FT-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Whalen Bayside CSC58FT-3

  • Page 1 品項 / 商品編號1515048 MODEL / 型號 / MODELO: CSC58FT-3 Foosball Table 手足球桌 Mesa de futbolito Customer Service: 1-877-494-2536 (English, French and Spanish) Pacific Standard Time: 8:30 am - 4:30 pm, Monday to Friday (Phone number is not valid in Mexico, toll-free in U.S.A. and Canada only) Or visit our website www.baysidefurnishings.com For customer service outside of North America, please e-mail your request to parts@baysidefurnishings.com...
