- Page 1 C-Band Weather Radar Radio Module GKP-2794 C-Band Weather Radar Radio Module GKP-2794 User’s Manual 2020 July...
- Page 2 PREFACE BEFORE OPERATION ■ GRAPHIC INDICATION Various graphic indications are included in this manual and are shown on the equipment so that it can be operated safely and correctly and prevent any danger to the operator and/or to other persons and any damage to property during operation. Such indications and their meanings are as follows.
- Page 3 C-Band Weather Radar Radio Module GKP-2794 ・PRECAUTIONS WARNING Do not touch TRX Unit. TRX Unit is a moving part, and it may cause injury. For internal inspection and repair work of equipment components, consult with our branch office, branch shop, sales office, or our distributor in your district.
- Page 4 C-Band Weather Radar Radio Module GKP-2794 Table of content PREFACE ......................................1 BEFORE OPERATION ................................1 ・PRECAUTIONS ..................................2 1.General ......................................1 2. Specifications ..................................... 2 2.1 Interface ....................................2 2.2 Performance ..................................3...
- Page 5 C-Band Weather Radar Radio Module GKP-2794 1.General GKP-2794 is sloid-state radio module of weather radar. It is composed with STALO, DSP Unit, TRX Unit Module, and PA Unit. The source oscillation signal is generated in Signal Processor. TRX Unit up-convert the source oscillation to the transmission frequency by mixing it with the local signals generated by STALO, and amplifies it at the PA Unit.
- Page 6 C-Band Weather Radar Radio Module GKP-2794 2. Specifications 2.1 Interface Transmitter STALO /Receiver High pass Power Harmonic DCN-DC522-102IR Amplifier CMN-856 filter filter 10dB ATT J401 RF OUT1 AT-110(40) LOIN SCHPF- CAH-5658 NFH- J402 5600/T51 5659 REF OUT1 LOIN 00-O/O J102...
- Page 7 C-Band Weather Radar Radio Module GKP-2794 2.2 Performance Item Specification Remarks Transmission 5600 MHz, 5800 MHz frequency TRX Unit IF 60MHz frequency Duty 10% or less 8MHz or less Transmit RF output 400 W (Peak) 0℃～+60℃ Operating temperature range 0℃～+60℃...
