INLINE MIXED-FLOW FANS
inWave
inWave EC
User's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the inWave and is the answer not in the manual?

Questions and answers

Related Manuals for BLAUBERG Ventilatoren inWave

Summary of Contents for BLAUBERG Ventilatoren inWave

  • Page 1 INLINE MIXED-FLOW FANS inWave inWave EC User’s manual...

  • Page 2: Table Of Contents

    The manual contains information about purpose, technical details, operating principle, design, and installation of the inWave (EC) unit and all its modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
  • Page 3 This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety.
  • Page 4 Connection to the mains must be made through a disconnecting device, which is integrated into the fixed wiring system in accordance with the wiring rules for design of electrical units, and has a contact separation in all poles that allows for full disconnection under overvoltage category III conditions.
  • Page 5 All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
  • Page 6 of any foreign objects that can damage the impeller blades. While mounting the unit, avoid compression of the casing! Deformation of the casing may result in motor jam and excessive noise. Misuse of the unit and any unauthorised modifications are not allowed.
  • Page 7 order to incorporate the latest technological developments. Never touch the unit with wet or damp hands. Never touch the unit when barefoot. BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS. THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE. DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE...
  • Page 8 (EC) 100/125 (spigot ø100 mm) inWave (EC) 100/125 (spigot ø125 mm) inWave (EC) 150 (spigot ø150 mm) inWave (EC) 160 (spigot ø150 mm with a rubber seal) Ø D inWave (EC) 100/125 inWave (EC) 150...

  • Page 9: Delivery Set

    Screws and dowels – 4 pcs. User’s manual – 1 pc. Packing box – 1 pc. Rubber seal (for the inWave 150/160 model) – 2 pcs. BRIEF DESCRIPTION The product described herein is a mixed-flow inline fan for supply or extract ventilation of premises.

  • Page 10: Designation Key

    DESIGNATION KEY inWave EC 150 US Options: T: timer; G1: speed controller with an electronic thermostat and an outdoor temperature sensor fixed on a 4 m cable. Equipped with a power cord with a mains plug. Temperature-based operation logic; GT1: speed controller with an electronic thermostat and external temperature sensor fixed on a 4 m cable.

  • Page 11: Technical Data

    TECHNICAL DATA To comply with the ErP 2018 regulation, a local demand controller and speed controller must be used.

  • Page 12: Mounting

    MOUNTING The fan is suitable both for horizontal or vertical mounting on the floor, on the wall or on the ceiling. The fan can be installed independently or as part of a set with parallel or in-series connection. min 1 m...
  • Page 13 The diameter of the spigots in the Stream 100/125 model can be changed using adapters, and in the Stream 150/160 model using the rubber seal. On outlet (discharge) spigot side it is necessary to install: • in case of horizontal installation – a duct with a length of at least 1 m; •...
  • Page 14 3 1 4 1 3 3...
  • Page 15 The fan wiring diagrams inWave inWave ...T High High High...
  • Page 16 High – maximum speed terminal; Med – medium speed terminal; Low – minimum speed terminal; QF – automatic circuit breaker; S – external speed controller; ST – external switch (for example, a light switch); X – input terminal. inWave EC Designations on diagrams: N — neutral L —...
  • Page 17 ...T 2 min 30 min inWave EC...

  • Page 18: Electronics Operation Algorithm

    ELECTRONICS OPERATION ALGORITHM inWave (EC)...FR1 inWave (EC)...G1,GT1,GS1 Thermostat control knob Speed control knob Speed control knob inWave The fan speed without options can be controlled by voltage, as well as by thyristor controllers. A speed controller can be purchased separately.
  • Page 19 The inWave ...T fan activates upon control voltage application to the LT input terminal by the external switch (e.g. indoor light switch). After the control voltage is off, the fan continues to operate within the set time period adjustable from 2 to 30 min by the timer.
  • Page 20 As the air temperature drops 2 °C below the set point or if the initial temperature is below the set point, the fan operates with the set speed. The inWave ...FR1 fan is equipped with a speed controller that enables switching the fan on/off and smooth speed (air flow) regulation from minimum to maximum value.

  • Page 21: Technical Maintenance

    TECHNICAL MAINTENANCE The fan surfaces must be regularly cleaned (once in 6 months) from dirt and dust. Disconnect the fan from power mains prior to any maintenance operations. To clean the fan, use a soft cloth or a brush wetted in a mild detergent solution. Do not allow water or liquid come into contact with electric components.

  • Page 22: Troubleshooting

    TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line When the unit is connected to power No power supply. is connected correctly, otherwise troubleshoot a connection error. mains, the fan does not rotate and does not respond to any controls. Internal connection fault.

  • Page 23: Storage And Transportation Regulations

    STORAGE AND TRANSPORTATION REGULATIONS • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5 ˚С to +40 ˚С and relative humidity up to 70 %. • Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and sealing deformation.

  • Page 24: Manufacturer's Warranty

    MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/ EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 25 • Redesign or engineering changes to the unit. • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. •...
  • Page 27 Quality Inspector’s Stamp Seller (name and stamp of the seller) Manufacture Date Purchase Date...
  • Page 28 inWave________________________________ www.blaubergventilatoren.de B238EN-03...
