Page 15: General Safety Summary
Provide Proper Ventilation. Refer to the manual’s installation instructions for details on installing the product so it has proper ventilation. No Power Switch. The power supply cord is considered the disconnecting device; disconect the main power by means of the power cord. MTX100 MPEG Recorder & Player User Manual...
Page 16 WARNING indicates an injury hazard not immediately accessible as you read the marking. CAUTION indicates a hazard to property including the product. Symbols on the Product. The following symbols may appear on the product: CAUTION Protective Ground (Earth) Terminal Refer to Manual MTX100 MPEG Recorder & Player User Manual...
Page 17 Preface The user manual for the MTX100 MPEG Recorder & Player contains the following sections: Getting Started briefly describes the MTX100 MPEG Recorder & Player and provides installation instructions, options listing, accessories listing, repacking instructions, and power on and off instructions.
Page 18: Contacting Tektronix
Related Manual The following related documentation for the instrument is available: H The MTX100 MPEG Recorder & Player Service Manual (Tektronix part number 070-A835-XX) describes how to maintain and service the MTX100 and provides a complete module-level description of the operation of the instrument.
Page 19 Getting Started...
Page 21: Getting Started
H Functional check procedure H Windows operations Product Description The MTX100 MPEG Recorder & Player generates and captures MPEG-2 transport streams that are compliant with ATSC, DVB, and ARIB standards. The MTX100 provides the following features: H Data rate: 200 Mbps maximum; 1 Kbps minimum...
Page 22: Table 1-1: Standard And Optional Accessories
Windows 2000. Accessories Table 1-1 lists the standard and optional accessories provided with the MTX100. Table 1 1: Standard and optional accessories Tektronix part number Accessory Std.
Page 23: Table 1-2: Instrument Options
Getting Started Options Table 1-2 lists the instrument options that can be ordered with the MTX100. Table 1-3 lists the available power cord options. Table 1 2: Instrument options Option number Description When you order Option 01, the MTX100 is equipped (Add ASI Interface) with the ASI interface.
Page 24: Initial Product Inspection
1. Inspect the MTX100 shipping carton for external damage, which indicates possible damage to the instrument. 2. Remove the MTX100 from the shipping carton, and then check that the instrument has not been damaged in transit. Prior to shipment, the instrument is thoroughly inspected for mechanical defects.
Page 25: Table 1-4: Environmental Operating Requirements
NOTE. If you are installing the instrument in a dedicated rack, refer to the instruction sheet that comes with the rackmounting kit for proper installation procedures. When the MTX100 is mounted in a 19-inch rack, verify that there is at least one unit of clearance above the MTX100. AC Line Voltage...
Page 26 NOTE. Allow the instrument to warm up for 20 minutes prior to calibrating the clock. The instrument must be completely warmed up to operate at its optimum precision. MTX100 MPEG Recorder & Player User Manual...
Page 27: Figure 1-1: Rear-Panel Power Connector
Getting Started Power connector Figure 1 1: Rear panel power connector ON/STBY switch Figure 1 2: Front panel ON/STBY switch MTX100 MPEG Recorder & Player User Manual...
Page 28: Repackaging For Shipment
125 kg (275 pounds). 2. If the instrument is being shipped to a Tektronix Service Center for repair or calibration, attach a tag to the instrument showing the following information: H The owner of the instrument (with address).
Page 29: Figure 1-3: Select File Dialog Box
5. Connect the interface cable provided with the instrument between the SPI IN/OUT connector on the MTX100 rear panel to the SPI IN connector on an MPEG decoder. See Figure 1-4. 6. Connect the decoder to a picture monitor.
Page 30: Figure 1-4: Equipment Connection For The Functional Check
Figure 1 4: Equipment connection for the functional check Windows Operations All of the functions of the MTX100 is performed as an application (MTX100 application) on Windows 2000 operating system. Therefore, if you connect the keyboard and mouse provided with the instrument to the front-panel USB connectors, you can operate the MTX100 system with the same environment as a Windows PC.
Page 31 Getting Started File Operation There are no menu commands managing file operations in the MTX100 application. Perform the file operations such as copy, delete, or upload/download on Windows. Refer to Windows 2000 Online Help or other documentation about file operations.
Page 32 Getting Started 1 12 MTX100 MPEG Recorder & Player User Manual...
Page 33 Operating Basics...
Page 35: Operating Basics
Operating Basics This section explains the basics of operating the MTX100. The information is divided into the following subsections: H Functional Overview contains descriptions of the front-panel controls, the rear-panel connectors, and elements of the display. H Optional Interface Cards describes the connectors and its function of each of the optional interface cards.
Page 36: Figure 2-1: Mtx100 Front Panel
Press the button again to start the stream output. When an M-TMCC transport stream is selected, the MTX100 outputs the stream from the start packet in the super frame to the maximum number of packets that can be looped as an integral multiple of the number of super frames.
Page 37 Icon cursor or to move among the menu selections. HDD Access Indicator. This indicator lights when the hard disk drive or the CD-ROM drive is in operation. MTX100 MPEG Recorder & Player User Manual...
Page 38: Figure 2-2: Mtx100 Rear Panel
MO drives. For instructions on how to connect a SCSI hard disk see page C-1. 100/10 BASE T. Use this connector to connect the MTX100 to your local Ethernet network. MTX100 MPEG Recorder & Player User Manual...
Page 39 Optional Interface Cards on page 2-10 for detailed information about the interface cards. Display Elements There are two types of display screens to operate the MTX100; the Play screen and the Record screen. H Play screen is used to output the selected stream. When you power on the instrument, this screen will display the last screen showing, previous to powering down.
Page 40: Figure 2-3: Elements Of The Play Screen
Menu Bar. The Menu bar displays the names of the menus that can be used in the Play or Record screen. Press the MENU button to enable or disable the menus. Refer to Using the Menus on page 3-3 for detailed information about the menus. MTX100 MPEG Recorder & Player User Manual...
Page 41: Figure 2-4: Play Status Indicator
1. Position Indicator. In the Play screen, this indicator shows the progress of stream output using the duration gauge. In the Record screen, this indicator shows the progress of stream record using the duration gauge. MTX100 MPEG Recorder & Player User Manual...
Page 42 This icon shows that the captured stream is being recorded. This icon shows that the stream record is being stopped. This icon shows that the MTX100 waits for a trigger event. This icon shows that a trigger event occurs. This icon shows that the captured stream is being processed on the hard disk.
Page 43: Figure 2-5: Status Bar
6. Output Source/Record Target. In the Play screen, this indicator shows the output source used to output the selected stream. In the Record screen, this indicator shows the record target used to record the input stream. MTX100 MPEG Recorder & Player User Manual...
Page 44: Optional Interface Cards
When the TCP/IP connection is closed, the remote status icons disappear. Optional Interface Cards The MTX100 is equipped with a card slot on the rear panel to install one of the following optional interface cards: H ASI interface (Option 01)
Page 45: Figure 2-6: Asi Interface
EVENT OUT. Use this BNC connector to output an event signal. This signal is the same as the PSYNC signal of the parallel output. 2 11 MTX100 MPEG Recorder & Player User Manual...
Page 46: Figure 2-8: Bnc Serial Interface
EXPANSION OUT. Use this 26 pin D-connector to output a DHEI (Digital Headend Equipment Interface) signal. EXPANSION IN. Use this 26 pin D-connector to input a DHEI (Digital Headend Equipment Interface) signal. 2 12 MTX100 MPEG Recorder & Player User Manual...
Page 47: Figure 2-10: Ieee1394/Asi Interface
H While a stream is being recorded using the IEEE1394 connector. H While a stream is being recorded using the ASI IN connector. ASI IN. Use this BNC connector to input an ASI (Asynchronous Serial Interface) signal. 2 13 MTX100 MPEG Recorder & Player User Manual...
Page 48: Figure 2-11: Smpte310M/Asi Interface
Basic Menu Operation This section describes the basics of using the MTX100’s menu and the methods for entering numeric input in the various dialog boxes. The menus are displayed in the menu bar at the top of the Play or Record screen.
Page 49: Figure 2-12: Front Panel Showing The Menu Controls
NOTE. When you press the left arrow button while the File menu is displayed or when you press the right arrow button while the Utility menu is displayed, the command list for window operation of the MTX100 application is displayed. Display States of the Menu Commands. The menu commands can have the...
