Page 1: Cover Page
GMCDH-12 Dehumidifier Instruction Manual Page | 1 For enquiries or support : visit www.gmcaircon.co.za or contact us on +27 12 661 1173... -
Page 2: Table Of Contents
CONTENTS COVER PAGE …………………………………………………………………1 CONTENTS …………………………………………………………………….2 IMPORTANT NOTES ………………………………………………………3 SAFETY INFORMATION ………………………………………………….4,5,6,7,8 PARTS …………………………………………………………………………..8 INSTALLATION ………………………………………………………………9 OPERATIONS …………………………………………………………………10,11,12,13 WATER DRAINAGE ………………………………………………………..14,15 MAINTENANCE ……………………………………………………………..16,17 SPECFICATIONS/FEATURES ……………………………………………18 TROUBLESHOOTING ………………………………………………………19 DECOMISSIONING …………………………………………………………20 SERVICE AND WARRANTY ……………………………………………...21 Page | 2 For enquiries or support : visit www.gmcaircon.co.za or contact us on +27 12 661 1173... -
Page 3: Important Notes
Thank you again for choosing GMC. If you have any issues at all with your product or any questions then the quickest route for resolution is to please contact us through our website www.gmcaircon.co.za or on +27 12-661-1173. -
Page 4: Safety Information
desired, set the humidity level to a lower setting or select continuous for maximum dehumidification. SAFETY INFORMATION Please read this manual carefully and fully understand before operating your dehumidifier. OPERATIONAL PRECAUTIONS If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. - Page 5 Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacture. The appliance shall be stored in a room without continuously operation sources (for example: open flames, an operating gas appliance or an operating electric heater).
- Page 6 2.SAFETY PRECAUTIONS ON SERVICING Please follow these warnings when to undertake the following when servicing a dehumidifier. 2.1 Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimized. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
- Page 7 period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere. 2.8 Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification.
-
Page 8: Parts
PRODUCT OVERVIEW/PARTS Page | 8 For enquiries or support : visit www.gmcaircon.co.za or contact us on +27 12 661 1173... -
Page 9: Installation
PRODUCT INSTALLATION 4.1 LOCATION 1. Place the unit on a firm, level surface in an area with at least 30cm of free space around it to allow for proper air circulation. 2. Never install the unit where it could be subject to： ... -
Page 10: Operations
OPERATIONS 5.1 CONTROL PANEL After switching on the power, all the indicators and the screen will be on for 1 second and then off. After a buzzer, the power indicator will be on and the machine will be in standby mode. - Page 11 Auto mode - continuously drying mode-sleeping mode cycle, press once to switch the mode from one to another, the corresponding indicator lights up. ● Auto mode: when environmental humidity ≥ set humidity +3%, the fan starts working and compressor starts working after 3 seconds. When environmental humidity ≤...
- Page 12 In the running state, set the time to turn off the machine; in the standby state, set the time to turn on the machine. The fan speed can only be adjusted in the automatic mode. Press this key to switch the high and low fan speed.
- Page 13 Colour Digital Display： Ambient Humidity <45%， The light shows Blue 45≤Ambient Humidity ≤65% ，The light shows Green Ambient Humidity ，The light shows Red ＞65% If the LED display E0、E2、CL、CH、LO、HI, the light will show red. Humidity sensor problem - Change a sensor Environmental humidity is below 20% - The dehumidifier shuts down for self- protection Environmental humidity is above 90% - The dehumidifier shuts down for self-...
-
Page 14: Water Drainage
DRAINAGE EMPTYING THE WATER TANK When the tank is full, the unit will make a buzzing sound, and the “Water Full” light will turn on. Press the POWER button to turn off the unit. Pull on the water tank and simply slide it out of the body of the dehumidifier. ... - Page 15 3. If the water tank is dirty, rinse it with clean water. Avoid using detergents, steel balls, chemical dust removers, diesel oil, benzene, diluents or other solvents. Otherwise, the water tank will be damaged and leak Replace the empty tank back into the unit. Otherwise, the water full indicator may remain red and the machine cannot restart.
-
Page 16: Maintenance
MAINTENANCE Note: before cleaning and maintaining the machine, be sure to turn off the machine and pull the power plug to prevent electric shock. • CLEANING THE AIR FILTER (every two weeks) Dust collects on the filter and restricts the airflow. The restricted airflow reduces the efficiency of the system and if it becomes blocked it can cause damage to the unit. - Page 17 3.Put the filter back. Page | 17 For enquiries or support : visit www.gmcaircon.co.za or contact us on +27 12 661 1173...
-
Page 18: Specfications/Features
SPECIFICATIONS AND FEATURES SPECIFICATIONS: Dehumidifying Capacity (Litre/Day) : 12Liter/Day Room Size : 8-15m2 Water Tank Capacity (Litre) : 2.0Liter Power Supply : 220-240V/50Hz Rated Input W (Cooling) 12L : 200W Rated Current Amps (Cooling) : 1.1A Refrigerant/Charge : R134A Air Circulation : 120m³/h Decibel Rating :≤38dB(A) -
Page 19: Troubleshooting
TROUBLE SHOOTING FUNCTIONING TEMP. 5°C ≤ Ambient Temp. ≤ 35°C When the ambient temp is lower or higher than the functioning temp, the dehumidifier stops. When 5°C ≤ Ambient temp. ≤ 16°C, the compressor automatically defrosts at intervals; during defrosting, the compressor stops and the fan keeps running. BEFORE CALLING FOR SERVICE Before contacting professional service, please review the trouble shooting list that includes common occurrences that are not the result of a defect in workmanship or materials. -
Page 20: Decomissioning
DECOMMISSIONING STORAGE Long-term storage - If you will not be using the unit for an extended period of time (more than a few weeks) it is best to clean the unit and dry it out completely. Please store the unit per the following steps: Press power button to switch off and unplug the unit. -
Page 21: Service And Warranty
SERVICE AND WARRANTY GMC Airconditioning CC was established in 1995 and is one of South Africa's leading cooling and heating companies. We pride ourselves on 100% customer satisfaction and have the highest online rating of all heating and cooling companies in South Africa. We will strive to ensure you are 100% satisfied with your product.
