Saving Data Log to a Smart Flash SD Card

1. Insert the target Smart Flash SD Card
(that has adequate space available) into
the control as previously described.
2. Press the Right Arrow (Comm Hot
Button) pushbutton. The control will go
directly to the "Memory Card" menu.
Memory Card
W
3. Press the Down Arrow pushbutton as
necessary to navigate to the "Save Data
Log" menu item.
Save Data Log
Press ENT to begin
4. Press the "ENT" pushbutton. The control
will respond with a "Confirmation"
message screen.
Press ENT to view
available data range
5. Press the "ENT" pushbutton. The control
will display a range of data.
MM/DD/YY HH:MM:SS
MM/DD/YY HH:MM:SS
6. Press the "ENT" pushbutton to enter
the desired data range. The control will
display the following with the cursor
located under the far left digit:
Enter start time
MM/DD/YY HH:MM:SS
2–40
7.
8.
V
9.
C
Utilizing the arrow pushbuttons enter
the desired "start" date and time, then
press "ENT". The control will display the
following:
Enter end time
MM/DD/YY HH:MM:SS
Utilizing the arrow pushbuttons enter
the desired "end" date and time, then
press "ENT". The control will display the
following:
Enter file name
M6280ADLG
Utilizing the arrow pushbuttons enter the
desired "file name", then press "ENT".
The control will briefly display a progress
screen and then display the file saved
screen.
Saving data file.
Please wait........
File saved!
Any key to continue