Page 50: Figure 2-13: Display States Of The Menu Commands
2. Press the TAB button repeatedly to select (highlight) the numeric parameter you want to change in the open dialog box. 3. Press the SELECT button to open the 10 Key Pad (see Figure 2-14). 2 16 MTX100 MPEG Recorder & Player User Manual...
Page 51: Figure 2-14: 10 Key Pad
6. Repeat steps 4 and 5 to enter all of the desired values. If you add an input digit, press the left ( ) arrow button. 7. After you change all of the values, press the ENTER button. 2 17 MTX100 MPEG Recorder & Player User Manual...
Page 52: About The Data Output Source
When you select the RAM as an output source, the MTX100 performs the following: H When data output rate is less than or equal to 120 Mbps, the MTX100 outputs the first stream data while transferring the data from the hard disk to the RAM and then continuously outputs the data from the RAM using looping methods.
Page 53: Table 2-1: Tutorial Recommended Test Equipment And Accessories
H Outputting a transport stream H Recording a transport stream NOTE. These tutorials do not cover all the features and functions of the MTX100. The tutorials are intended to introduce you to the operations required to execute the instrument’s basic functions.
Page 54: Figure 2-15: Select File Dialog Box
Tutorials Outputting a Transport Stream The hard disk drive of the MTX100 is shipped with files containing factory-sup- plied samples of transport streams. This tutorial opens one of these sample files and outputs the transport stream. Perform the following steps to select and output a stored transport stream: 1.
Page 55: Figure 2-16: Hierarchy View Of The Transport Stream File
7. Set up the MPEG test system to monitor the transport stream output from the MTX100. Figure 2-18 shows the transport stream data displayed on a Tektronix MTS300 Series Real-Time Analyzer. 8. Press the STOP button on the MTX100 to stop the transport stream output. Observe that the Play Status indicator disappears. 2 21...
Page 56: Figure 2-18: Transport Stream Display From A Tektronix Mts300 Series Real-Time Analyzer
Tutorials Figure 2 18: Transport stream display from a Tektronix MTS300 Series Real Time Analyzer Recording a Transport Stream This tutorial captures a transport stream being applied into the SPI IN/OUT connector and records it in the hard disk as a file.
Page 57: Figure 2-20: Record Status Indicator
MTX100 may not function correctly. 2. Connect the interface cable between the SPI IN/OUT connector on the MTX100 rear panel to the SPI connector of the MPEG test system. 3. Output a transport stream from the MPEG test system.
Page 58 Tutorials 2 24 MTX100 MPEG Recorder & Player User Manual...
Page 59 Reference...
Page 61: Reference
H Network Interface Specifications describes the MTX100 network interface specifications. H Using the IEEE1394 Interface (Option 05 Only) explains how to connect the MTX100 Option 05 and an IEEE1394 devices(s), and how to set up the MTX100 Option 05. MTX100 MPEG Recorder & Player User Manual...
Page 62 Reference MTX100 MPEG Recorder & Player User Manual...
Page 63: Table 3-1: File Menu Commands (Play Screen)
Opens a stream file stored in the E: drive (volume E). When a file is selected, the MTX100 checks the packet size of the file. When it is a transport stream file, its data is output in a packet unit. Therefore, if an incomplete packet is included at the start or end point of the file, the portion is not output.
Page 64: Figure 3-1: Select File Dialog Box
Table 3 1: File menu commands (Play screen) (Cont.) Command Description Exit Quits the MTX100 application. The MTX100 application settings are saved. Shutdown Quits the MTX100 application and shuts down the MTX100. Select File Dialog Box. When you select the Open command from the File menu, the Select File dialog box appears as shown in Figure 3-1.
Page 65: Table 3-2: View Menu Commands
8VSB or 16VSB for an output signal format in Option 06, the packet size is fixed to 188. When you select Non TS, the MTX100 deals with stream data in a byte unit (not a packet unit) and outputs all of the data in a file. If a transport stream contains any error, you can output it by selecting Non TS.
Page 66 Sets whether or not the transport stream is automatically output using the last power down settings when you turn the MTX100 on. You can select On or Off. If you set it to On, take care of the output level setting used when the MTX100 was last turned off and the input level of the instrument (device) currently connected to the MTX100.
Page 67: Figure 3-2: Clock Dialog Box
) arrow button to select the desired clock source. You can select from the following settings: Internal uses the internal clock of the MTX100 as the clock reference. Ext Ref allows you to input a signal on the CLK/REF IN connector for use as the clock reference.
Page 68 Enter values into the numerator and denominator text boxes (see Figure 3-2, on page 3-7). The MTX100 will then calculate the clock rate based on the ratio of the numerator and denominator values. Enter a value into the clock rate text box. The MTX100 will then calculate the numerator and denominator text boxes based on the clock rate.
Page 69: Figure 3-3: Non-Ts Sync Dialog Box
Non TS Sync Dialog Box. When you select the Non-TS from the Sync command in the Play menu, the Non-TS Sync dialog box appears as shown in Figure 3-3. Figure 3 3: Non TS Sync dialog box MTX100 MPEG Recorder & Player User Manual...
Page 70: Figure 3-4: Pcr Initial Value Dialog Box
Press the TAB button repeatedly to select the text box, and then press the SELECT button to open the 10 Key Pad. Use the 10 Key Pad to set the desired value. 3 10 MTX100 MPEG Recorder & Player User Manual...
Page 71: Figure 3-5: Timer Play/Record Dialog Box
) or down ( ) arrow button to set the value. If a mouse is connected to the MTX100, you can display a calendar for date setting by clicking the arrow button at the right side of the date display, When you press the ENTER button after setting the date and time, a dialog box showing the current date and time, and set date and time is displayed.
Page 72: Figure 3-6: Start/Stop Position Dialog Box
OFDM frames between the start packet and stop packet is not an even number, the packet in the last OFDM frame becomes the stop packet. 3 12 MTX100 MPEG Recorder & Player User Manual...
Page 73 To reset all of the settings to the values when the dialog box is first displayed, press the TAB button repeatedly to select the Reset button, and then press the SELECT button. 3 13 MTX100 MPEG Recorder & Player User Manual...
Page 74 Press the TAB button repeatedly to select the check box, and then press the ENTER button to toggle the output on or off. 3 14 MTX100 MPEG Recorder & Player User Manual...
Page 75 TDT, TOT, or STT are available. Press the TAB button repeatedly to select an option button, and then press the arrow buttons to select one of the options. 3 15 MTX100 MPEG Recorder & Player User Manual...
Page 76: Table 3-4: Asi I/F Menu Commands (Play Screen)
Through Out Sets whether the signal supplied to the ASI IN connector is output from the ASI OUT connector when a stream is not output. You can select On or Off. 3 16 MTX100 MPEG Recorder & Player User Manual...
Page 77: Table 3-5: Univ I/F Menu Commands (Play Screen)
Sets whether the signal supplied to the EXPANSION IN (OUT) connector is output from the EXPANSION OUT (IN) connector when a stream is not output. You can select On or Off. 3 17 MTX100 MPEG Recorder & Player User Manual...
Page 78: Table 3-8: Asi/1394 Menu Commands (Play Screen)
Refer to IEEE1394 Dialog Box on page 3 18 for more information. Bus Reset Performs software resetting for the IEEE1394 bus. Use this command to reset the connection when the MTX100 Option 05 does not recognize an IEEE1394 device or when an IEEE1394 device does not recognize the MTX100 Option 05.
Page 79: Table 3-9: Asi/310M Menu Commands (Play Screen)
SELECT button to toggle the check box on (checked) or off (not checked). Some IEEE1394 devices do not recognize the MTX100 Option 05 when you make connection from the MTX100 Option 05. In this case, when you select the check box, the IEEE1394 device takes initiative for the connection. You need to select the check box when you connect a BS/CS tuner to the MTX100 Option 05.
Page 80: Figure 3-9: Communication Dialog Box
Figure 3 9: Communication dialog box H Port Number: Sets the port number needed to remotely control the MTX100 over an Ethernet network. You can set the value from 1024 to 65535. Press the TAB button repeatedly to select the box, and then press the up ( or down ( ) arrow button to set the value.
Page 81: Figure 3-10: Status Dialog Box
Status Dialog Box. When you select the Status command from the Utility menu, the Status dialog box appears as shown in Figure 3-10. This dialog box shows the version of the MTX100 application and hardware version of the main and installed interface modules.
