MTX100 MPEG Recorder & Player Service Manual
Checking the Record Operation.
24. Press the REC button on the MTX100 Option 02 to display the Record
screen.
25. In the Record menu on the MTX100 Option 02, make the following
settings:
Source . . . . . .
Record size . .
Target . . . . . .
26. In the Univ I/F menu on the MTX100 Option 02, make the following
settings:
Level . . . . . . .
Format . . . . . .
Receive . . . . .
Termination . .
27. Press the PLAY button on the MPEG recorder & player to display the Play
screen.
28. In the Play menu on the MPEG recorder & player, make the following
settings:
Data rate . . . .
Update . . . . . .
Source . . . . . .
29. In the Univ I/F menu on the MPEG recorder & player, make the following
settings:
Level . . . . . . .
Format . . . . . .
30. Open the UNIpara file on the MPEG recorder & player.
a. Select Open from the File menu.
b. In the resulting Select File dialog box, select the UNIpara file, and then
press the ENTER button.
31. Press the PLAY button on the MPEG recorder & player to start the signal
output of the file.
32. Verify that the hierarchic view is displayed on the screen of the MTX100
Option 02. In addition, verify that the bit rate display is 200 Mbps.
33. Select Save from the File menu on the MTX100 Option 02 to open the Save
As dialog box.
Univ I/F
100 MBytes
RAM
LVDS
Parallel
Differential
On
200 Mbps
Off
RAM
LVDS
Parallel
Performance Verification
4-27
