Root Level 2nd Level
Login Setup
Pager Setup
Serial Setup
Init Memory
Exit

Run Display

The Run Display indicates the date, system time, temperature (temp), pH,
and ORP. During most of the AquaController II operation this will be the
active display. If no input occurs (button selection) the LCD screen will
automatically return to this display. It can be selected by pressing the Select
(left) button when the arrow cursor is pointing at RUN.
Jan 10 8:10:30
Figure 2: Clock Display
In Figure 2 Normal Clocking is enabled and the first line displays the date
(month day) followed by the tank time (hour:minute:second). The clock
Time can also displayed by setting Advanced Clocking to ON (see section
' Enabling/Disabling Advanced Clocking' on page 19).
The second line indicates the current status of the control modules; the
first character represents the status of the first timer name, the second
character represents the status of the second timer name and so on. If the
character displayed is either an "M" or "m" then that timer is in manual
mode (operation). The "M" indicates that the controlled device is
operating and the "m" indicates the device is idle. Manual Mode Operation
is described in section ' Control and Status' on page 16
The other special characters displayed on this line indicate that the timer is
in Automatic mode, and the controlled device(s) are either "on" or "off".
15
AquaController II Owner' s Manual V1.00b
Copyright 1998/1999 - Neptune Systems
All rights reserved
3rd Level 4th Level
Login: On/Off
Login Name
Login Password
Pager: On/Off
Pager Number
Dial Delay
Repage Delay
Alarm Name:
Type: RS232/RS485
Exit
The character that is displayed for a particular timer is programmed in the
'Setup:Timer Setup:Timer Names' sub-menu. The following table shows
the special characters (the first column represents on and the second off):
Typically Lights
Typically Heater/Chiller
Typically Pumps/Powerheads
Other Controlled Devices
Figure 3: Run Display Special Characters
In the figure below the monitored probes are displayed. with temperature
(°F or °C), pH, and ORP (millivolts) enabled. The UP button is used to
toggle between the Clock Display and the Monitored Probes display.
Temp pH ORP
78.3 8.34 382mV
Figure 4: Monitored Probes Display
.
Pressing the Down button while the Run Display is active will initiate a
Feed Cycle. During the Feed Cycle the display will show a countdown of
the number of seconds remaining. The Run Display is resumed following
the completion of the Feed Cycle. The Select button can be used to end
the Feed Cycle early. See section ' Feed Cycle' on page 16 for more details.
To exit the Run Display and enter the root level menu press the Select
button.

Control and Status

The control and status menu option allows the user to take any timer out
of the automatic mode of operation and force it to either an "on" or "off"
state as well as viewing other operational status.

Feed Cycle

A special case of manual mode of operation is the Feed Cycle. This option
16