Page 82: Table 3-11: File Menu Commands (Record Screen)
The File menu in the Record screen contains commands for setting the save mode and for saving and loading a preset file. This menu also contains com- mands for exiting the MTX100 application and for shutdown of the instrument. Table 3-11 describes the commands in the File menu.
Page 83: Table 3-12: Record Menu Commands
Others Dialog Box on page 3 25 for more information. Target Dialog Box. When you select the Target command from the Record menu, the Target dialog box appears as shown in Figure 3-11. Figure 3 11: Target dialog box 3 23 MTX100 MPEG Recorder & Player User Manual...
Page 84 H Format: Specifies the way to set the record size and trigger position. You can select Time or File Size. H Ignore D valid: Sets whether the MTX100 ignores the DVALID signal from the selected interface when a stream data is acquired. When it is checked, the MTX100 ignores the DVALID signal, and the stream data is acquired according to the internal clock signal.
Page 85: Figure 3-12: Others Dialog Box
MTX100 acquires pretrigger data when a valid trigger signal occurs and then waits for a trigger. When a valid trigger signal occurs again, the MTX100 acquires posttrigger data and then creates a stream file. Press the TAB button repeatedly to select the list box, then press the arrow buttons to select one of the external record modes.
Page 86: Table 3-13: Asi I/F Menu Command (Record Screen)
Sets the input mode for the parallel interface. You can select Differential or Single End. Termination Sets the internal termination either On or Off. When you have selected Single End from the Receive command, you cannot select Off. 3 26 MTX100 MPEG Recorder & Player User Manual...
Page 87: Table 3-15: Bnc I/F Menu Commands (Record Screen)
Expansion In (EXPANSION IN) or Expansion Out (EXPANSION OUT). Through Out Sets whether the signal supplied to the EXPANSION IN (OUT) connector is output from the EXPANSION OUT (IN) connector. You can select On or Off. 3 27 MTX100 MPEG Recorder & Player User Manual...
Page 88: Table 3-17: Asi/1394 Menu Command (Record Screen)
Sets the connection mode when using the IEEE1394 interface. You can select PtoP Connect (point to point connection) or Probe (data probing). In the PtoP Connect mode, you can connect the MTX100 Option 05 and an IEEE1394 device using a point to point line configuration. In the...
Page 89: Figure 3-13: Ieee1394 Dialog Box (Record Screen)
Some IEEE1394 devices do not recognize the MTX100 Option 05 when you make a connection from the MTX100 Option 05. In this case, when you select this check box, the IEEE1394 device takes the initiative for the connection. You need to select the check box when you connect a BS/CS tuner to the MTX100 Option 05.
Page 90: Table 3-18: Asi/310M Menu Command (Record Screen)
Refer to Using the IEEE1394 Interface (Option 05 only) on page 3-111 for detailed information on how to connect the MTX100 Option 05 and an IEEE1394 device(s), and how to set up the MTX100 Option 05 when using the PtoP Connect and Probe modes.
Page 91: Table 3-19: Toolbar Button Descriptions
Play menu. This button is available when the Play screen is displayed. Target Opens the Target dialog box. Equivalent to the Target command in the Record menu. This button is available when the Record screen is displayed. 3 31 MTX100 MPEG Recorder & Player User Manual...
Page 92 Opens the IEEE1394 dialog box for data probing. Equivalent to the Probe item from the 1394 command in the ASI/1394 menu. This button is available when the Record screen is displayed. 3 32 MTX100 MPEG Recorder & Player User Manual...
Page 93: Hierarchy Display
Overview of the Hierarchy Display The MTX100 uses icons displayed in a hierarchical structure to show the interrelationship of transport stream components (see Figure 3-15). Additional information about each stream component such as PID and Table ID numbers is displayed next to each icon.
Page 94: Table 3-20: Icons Used For Mpeg-2, Arib, Dvb, And Atsc
Hierarchy Display Icons Table 3-20 describes the icons you may encounter in the hierarchy display of the MTX100 for transport streams using the MPEG-2, ARIB, DVB, and ATSC formats. Table 3-21 on page 3-37 describes icons that are specific to transport streams using DVB format.
Page 95 One or more transport packets with a PID value specified by the elementary_PID in the PMT and a stream_type value of 0x0F or 0x81 (ATSC format). A lock symbol appears in the icon when the transport_scrambling_control value is set to 01. 3 35 MTX100 MPEG Recorder & Player User Manual...
Page 96 One or more transport packets in the section data structure at the beginning of the section are not complete. Adaptation Field Error (ADFERR) One or more transport packets with an adaptation_field_control value of 0x00. 3 36 MTX100 MPEG Recorder & Player User Manual...
Page 97: Table 3-21: Icons Specific To Dvb Format
One or more transport packets with a PID value of 0x0014 and a table_id value of 0x72. Time Offset Table (TOT) One or more transport packets with a PID value of 0x0014 and a table_id value of 0x73. 3 37 MTX100 MPEG Recorder & Player User Manual...
Page 98: Table 3-22: Icons Specific To Arib Format
PMT and a table_id value of 0xD1 when a stream type value is 0x05. Index Transmission Table (ITT) One or more transport packets with a PID value specified by the elementary_PID in the PMT and a table_id value of 0xD2. 3 38 MTX100 MPEG Recorder & Player User Manual...
Page 99 One or more transport packets with a PID value of 0x0014 and a table_id value of 0x72. Time Offset Table (TOT) One or more transport packets with a PID value of 0x0014 and a table_id value of 0x73. 3 39 MTX100 MPEG Recorder & Player User Manual...
Page 100: Table 3-23: Icons Specific To Atsc Format
PMT and a table_id value of 0xD0 when a stream_type value is 0x85. System Time Table (STT) One or more transport packets with a PID value of 0x1FFB and a table_id value of 0xCD. 3 40 MTX100 MPEG Recorder & Player User Manual...
Page 101: Icon Text And Dialog Box
Hierarchy Display Icon Text and Dialog Box To the right of each icon, the MTX100 displays text that describes each transport stream component. In addition, for the PCR icon, you can display a dialog box to change the parameters for the component.
Page 102 H PrgNo: Shows the program number associated with the PMT. Program Clock Reference The following text information is displayed for the Program Clock Reference (PCR) Icon (PCR) icon. H PID: Shows the PID value of the PCR. 3 42 MTX100 MPEG Recorder & Player User Manual...
Page 103: Table 3-24: Pcr Inaccuracy Dialog Box Parameters
Sets the pulse width of the waveform used to add jitter. You can set the value from 1 to (period - 1) packet(s) in 1 packet steps. This Pulse Width parameter is available only when the Pattern parameter is set to Pulse. 3 43 MTX100 MPEG Recorder & Player User Manual...
Page 104 The following text information is displayed for the digital storage media command and control (DSM_CC) icon. H PID: Shows the PID value of the data DSM-CC. H StrmTyp: Shows the type of the DSM-CC. 3 44 MTX100 MPEG Recorder & Player User Manual...
Page 105 ERT, ITT, PCAT, SDTT, DCT, DLT, BIT, NBIT, or LDT. H TblID: Shows the table_id value of the SDT, BAT, EIT, RST, ST, DIT, SIT, LIT, ERT, ITT, PCAT, SDTT, DCT, DLT, BIT, NBIT, or LDT. 3 45 MTX100 MPEG Recorder & Player User Manual...
Page 106 The following text information is displayed for the System Time Table (STT) Icon icon. H PID: Shows the PID value of the STT. H TblID: Shows the table_id value of the STT. 3 46 MTX100 MPEG Recorder & Player User Manual...
Page 107: Adding Jitter To Pcrs
Adding Jitter to PCRs The MTX100 provides the capability to add jitter to PCRs (Program Clock References). Adding jitter to PCRs allows you to simulate transmission delay variations and to test the robustness of decoders under various conditions. The jitter function adds jitter to the program_clock_reference_base value and the program_clock_reference_extension value in the adaptation field of transport stream packets.
Page 108 Sine is selected as a jitter-pattern waveform. The PCR values varies by the value of sine waveform defined by the amplitude and period. The PCR period does not change. 3 48 MTX100 MPEG Recorder & Player User Manual...
Page 109: Figure 3-18: Jitter Function With A Sine Jitter Pattern Applied
Number of packets (time) PCR values PCR period PCR values - Original PCR values - PCR values with sine jitter applied Time Figure 3 18: Jitter function with a sine jitter pattern applied 3 49 MTX100 MPEG Recorder & Player User Manual...
