- Page 1 Natural Gas Broilers Models CE-CN-KB-3, KB-4 Items 47496, 47497 Instruction Manual Revised - 09/02/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model CE-CN-KB-3 / Model CE-CN-KB-4 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 7 Operation --------------------------------------------------------------------------------------------- 8 Maintenance ----------------------------------------------------------------------------------------- 9 Troubleshooting ----------------------------------------------------------------------------------- 10... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
Safety and Warranty Please see https://omcan.com/disclaimer for complete info. WARNING: The packaging components (cardboard, polyethylene, and others) are classified as normal solid urban waste and can therefore be disposed of without difficulty. In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. -
Page 7: Installation
Installation • The equipment and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa). • The equipment must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½... -
Page 8: Operation
Operation LIGHTING THE PILOT The manifold units are equipped with standing pilots and each should be lit immediately after the gas is supplied to the equipment. 1. Before attempting to light the pilots, turn off the main gas valve to the equipment and wait 5 minutes to clear the gas. -
Page 9: Maintenance
Maintenance COMPONENT PARTS The broiler comes with several standard parts as illustrated. Each can be easily removed and installed easily by hand for cleaning and maintenance. Note that the Burner and Deflector are an assembly and are NOT designed to be disassembled. CLEANING Spits may be immersed in strong commercial cleaning compound overnight. -
Page 10: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSES Uneven heating, sides burning. Burner valves improperly adjusted. Fluctuating gas pressure. Improperly adjusted burner. Too much top heat. Burner valves adjusted too high. Faulty ventilation. Overrated gas pressure. Improperly adjusted burner. Uneven heat side to side. Burner valves improperly adjusted. -
Page 11: Parts Breakdown
Parts Breakdown Model CE-CN-KB-3 47496 Model CE-CN-KB-4 47497... - Page 12 Parts Breakdown Model CE-CN-KB-3 47496 Item No. Description Position Item No. Description Position Item No. Description Position AL117 Back Plate for 47496 AL133 Sliding Bracket for 47496 AL145 Pin for 47496 AL118 Frame Assembly for 47496 AL134 Locking Nut for 47496...
-
Page 13: Electrical Schematics
Electrical Schematics Model CE-CN-KB-3 47496 Model CE-CN-KB-4 47497... -
Page 14: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... -
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
