- Page 1 Installation & Operation Manual CAMcourse Video Transmitting Magnetic Compass for Overhead Compass CASSENS & PLATH GmbH Manufacturers of Nautical Instruments Am Lunedeich 131 D-27572 Bremerhaven, Germany tel +49 (0)471 483 999 0 fax +49 (0)471 483 999 10 sales@cassens-plath.de www.cassens-plath.de...
-
Page 2: Table Of Contents
CAMcourse Page 2 Index Range of Delivery ....................Technical Data ………………………………………………………………………… Controls ………………………………………………………………………………… Operation ………………..……………………………………………………………... Wiring of Junction Boxes ……………………………………………………………... Junction Box 1 …………………………………………………………………………. Junction Box 2 …………………………………………………………………………. Installation of Camera ………………………………………………………………… Installation of Monitor Unit ……………………………………………………………. Range of Delivery ... -
Page 3: Controls
CAMcourse Page 3 Controls: Main Indicator: Power on/off AV1/AV2 -Key Menu +Key Alterations / Errors Reserved 16/Wo/266D Cassens & Plath GmbH, Am Lunedeich 131, D-27572 Bremerhaven, Germany, tel +49(0)471 483 999 0, fax +49(0)471 483 999 10 www.cassens-plath.de, sales@cassens-plath.de... -
Page 4: Operation
CAMcourse Page 4 Operation: Switch on unit by pressing power button on monitor. Switch Monitor to AV2 input by pressing “AV1/AV2” button on monitor. By pressing menu button on monitor picture menu will be displayed By pressing menu button again, the functions will be selected. Adjustment of function with “+” and “-“. Menu will be left automatically after some seconds when no key is pressed. -
Page 5: Wiring Of Junction Boxes
CAMcourse Page 5 5. Wiring of Junction Boxes: System Overview: Camera Monitor Junction box 2 Junction box 1 Cable, yard supply: 4x0.14mm² min., twisted pairs, Schielded, max. 40m Alterations / Errors Reserved 16/Wo/266D Cassens & Plath GmbH, Am Lunedeich 131, D-27572 Bremerhaven, Germany, tel +49(0)471 483 999 0, fax +49(0)471 483 999 10 www.cassens-plath.de,... - Page 6 CAMcourse Page 6 Main Indicator (Measures Junction Box 1: w125xh80xd60mm) To Monitor: 1) +12V DC 2) GND 3) GND 4) Video To 2nd Monitor (optional): 5) +12V DC 6) GND 7) GND 8) Video To Junction Box 2 (Camera): 9) +12V DC...
-
Page 7: Installation Of Camera
CAMcourse Page 7 6. Installation of Camera: Longitudinal Compass Mounting: First install overhead compass (refer to manual of overhead compass). Then install monitor unit (ref. para. 8) and make connections between junction box 1 and junction box 2 (ref. para. 5). - Page 8 CAMcourse Page 8 Athwardship Compass Mounting: Ahead Alterations / Errors Reserved 16/Wo/266D Cassens & Plath GmbH, Am Lunedeich 131, D-27572 Bremerhaven, Germany, tel +49(0)471 483 999 0, fax +49(0)471 483 999 10 www.cassens-plath.de, sales@cassens-plath.de...
-
Page 9: Installation Of Monitor Unit
CAMcourse Page 9 7. Adjustment of Camera: To adjust camera loosen arrest knob (1). Rotate camera until image is centered. Fix camera in that position with arrest knob. After that focus camera by turning the camera lens (2). 8. Installation of Monitor Unit:...