Page 110 Adding Jitter to PCRs 3 50 MTX100 MPEG Recorder & Player User Manual...
Page 111: Preset File
Preset File The MTX100 provides the capability to save the user-defined instrument settings as a preset file and load the instrument settings saved as a preset file. This section describes the contents of the instrument settings saved as a preset file and how to save and load a preset file.
Page 112: Loading A Preset File
Perform the following steps to load a preset file: 1. Select Load Preset from File menu, and then press the ENTER button. The Open dialog box appears as shown in Figure 3-20. 3 52 MTX100 MPEG Recorder & Player User Manual...
Page 113: Figure 3-20: Open Dialog Box
) arrow button to select the preset file that you want to load. The selected file name is displayed in the File Name text box. 4. Press the ENTER button. This loads the preset file into the instrument. 3 53 MTX100 MPEG Recorder & Player User Manual...
Page 114 Preset File 3 54 MTX100 MPEG Recorder & Player User Manual...
Page 115: Connecting To A Network
Connecting to a Network The MTX100 has a 100/10 BASE-T port on the rear panel that allows you to upload and download stream files. This section provides instructions for connecting the MTX100 to a single PC or a network and setting the network parameters for the 100/10 BASE-T port.
Page 116: Setting Ethernet Network Parameters
Connecting to a Network Setting Ethernet Network Parameters You can set the network parameters for the MTX100 using the Control Panel of Windows 2000. NOTE. The following procedure assumes that you are familiar with the basics of using the Windows 2000 operating system. If necessary, review the Windows 2000 documentation.
Page 117: Figure 3-23: Local Area Connection Status Dialog Box
Figure 3 23: Local Area Connection Status dialog box 6. Click the Properties button. The Local Area Connection Properties dialog box appears as shown in Figure 3-24. Network component field Figure 3 24: Local Area Connection Properties dialog box 3 57 MTX100 MPEG Recorder & Player User Manual...
Page 118: Figure 3-25: Internet Protocol (Tcp/Ip) Properties Dialog Box
Figure 3 25: Internet Protocol (TCP/IP) Properties dialog box The settings in the dialog box depend on whether a DHCP (Dynamic Host Configuration Protocol) server is in the network connected to the MTX100. When the DHCP Server is in the Network.
Page 119 Connecting to a Network NOTE. Under some network environments, the MTX100 may not be able to obtain the IP address automatically from a DHCP server. In this case, you need to enter the appropriate address value in each submenu item.
Page 120 Connecting to a Network 3 60 MTX100 MPEG Recorder & Player User Manual...
Page 121: Outputting An Isdb-T Transport Stream
Outputting an ISDB T Transport Stream This section describes how to set up the MTX100 and how to connect the MTX100 and a modulator when you output an ISDB-T (Integrated Services Digital Broadcasting for Terrestrial) transport stream. Perform the following procedure to output an ISDB-T transport stream from the MTX100: 1.
Page 122: Figure 3-26: Hierarchy View Of The Isdb-T Transport Stream File
(or click the icon with the right mouse button) to open the ISDB-T Information dialog box, shown in Figure 3-27. NOTE. The ISDB-T transport stream is different from the typical transport stream, so the icon is not represented as a train. 3 62 MTX100 MPEG Recorder & Player User Manual...
Page 123: Figure 3-27: Isdb-T Information Dialog Box
MTX100 and an ISDB-T modulator. 8. Press the PLAY button on the MTX100 to output the transport stream. NOTE. For an ISDB-T transport stream, the MTX100 outputs the stream from the start packet in the OFDM frames to the maximum number of packets that can be looped as 2 N of the number of OFDM frames.
Page 124 12. Use an interface cable to connect the UNIVERSAL IN/OUT connector on the MTX100 Option 02 and the PI input on the ISDB-T modulator. 13. In the Univ I/F menu on the MTX100 Option 02, make the following settings: Level .
Page 125: Syntax
Syntax This section contains information on the Standard Commands for Programmable Instruments (SCPI) and IEEE 488.2 Common Commands you can use to program your MTX100. The information is organized in the following subsec- tions: SCPI Commands and Queries SCPI is a standard created by a consortium that provides guidelines for remote programming of instruments.
Page 126: Table 3-25: Parameter Types Used In Syntax Descriptions
The parameters are enclosed in brackets, such as <pattern>. The parameter type is listed after the parameter and is enclosed in parentheses, for example, (discrete). Some parameter types are defined specifically for the MTX100 command set and some are defined by ANSI/IEEE 488.2-1987 (see Table 3-25).
Page 127 Second command First query Second query The response from this chained message might be 30;50 Response from first query Response from second query Figure 3 30: Example of chaining commands and queries 3 67 MTX100 MPEG Recorder & Player User Manual...
Page 128 H You can use upper case, lower case, or a mixture of both cases for all commands, queries, and parameters. RECORD:TARGET:TRIGGER:POSITION 50 is the same as record::position target:trigger50 RECORD:target:trigger:POSITION 50 NOTE. Literal strings (quoted) are case sensitive. For example: file names. 3 68 MTX100 MPEG Recorder & Player User Manual...
Page 129: Table 3-26: Bnf Symbols And Meanings
ANSI/IEEE Standard 488.2 defines the codes, formats, protocols, and usage of common commands and queries used on the interface between the controller and the instruments. The MTX100 complies with this standard. Command and Query The syntax for an IEEE 488.2 common command is an asterisk (*) followed by a Structure command and, optionally, a space and parameter value.
Page 130 Syntax 3 70 MTX100 MPEG Recorder & Player User Manual...
Page 131: Remote Commands
Remote Commands This section describes the remote command set used in the MTX100. The commands for the MTX100 are divided into the following six groups: H Common commands H DISPLAY commands H MASS MEMORY commands H PLAY commands H RECORD commands...
Page 132: Common Commands
Returns the contents of SESR (Standard Event Status Register) used in the status and events reporting system. *IDN? Returns the ID information of the instrument. The ID information contains manufacturer, model, firmware version, hardware version, and FPGA code version. 3 72 MTX100 MPEG Recorder & Player User Manual...
Page 133 SBR is read as a MSS (Master Status Summary) bit. *TRG Generates a trigger event. *TST? Performs the self test and returns its result. The MTX100 always returns 1. *WAI Wait-to-continue command. This command is not necessary since the MTX100 handles commands sequentially.
Page 134: Display Commands
Use these commands to perform file related operations such as changing and moving a directory, and loading and saving a preset. Command Tree :MMEMory :CATalog? [<directory_path>] :CDIRectory [:DATA] <directory_path> :STATe <directory_path> :LOAD :STATe <preset_name> :MDIRectory <directory_path> :STORe :STATe <preset_name> 3 74 MTX100 MPEG Recorder & Player User Manual...
Page 135 :MMEMory:MDIRectory <directory_path> Creates a subdirectory. The command is invalid if a directory with the specified name already exists. :MMEMory:STORe:STATe <preset_name> Saves the instrument settings with the specified preset name. 3 75 MTX100 MPEG Recorder & Player User Manual...
Page 136: Play Commands
ON|OFF :PACKet 188|204|208|NONTs :PCR :INITial <numeric_value>,<numeric_value> :INACcuracy NONE|SINe|SQUare|TRIangle|PULSe|SAW| RANDom|OFFSet[,,numeric_value>, <numeric_value>[,<numeric_value> [,<numeric_value>[,<numeric_value>]]] :SOURce RAM|DISK :SPIOutput ON|OFF :SSPOsition :POSition <numeric_value>,<numeric_value> :TIME <string>,<string> :STANdard? :STARt :STOP :SYNC :PSYNc TSPAcket|SF|NONTs :INTErval NONE|<numeric_value> :DVALid :WIDth NONE|<numeric_value> 3 76 MTX100 MPEG Recorder & Player User Manual...
Page 137 :PLAY:AUTOplay ON|OFF Sets whether or not the selected stream is automatically output using the last power-down settings when you turn the MTX100 on. You can use 1 or 0 instead of ON or OFF. The default value is OFF. :PLAY:AUTOplay? Return the current auto play mode status.
Page 138 You can set both values from 0 to 2000000000. The default values are 629 for the numerator and 300 for the denomina- tor. :PLAY:CLOCk:RATE:RATIo? Returns the current clock rate for the stream output using a fraction. 3 78 MTX100 MPEG Recorder & Player User Manual...
