is selected.
This page intentionally left blank.
To test the port type several carriage returns and an AquaController>
prompt should be returned. At this point data can be downloaded from
the AquaController II to the host Macintosh. Please refer to section ' Serial
Port Commands' on page 52 for a detailed description of the serial port
commands.

PC Compatible Installation

To connect the AquaController II to an IBM/PC compatible computer
use our serial cable (P/N SERPC). To install simply place the mini-DIN 8
connector into the AquaController II serial port (see figure 1) and the
DB25 connector into the PC's serial port. For PCs with DB9 connector a
DB25 to DB9 converter is required in addition to the serial cable.
Any of the many serial port communications programs for the PC can be
used. The terminal emulator in Windows (Hyperterminal) or a public
domain program such as Kermit will both work. The communications
program on the PC must be configured to run at 9600 baud, 8 bits/char,
no parity, 1 stop bit and no flow control. Also make sure that the correct
serial port is selected (COM1 or COM2).
To test the port type several carriage returns and an AquaController>
prompt should be returned. At this point data can be downloaded from
the AquaController II to the host PC. Please refer to section ' Serial Port
Commands' on page 52 for a detailed description of the serial port
commands.
