- Page 1 Fire & Safety Systems TWM-1885 Wireless Addressable Coordinator Installation & User Manual Revizyon Tarihi: 15/09/2021 Rev:01...
-
Page 2: Table Of Contents
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR Contents - General ............................2 - Technical Specifications ......................2 Installation..........................2 - Mounting ..........................3 3.1.1 - Cable Holes ........................ 3 3.1.2 - Wall Mounting ......................4 - Antenna Installation ......................4 - Network Cable Connection .................... -
Page 3: General
FLASHLINK-TLPWAN protocol converter. TLPWAN (Teknim Low Power Wide Area Network) is a wireless communication protocol developed by Teknim, in which devices with low power requirements can communicate stably and reliably in larger areas using two-way communication. -
Page 4: Mounting
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 3.1 - Mounting To establish a healthy communication between the coordinator and the devices, pay attention for following conditions: • Choosing a proper communication channel will make the communication between the devices more stable. Channel selection can be made automatically or manually. If manual selection is to be made, initially all transmissions in the environment must be detected with the RF- analyzer and according to this, relatively the most available channel must be preferred. -
Page 5: Wall Mounting
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 3.1.2 - Wall Mounting Mark the wall according to the 4 screw holes seen below and bore 4 holes on the wall by using a drill according to the diameters of the wall plugs included in the pack. Insert the wall plugs into the bored holes and fix the module on the wall by screwing it onto the wall. -
Page 6: Network Cable Connection
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR Figure 4 – Antenna Housing Installation 3.3 - Network Cable Connection Pass the cables through the cable holes and strip their ends at a proper length, then make “in” and “out” connections as shown in the following connection diagram. Make sure that the terminal screws are tightened firmly. -
Page 7: Module Interface
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR Normally Open Common Normally Closed Figure 6 – Relay Connection Diagram - Module Interface Tamper Button OLED Screen Loop Connection L3 - Alarm Led L4 - Heart Led Relay Out L5 – Fault Led L6 – Low Battery Led... -
Page 8: Programming Menu
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR • Fault Led: It shows any fault state on the system. • Low Battery Led: It lights when the battery of any wireless devices is low. • L1 Led: It lights when connection to wireless network is activated. -
Page 9: Settings
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR Fault (2) >1.Coordinator ID:18850601200001 2.Detector ID:18502001200015 To navigate through the device list, use the DOWN and UP buttons on the menu. Go to sub-menu by pressing the FORWARD button to read the details of faults. Example: Coordinator is selected, and its fault detail is displayed. - Page 10 TWM-1885 WIRELESS ADDRESSABLE COORDINATOR Use the UP and DOWN buttons to change the address value by increasing or decreasing the value. Press FORWARD button to approve and see the “Successful” inscription on the screen. Press BACK button to exit from the menu or to cancel the changed value. Address value cannot be selected higher than 225.
- Page 11 TWM-1885 WIRELESS ADDRESSABLE COORDINATOR wireless systems can communicate through “10” channels. To enter the Channel screen, navigate through the settings menu by using UP and DOWN buttons and select “Channel” menu. To change the channel value increase or decrease the value by using UP and DOWN buttons. Press FORWARD button to approve and see the “Successful”...
-
Page 12: Functions
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 3.6.3 - Functions Functions menu allows the settings such as wireless system setup, reset, connection permission to be made. Functions To enter the menu: “Main screen” > FORWARD > DOWN > “Functions” > FORWARD Functions >1. Setup PAN 2. - Page 13 TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 3.6.3.2 - Delete PAN!! A previously established PAN (Wireless Network) can be deleted from this menu. PAN deletion operation does not affect other wireless networks, but only deletes the devices connected to it and the settings and gets prepared for a new PAN to be set.
-
Page 14: Device List
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 3.6.3.4 - Reset PER PER is an abbreviation being used in the communication technology. It stands for Packet Error Ratio. It indicates the ratio of the number of erroneous packets sent by the device from the beginning to the total number of packets sent. - Page 15 TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 18871702200013 18871702200013 >1.Address:(2)24966 5.HW: 1.0.0 2.RSSI: -23dB 6.SW: 1.0.0 3.Battery: 98% 7.Ping: 20s 4.PER: <2% 8. Reset PER 5.HW: 1.0.0 >9. Delete Example: GC Module is selected and the device detail is viewed. Device Details Screen: 1.
-
Page 16: Information
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 3.6.5 - Information Module software and hardware versions, PAN details are viewed under this screen. Information To enter the menu: “Main screen” > FORWARD > DOWN > “Information” > FORWARD Information Information >1.16 Device 4.SW: 1.0.0 2.4 Router... -
Page 17: Ping Time
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR - Ping Time Ping time indicates the frequency that the devices will communicate with the connected coordinator or router. A shorter ping time means that the coordinator will communicate with the device faster and that reduces battery life. -
Page 18: Quick Menu Access
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR - Quick Menu Access General structure of the module menu is shown in the following diagram. Address Device X Fire Type Fires Device Z Address Events Fault 1 Faults Device A Fault 2 Warnings Fault.. Addressing... -
Page 19: Events And Indicators
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR - Events and Indicators The events of all devices in the wireless system and the way they are displayed are given in the tables below. Wireless Detector OLED Smoke Alarm Temperature Alarm Pollution Alarm Temperature Increase Alarm... -
Page 20: Signal Strength Table (Rssi Table)
“Connection Permission” screen. - Software Update You may download the software files of all wireless devices under the “Firmware & Software” section of www.teknim.com web site and carry out the update operation by using “Teknim Updater” software. TWM-1885 WIRELESS ADDRESSABLE COORDINATOR... -
Page 21: Manufacturer
TWM-1885 WIRELESS ADDRESSABLE COORDINATOR 1922 Bilgi Elektronik San. ve Tic. A.Ş. Dudullu OSB 1. Cad. İsmet Tarman İş Merkezi No:1 Kat:2 No:32 Ümraniye / İstanbul 1922-CPR-1596 EN 54-18:2005, EN 54-18:2005/AC:2007 Fire Detection And Fire Alarm Systems (Input/Output Devices) EN 54-17:2005, EN 54-17:2005/AC:2007...