Page 139 Sets the packet size for the selected stream file. The choices are 188, 204, 208, or NONTs (Non TS). The default value is 188. :PLAY:PACKet? Returns the current packet size setting for the selected stream file. 3 79 MTX100 MPEG Recorder & Player User Manual...
Page 140 Sets whether the signal output from the SPI IN/OUT connector is enabled or not. You can use 1 or 0 instead of ON or OFF. The default value is ON. :PLAY:SPIOutput? Returns the current output status of the SPI IN/OUT connector. 3 80 MTX100 MPEG Recorder & Player User Manual...
Page 141 STMCc, or ISDBT. The MTMCc, STMCc, and ISDBT standards are checked only when the :SYSTem:STANdard command is set to ARIB. :PLAY:STARt Starts outputing the selected stream. There are no arguments. :PLAY:STOP Stops outputing the selected stream. There are no arguments. 3 81 MTX100 MPEG Recorder & Player User Manual...
Page 142 <year>, <month>, <date>, <hour>, <minute>, and <second>. You can set the values from 1900,3,1,0,0,0 to 2038,4,22,23,59,59 for the TDT and TOT and from 1980,1,6,0,0,0 to 2116,2,12,6,28,15 for the STT. The default values are the current date and time. 3 82 MTX100 MPEG Recorder & Player User Manual...
Page 143 Sets whether or not the PCR, continuity_counter, PTS, DTS, TDT, TOT, and STT values are updated. You can use 1 or 0 instead of ON or OFF. The default value is ON. :PLAY:UPDAte? Returns the current update mode status. 3 83 MTX100 MPEG Recorder & Player User Manual...
Page 144: Record Commands
:STOP :CLOCk :RATE? :EXTernal RISE|FALL|OFF :PACKet? :SOURce SPI|ASI|UNIVersal|BNCserial|DHEI| I1394I|S310M|STANdard|OPTion :STANdard? :STARt :STOP :STORe :FILE <file_name> :MODE NEWfile|OVERwrite :TARGet :IGNOredvalid ON|OFF :SIZE <numeric_value> :TIME <string> :TRIGger :POSition <numeric_value> :TYPE RAM|DISK :UNLImit ON|OFF 3 84 MTX100 MPEG Recorder & Player User Manual...
Page 145 Sets the interface used to capture a stream data. The choices are SPI, ASI, UNIVersal, BNCserial, DHEI, I1394I (IEEE1394), S310M (SMPTE310M), STANdard (same as SPI), or OPTion (optional interface currently installed). The default value is SPI. 3 85 MTX100 MPEG Recorder & Player User Manual...
Page 146 ON, the instrument ignores the DVALID signal, and the stream data is acquired according to the internal clock signal. You can use 1 or 0 instead of ON or OFF. The default value is OFF. 3 86 MTX100 MPEG Recorder & Player User Manual...
Page 147 Sets whether to record the input stream to the full free space in the hard disk or RAM. You can use 1 or 0 instead of ON or OFF. The default value is OFF. 3 87 MTX100 MPEG Recorder & Player User Manual...
Page 148: System Commands
:SYSTem:COMMunicate:SOCKet:PORT? Returns the current port number setting. :SYSTem:COMMunicate:SOCKet:RXTERM CR|LF Sets the terminator used when the MTX100 receives commands from a controller. The choices are CR (carriage return) or LF (linefeed). The default value is LF. 3 88 MTX100 MPEG Recorder & Player User Manual...
Page 149 Returns the terminator used when the MTX100 receives commands from a controller. :SYSTem:COMMunicate:SOCKet:TXTERM CR|LF|CRLF|LFCR Sets the terminator used when the MTX100 sends information to a controller. The choices are CR (carriage return) , LF (linefeed), CRLF, or LFCR. The default value is CRLF.
Page 150: Optional Commands
ASI OUT connector when a stream is not output. You can use 1 or 0 instead of ON or OFF. This setting changes the :RECord:ASI:THROughout command setting. The default value is ON. 3 90 MTX100 MPEG Recorder & Player User Manual...
Page 151 Sets the output level of the universal parallel/serial interface. The choices are ECL, TTL, or LVDS. The default value is ECL. :PLAY:UNIVersal:LEVEl? Returns the current output level setting of the universal parallel/ serial interface. 3 91 MTX100 MPEG Recorder & Player User Manual...
Page 152 You can use 1 or 0 instead of ON or OFF. The default value is ON. :RECord:UNIVersal:PSYNc? Returns whether or not the PSYNC signal is used for serial input. 3 92 MTX100 MPEG Recorder & Player User Manual...
Page 153 Sets the output level of the BNC serial interface. The choices are ECL and TTL. This setting changes the :RECord:BNCserial:LEVEl command setting. The default value is ECL. :PLAY:BNCserial:LEVEl? Returns the current output level setting of the BNC serial interface. 3 93 MTX100 MPEG Recorder & Player User Manual...
Page 154 OUT (IN) connector when a stream is not output. You can use 1 or 0 instead of ON or OFF. This setting changes the :RE- Cord:DHEI:THROughout command setting. The default value is :PLAY:DHEI:THROughout? Returns the current throughout mode status when a stream is not output. 3 94 MTX100 MPEG Recorder & Player User Manual...
Page 155 Option 05 IEEE1394/ASI Interface :I1394I:CONNect <numeric_value>[,<numeric_value>] Starts the connection between the MTX100 Option 05 and an IEEE1394 device(s). Specify the node ID of the device(s) in the argument(s). Refer to the :I1394I:NODE:Catalog command. When the :I1394I:MODE command is set to PTOP, specify the destination device.
Page 156 :I1394I:TOTUner ON|OFF Sets whether the connection setting is made by the IEEE1394 device in connecting the MTX100 Option 05 to an IEEE1394 device. You can use 1 or 0 instead of ON or OFF. The default value is OFF. :I1394I:TOTUner?
Page 157 Selects which signal to output from the OUTPUT connector. The choices are ASI or S310M (SMPTE310M). The default value is S310M. :PLAY:S310M:PORT? Returns the current output signal selection. :PLAY:S310M? Returns the current output data rate setting for the SMPTE310M signal. 3 97 MTX100 MPEG Recorder & Player User Manual...
Page 158 Remote Commands :RECord:S310M:PORT ASI|S310M Selects the input signal expected from the INPUT connector. The choices are ASI or S310M (SMPTE310M). The default value is S310M. :RECord:S310M:PORT? Returns the current input signal selection. 3 98 MTX100 MPEG Recorder & Player User Manual...
Page 159: Table 3-27: Default Settings
:PLAY:PCR:INACcuracy NONE :PLAY:PCR:INITial 0, 0 :PLAY:SOURce DISK :PLAY:SPIOutput ON (1) :PLAY:SSPOsition[:POSition] 0, 0 :PLAY:SSPOsition:TIME "00:00:00","00:00:00" :PLAY:SYNC TSPAcket :PLAY:SYNC:DVALid:WIDTh NONE :PLAY:SYNC:PSYNc:INTerval NONE :PLAY:TIMEpacket:DEFine Current data and time :PLAY:TIMEpacket:MODE ORIGinal :PLAY:UPDAte ON (1) 3 99 MTX100 MPEG Recorder & Player User Manual...
Page 160 PACKet :PLAY:ASI:THROughout ON (1) :RECord:ASI:THROughout ON (1) Option 02 Universal Parallel/Serial Interface :PLAY:UNIVersal:CLOCk RISE :PLAY:UNIVersal:FORMat PARallel :PLAY:UNIVersal:LEVEl :PLAY:UNIVersal:PICLock :RECord:UNIVersal:CLOCk RISE :RECord:UNIVersal:FORMat PARallel :RECord:UNIVersal:LEVEl :RECord:UNIVersal:PSYNc ON (1) :RECord:UNIVersal:RECEive SINGleend :RECord:UNIVersal:TERMination ON (1) 3 100 MTX100 MPEG Recorder & Player User Manual...
Page 161 :RECord:DHEI:INPUtport EXIN :RECord:DHEI:THROughout ON (1) Option 05 IEEE1394/ASI Interface :I1394I:MODE PTOP :I1394I:TOTUner OFF (0) :PLAY:ASI:FORMat PACKet :RECord:I1394I:INPUtport I1394I :RECord:I1394I:PARTialts ON (1) Option 06 SMPTE310M/ASI Interface :PLAY:ASI:FORMat PACKet :PLAY:S310M:PORT S310M :RECord:S310M:PORT S310M 3 101 MTX100 MPEG Recorder & Player User Manual...
Page 162 Default Settings 3 102 MTX100 MPEG Recorder & Player User Manual...
Page 163: Error Messages And Codes
-121 invalid character in numeric -123 exponent too large -124 too many digits -128 numeric data not allowed -130 suffix error -131 invalid suffix -134 suffix too long 3 103 MTX100 MPEG Recorder & Player User Manual...
Page 164: Execution Errors
Table 3 29: Execution errors Error code Error message -200 execution error -201 invalid while in local -202 settings lost due to RTL -210 trigger error -211 trigger ignored -212 arm ignored 3 104 MTX100 MPEG Recorder & Player User Manual...
Page 165 -271 macro syntax error -272 macro execution error -273 illegal macro label -274 execution macro parameter error -275 macro definition too long -276 macro recursion error -277 macro redefinition not allowed 3 105 MTX100 MPEG Recorder & Player User Manual...
Page 166: Device Specific Errors
-310 system error -311 memory error -312 PUD memory lost -313 calibration memory lost -314 save/recal memory lost -315 configuration memory lost -330 self test failed -350 queue overflow 3 106 MTX100 MPEG Recorder & Player User Manual...
Page 167: Query Errors
These error codes are returned in response to an unanswered query. Table 3 31: Query errors Error code Error message -400 query error -410 query interrupted -420 query unterminated -430 query deadlocked -440 query unterminated after indefinite period 3 107 MTX100 MPEG Recorder & Player User Manual...
Page 168 Error Messages and Codes 3 108 MTX100 MPEG Recorder & Player User Manual...
Page 169: Network Interface Specifications
To check remote command operation of the MTX100 perform the following procedure: 1. Connect the MTX100 to your PC using an Ethernet cable. Refer to Connect- ing to a Network on page 3-55 for detailed information about how to connect the MTX100 to your PC.
Page 170 6. Select Remote System from the Connect pull-down menu. The Connect dialog box appears. 7. In the Host Name field, enter the IP address of the MTX100. 8. In the Port field, enter the port number set by the Communication dialog box or the :SYSTem:COMMunicate:SOCKet:PORT command (the default value is 49152).
Page 171: Using The Ieee1394 Interface (Option 05 Only)
This section explains how to connect the MTX100 Option 05 and an IEEE1394 device(s), and how to set up the MTX100 Option 05 when using these modes. This section assumes that a key board and mouse are connected to the MTX100 Option 05.
Page 172: Point-To-Point Connection
Using the IEEE1394 Interface (Option 05 Only) H The MTX100 Option 05 does not function as a repeater with the instrument powered off. If you make the following connections when the MTX100 Option 05 is powered off, the connection between a BS/CS tuner and a D-VHS recorder is not established.
Page 173 TS file. 8. In the dialog box, select the transport stream file you want to output. 9. Press the PLAY button on the MTX100 Option 05 to output the transport stream. 10. If you want to record the transport stream, press the Record button on the D-VHS recorder.
Page 174: Data Probing
Refer to About the Partial Transport Stream on page 3-118 for detailed information about the partial transport stream. 11. Press the REC button on the MTX100 Option 05 to start recording the transport stream. Data Probing...
Page 175: Asi/Ieee1394 Conversion
4. Press the Play button on the D-VHS recorder, and then check that a picture is played by the BS/CS tuner. 5. Press the REC button on the MTX100 Option 05 to display the Record screen. 6. Select ASI/1394 from the Source command in the Record menu.
Page 176 Option 05. Refer to the instruction manual attached with the D-VHS recorder for the device connection menu. 4. Press the REC button on the MTX100 Option 05 to display the Record screen. 5. Select ASI from the Input Port command in the ASI/1394 menu.
Page 177 1. Use an IEEE1394 cable to connect the IEEE1394 connector on the BS/CS tuner to the IEEE1394 connector on the MTX100 Option 05. 2. Use a 75 W BNC cable to connect ASI OUT connector on the MTX100 Option 05 to the ASI IN connector on the MPEG analyzer.
Page 178: About The Partial Transport Stream
Time cord (4 bytes) Time cord (4 bytes) Figure 3 36: Partial transport stream In the MTX100 Option 05, a captured transport stream can be recorded as a partial transport stream by setting the Partial TS command in the ASI/1394 menu to On.
Page 179 Appendices...
Page 181: Appendix A: Specifications
Table A-10 on page A-15. H The MTX100 must have a warm-up period of at least 20 minutes. H The MTX100 must be operating at an ambient temperature between +5_ C to +40_ C, unless otherwise noted.
Page 182: Electrical Specifications
V (low level) Frequency 64 MHz to 128 MHz, Locked to reference clock Output clock 64 MHz maximum (serial clock) 25 MHz maximum (parallel clock) Output rate 200 Mbps maximum 1 Kbps minimum MTX100 MPEG Recorder & Player User Manual...
Page 183 Clock pulse width, typical T/2 T/10, T=1/f (f=byte clock frequency) (See Figure A 1.) Data hold time, typical T/2 T/10, T=1/f (f=byte clock frequency, Data are latched on DCLK rising edge) (See Figure A 1.) MTX100 MPEG Recorder & Player User Manual...
Page 184 Supports SPP (Standard Parallel Port), EPP (Enhanced Parallel Port ), and ECP (Extended Capabilities Port) modes. Connector type D sub, 25 pin Pin assignments STROBE AUTOLF INIT SELECT 10 ACK 11 BUSY 12 Paper Empty 13 SELECT MTX100 MPEG Recorder & Player User Manual...
Page 185 28 LVCDP LVCDM 29 LVREQP LVREQM 30 LVIOP LVIOM 31 LVDP8 LVDM8 32 LVDP9 LVDM9 33 LVDP10 LVDM10 34 LVDP11 LVDM11 Keyboard interface Connector type USB (A type, 4 pin) Pin assignments -DATA +DATA MTX100 MPEG Recorder & Player User Manual...
Page 186 Frequency Range 50 Hz to 60 Hz Maximum power 120 VA Maximum current 1.3 A Main fuse data 5 A Time-delayed, 250 V (not operator replaceable) 2 A Time-delayed, 250 V (not operator replaceable) MTX100 MPEG Recorder & Player User Manual...
Page 187: Table A-3: Asi Interface (Option 01)
D sub, 25 pin (the same connector as Serial output) Data rate 1 Kbps to 200 Mbps Pin assignments DCLK 3 to 10 DATA 7 to DATA 0 DVALID PSYNC Shield DCLK 16 to 23 DATA 7 to DATA 0 DVALID PSYNC MTX100 MPEG Recorder & Player User Manual...
Page 188 D sub, 25 pin (the same connector as Parallel output) Data rate 1 Kbps to 40 Mbps Pin Assignments DCLK 3 to 9 Not managed DATA 0 DVALID PSYNC Shield DCLK 16 to 22 Not managed DATA 0 DVALID PSYNC MTX100 MPEG Recorder & Player User Manual...
Page 189 T/2 T/10, T=1/f (f=byte clock frequency, data are latched on DCLK rising or falling edge) (See Figure A 1.) Event output (EVENT OUT) Connector type Output level, typical TTL without termination LO: t 0.4 V HI: u 2.4 V Output impedance, typical 50 W MTX100 MPEG Recorder & Player User Manual...
Page 190: Table A-5: Bnc Serial Interface (Option 03)
T/2 T/10, T=1/f (f=byte clock frequency) (See Figure A 1.) Data hold time, typical T/2 T/10, T=1/f (f=byte clock frequency, Data are latched on DCLK rising or falling edge) (See Figure A 1.) A 10 MTX100 MPEG Recorder & Player User Manual...
Page 191: Table A-6: Dhei Interface (Option 04)
Data delay, typical 0 3 ns from the falling edge of DCLK Input Input level, typical u 0.5 Vp-p (between +pin and -pin) Input resistance, typical 120 W 5% (between +pin and -pin) A 11 MTX100 MPEG Recorder & Player User Manual...
Page 192: Table A-7: Ieee1394/Asi Interface (Option 05)
0.4 ns v A v 5.0 ns (20% to 80%) Frequency range, typical Input Number of input 1 (with active loop through output) Input voltage, typical 800 mV 10% Frequency range, typical A 12 MTX100 MPEG Recorder & Player User Manual...
Page 193 Data bytes (Insert Byte unit) Input Number of input 1 (with active loop through output) Input voltage, typical 800 mV 10% Return loss u 15 dB ( 5 MHz to 270 MHz) A 13 MTX100 MPEG Recorder & Player User Manual...
Page 194: Figure A-1: Timing Diagram Of The Dvb-Spi, Universal Parallel/Serial And Bnc Serial Interfaces
* In the universal parallel/serial and BNC serial interfaces, the polarity of DCLK can be inverted. Input data hold time Figure A 1: Timing diagram of the DVB SPI, universal parallel/serial, and BNC serial interfaces A 14 MTX100 MPEG Recorder & Player User Manual...
Page 195: Mechanical (Physical) Characteristics
(2.28 Grms), 5 Hz to 500 Hz, 10 min, three axes Shock Non operating 294 m/s (30 G), half sine, 11 ms duration. Installation requirements Power dissipation 100 W maximum. Maximum line current is 1.3 A at 50 Hz. A 15 MTX100 MPEG Recorder & Player User Manual...
Page 196: Certifications And Compliances
Australia/New Zealand Declaration Complies with EMC provision of Radio Communications Act per the following standard(s): of Conformity - EMC AS/NZS 2064.1/2 Industrial, Scientific, and Medical Equipment: 1992 A 16 MTX100 MPEG Recorder & Player User Manual...
Page 197 Installation Category II (as defined in IEC 61010 1, Annex J) Pollution Degree 2 (as defined IEC 61010 1) Safety Class 1 (as defined in IEC 61010 1, Annex H)-grounded product A 17 MTX100 MPEG Recorder & Player User Manual...
Page 198 Appendix A: Specifications A 18 MTX100 MPEG Recorder & Player User Manual...
Page 199: Appendix B: Using The Remux Application
NOTE. The ReMux application cannot handle files larger than 2 GB. Starting and Exiting ReMux To start the ReMux application, select Tektronix ³ MPEG ³ ReMux from the Start –Programs menu on the Windows desktop. If you create the shortcut icon of the Remux application on the Windows desktop, you can start the ReMux application by double-clicking it.
Page 200: Elements Of The Remux Window
Figure B-1 shows the ReMux application window. Table B-1 provides a description of the elements in the application window. Title bar Menu bar Toolbar Welcome to ReMux Application dialog box Status bar Figure B 1: ReMux application window MTX100 MPEG Recorder & Player User Manual...
Page 201: Table B-1: Elements Of The Remux Window
The status bar displays the short explanation of the currently selected command and information related to the operation. You can toggle the status bar display on and off using the Status Bar command in the View pull down menu. MTX100 MPEG Recorder & Player User Manual...
Page 202: Table B-2: Toolbar Button Descriptions
Make S TMCC Equivalent to the Mode: Make S TMCC TS command in the ReMux menu. DeMux to M Equivalent to the Mode: DeMux to M TMCC TS command in the TMCC TS ReMux menu. MTX100 MPEG Recorder & Player User Manual...
Page 203: Using The Remux Menus
B-2 ) appears after you select the New command in the File menu. Select one of the ReMux modes, then click the OK button. Table B-4 describes the Select Remux Mode dialog box parameters. Figure B 2: Select Remux Mode dialog box MTX100 MPEG Recorder & Player User Manual...
Page 204: Table B-4: Select Remux Mode Dialog Box Parameters
Welcome dialog box display on or off. Refer to OPTION Dialog Box on page B 7 for detailed information about the dialog box parameters. MTX100 MPEG Recorder & Player User Manual...
Page 205: Figure B-3: Option Dialog Box
Arranges the editing windows so that they overlap one another. Tile Arranges the editing windows so that they do not overlap each other. Arrange Icons When the editing windows are minimize, arranges their title bars. MTX100 MPEG Recorder & Player User Manual...
Page 206: Remux Tutorials
Select Remux Mode dialog box shown in Figure B-2 on page B-5. 2. Select Make S-TMCC TS in the dialog box, and then click the OK button to open the editing window for the Make S-TMCC TS mode shown in Figure B-4. MTX100 MPEG Recorder & Player User Manual...
Page 207: Figure B-4: Editing Window For The Make S-Tmcc Ts Mode
Open dialog box. 4. In the dialog box, select a transport stream file, and then click the Open button to open the Edit TS Information dialog box shown in Figure B-5. MTX100 MPEG Recorder & Player User Manual...
Page 208: Figure B-5: Edit Ts Information Dialog Box
HQ level. H LQ: Specifies the modulation system and the number of slots to be assigned to LQ level. This field is enabled only when the hierarchical control descriptor exists in PMT. B 10 MTX100 MPEG Recorder & Player User Manual...
Page 209: Figure B-6: Window Displaying A Transport Stream Icon
The information displayed at the right side of the transport stream icon has the following meaning: Transport Number of File name Transport stream number super frames stream ID Effective time of the Number of transport stream contract slots B 11 MTX100 MPEG Recorder & Player User Manual...
Page 210: Figure B-7: Edit Tmcc Information Dialog Box (S-Tmcc)
8. Select Execute in the ReMux pull-down menu or click the (Execute) button to open the Save As... dialog box. 9. In the dialog box, specify a file name, and then click the Save button. B 12 MTX100 MPEG Recorder & Player User Manual...
Page 211: S-Tmcc Ts Mode
Open button to open the Edit TS Information dialog box shown in Figure B-5 on page B-10. NOTE. If you select a transport stream file having no S-TMCC structure, an error message appears. B 13 MTX100 MPEG Recorder & Player User Manual...
Page 212: Figure B-9: Transport Stream Is Multiplexed
This multiplexes the newly selected transport stream and the transport stream icon is added in the window (See Figure B-9). Figure B 9: Transport stream is multiplexed 9. If you want to multiplex more transport streams, repeat steps 6 through 8. B 14 MTX100 MPEG Recorder & Player User Manual...
Page 213: Figure B-10: Edit Tmcc Information Dialog Box (M-Tmcc)
H Extended Information: Sets the extended information. When you set the Flag (extension flag) item to 1, the Field item becomes active. 11. After you change the parameters, click the OK button to confirm the changes and close the dialog box. B 15 MTX100 MPEG Recorder & Player User Manual...
Page 214: Figure B-11: Add Tmcc Dialog Box
The following illustration shows the positional relationship of TMCC informa- tion and the transport stream to be inserted to the transport streams already multiplexed. B 16 MTX100 MPEG Recorder & Player User Manual...
Page 215 19. Repeat steps 6 through 8 to multiplex the transport stream file. 20. If you want to further multiplex a transport stream(s) of M-TMCC structure having different TMCC information, repeat steps 14 through 19. B 17 MTX100 MPEG Recorder & Player User Manual...
Page 216: Figure B-12: Editing Window For The Remux To M-Tmcc Ts Mode
2. Select ReMux to M-TMCC in the dialog box, and then click the OK button to open the edit window for the ReMux to M-TMCC TS mode shown in Figure B-12. Figure B 12: Editing window for the ReMux to M TMCC TS mode B 18 MTX100 MPEG Recorder & Player User Manual...
Page 217 M-TMCC structure having different TMCC information. Creating a Transport Stream of M TMCC Structure.. 9. Perform steps 21 and 22 on page B-18 to create a transport stream of M-TMCC structure. B 19 MTX100 MPEG Recorder & Player User Manual...
Page 218: Figure B-13: Editing Window For The Demux M-Tmcc Ts Mode
NOTE. If you select a transport stream file having no M-TMCC structure, an error message appears. " 3. Select Execute in the ReMux pull-down menu or click the (Execute) button to open the DEMUX dialog box shown in Figure B-14. B 20 MTX100 MPEG Recorder & Player User Manual...
Page 219: Figure B-14: Demux Dialog Box
4. After you select the directory and transport stream(s), click the OK button. The transport stream(s) is (are) de-multiplexed and saved to the directory. B 21 MTX100 MPEG Recorder & Player User Manual...
Page 220 Appendix B: Using the ReMux Application B 22 MTX100 MPEG Recorder & Player User Manual...
Page 221 Appendix C: Control Signals for Option 02 For the MTX100 Option 02, the control signals for the hierarchical multiplexing parameters are output from the UNIVERSAL IN/OUT connector when outputting an ISDB-T transport stream. This section describes the pin assignments of the UNIVERSAL IN/OUT connector when the control signals are output and shows the timing relationship of these signals.
Page 222 L: fixed HFLAG2 Frame 1 frame Data[0-7] (byte unit) TS Clock (Duty 50% " 0.5%) Psync Dvalid 1 TSP (204 bytes) Figure C 1: Timing relationship of the signals on the UNIVERSAL IN/OUT connector MTX100 MPEG Recorder & Player User Manual...
Page 223: Appendix D: Connecting Scsi Hard Disk(S)
Perform the following procedure to connect a SCSI hard disk(s) to the MTX100: 1. Power off the MTX100. 2. Connect the SCSI connector (see Figure 2-2 on page 2-4) on the MTX100 rear panel and the connector on the hard disk using a SCSI cable.
Page 224: Figure D-1: Computer Management Window
This displays the volume list at the top right of the window and graphical view at the bottom right of the window (see Figure D-2). The connected hard disk is displayed at the bottom right of the window as Disk 1. MTX100 MPEG Recorder & Player User Manual...
Page 225: Figure D-2: Computer Management Window After Selecting Disk Management
5. Click the Unallocated portion at the bottom right of the window, and then select All Tasks ³ Create Partition from the Action menu. The Create Partition Wizard dialog box appears as shown in Figure D-3. MTX100 MPEG Recorder & Player User Manual...
Page 226: Figure D-3: Create Partition Wizard Dialog Box
After all settings are completed, the dialog box showing completion of the Create Partition Wizard appears as shown in Figure D-4. Figure D 4: Dialog box showing completion of Create Partition Wizard MTX100 MPEG Recorder & Player User Manual...
Page 227: Figure D-5: Computer Management Window After The Format Is Complete
If you create striped volumes, data writing process is distributed among the disks. Writing speed for the stream record can be improved, when you create striped volumes for the hard disks connected to the MTX100. This subsection provides instructions for creating striped volumes for two hard disks.
Page 228: Figure D-6: Computer Management Window After Selecting Disk Management
5. Click Disk 1, then select All Tasks ³ Upgrade to Dynamic Disk from the Action menu. The Upgrade to Dynamic Disk dialog box appears as shown in Figure D-7. MTX100 MPEG Recorder & Player User Manual...
Page 229: Figure D-7: Upgrade To Dynamic Disk Dialog Box
The Create Volume Wizard dialog box appears as shown in Figure D-8. Figure D 8: Create Volume Wizard dialog box 8. Click the Next button. The Select Volume Type dialog box appears as shown in Figure D-9. MTX100 MPEG Recorder & Player User Manual...
Page 230: Figure D-9: Select Volume Type Dialog Box
10. Select Disk 2 in the All available dynamic disks field, and then click the Add button. This adds Disk 2 in the Selected dynamic disks field. 11. Click the Next button. The Assign Drive Letter or Path dialog box appears as shown in Figure D-11. MTX100 MPEG Recorder & Player User Manual...
Page 231: Figure D-11: Assign Drive Letter Or Path Dialog Box
Click the Next button. The Format Volume dialog box appears as shown in Figure D-12. Figure D 12: Format Volume dialog box In the dialog box, you can set the format type. This procedure uses the default settings. MTX100 MPEG Recorder & Player User Manual...
Page 232: Figure D-13: Dialog Box Showing Completion Of The Create Volume Wizard
When you click the Finish button, it starts formatting Disk 1 and Disk 2. After the format is complete, Disk 1 and Disk 2 change to dynamic disks and can be used as striped volumes. The Computer Management window resembles Figure D-14. D 10 MTX100 MPEG Recorder & Player User Manual...
Page 233: Figure D-14: Computer Management Window After The Format Is Complete
Appendix D: Connecting SCSI Hard Disk(s) Figure D 14: Computer Management window after the format is complete D 11 MTX100 MPEG Recorder & Player User Manual...
Page 234 Appendix D: Connecting SCSI Hard Disk(s) D 12 MTX100 MPEG Recorder & Player User Manual...
Page 235: Appendix E: Defragment The Hard Disk Drive
1. Connect the keyboard and mouse provided with the instrument to the USB port on the front panel. 2. Select Exit from File menu in the Play or Record screen to exit the MTX100 application. This appears on the Windows 2000 desktop.
Page 236: Figure E-1: Disk Defragmenter Window
Figure E-2. Figure E 2: Defragmentation Complete dialog box 6. Click the Close button. 7. Click the Close button at the upper right of the screen to close the Disk Defragmenter window. MTX100 MPEG Recorder & Player User Manual...
Page 237: Appendix F: Using The Recovery Discs
1. Insert the Windows 2000 Professional Operating System Recovery Disc into the CD-ROM drive. 2. Turn off, then turn on the instrument. The MTX100 runs from the disc, and a window for installing the operating system is displayed. 3. Follow the installing instructions on the screen.
Page 238: Reinstalling The Mtx100 Application
Reinstalling the MTX100 Application Perform the following procedure to reinstall the MTX100 application software: 1. Insert the MTX100 & RTX100 Application Software Recovery Disc into the CD-ROM drive. 2. Double-click the D: drive icon (Substitute your CD-ROM drive letter if it is different than D).
Page 239: Appendix G: Inspection And Cleaning
2. Remove remaining dirt with a lint-free cloth dampened with a general pur- pose detergent-and-water solution. Do not use abrasive cleaners. 3. Clean the monitor screen with a lint-free cloth dampened with a gentle, general purpose detergent-and-water solution. MTX100 MPEG Recorder & Player User Manual...
Page 240 Appendix G: Inspection and Cleaning MTX100 MPEG Recorder & Player User Manual...
Page 241 Glossary...
Page 243 It has several tables, including: NIT, SDT, BAT, and EIT. (NIT is also required for MPEG-2.) Glossary-1 MTX100 MPEG Recorder & Player User Manual...
Page 244 MPEG-2 Program Specific Information (PSI). ISO (International Standard Organization) Organization responsible for establishing standards at the world-wide level. MPEG-2 A standard developed by MPEG (Moving Picture Experts Group) for the compression of digital video. Glossary-2 MTX100 MPEG Recorder & Player User Manual...
Page 245 PES packet header that indicates the time that a presentation unit is presented in the T-STD. RST (Running Status Table) One of the tables defined by DVB-SI. The RST gives a quick updating mechanism for the status information carried in the EIT. Glossary-3 MTX100 MPEG Recorder & Player User Manual...
Page 246 MPEG-2 standard. T-STD (Transport Stream System Target Decoder) Described by the MPEG-2 standard, the T-STD is a hypothetical reference model of a decoding process used to define the semantics of a TS. Glossary-4 MTX100 MPEG Recorder & Player User Manual...
Page 247 Index...
Page 249 Display, 2-1 Cleaning the instrument exterior, G-1 DISPLAY commands, 3-74 CLK/REF IN connector, 2-5 Display elements, 2-5, 2-6 DIT icon, 3-45 Clock dialog box, 3-7 Clock source indicator, 2-9 DLT icon, 3-45 Index-1 MTX100 MPEG Recorder & Player User Manual...
Page 250 NBIT icon, 3-45 Help menu (ReMux), B-8 NIT icon, 3-42 Hierarchy display, 2-7, 3-33 Non TS icon, 3-41 Hierarchy display icons, 3-34, 3-36, 3-37, 3-38, 3-40 Non–TS Sync dialog box, 3-9 Hierarchy Tree, 3-65 Index-2 MTX100 MPEG Recorder & Player User Manual...
Page 251 SDTT icon, 3-45 Preset file, 3-51 PRINTER connector, 2-5 SELECT button, 2-3 Select File dialog box, 1-9, 2-20, 3-4 Product description, 1-1 Product support, contact information, xii Select Remux Mode dialog box (ReMux), B-5 Index-3 MTX100 MPEG Recorder & Player User Manual...
Page 252 VIDEO icon, 3-44 TDT icon, 3-46 View menu (ReMux), B-8 Technical support, contact information, xii Timer Play/Record dialog box, 3-11 Toolbar, 2-7 Toolbar buttons, 3-31 TOT icon, 3-46 Web site address, Tektronix, xii Index-4 MTX100 MPEG Recorder & Player User Manual...

Tektronix MTX100 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tektronix MTX100

Summary of Contents for Tektronix MTX100

Table of Contents
