ANEL ANELVPSM-01ST Instructions For Use And Maintenance Manual

: ANELVPSM-01ST / ANELVPSM-02ST / ANELVPSM-03ST/ANELVPSM-04ST
Types

Applications

The device is used to produce:
1. Vapor
2. Hybrid vapor with the smell of burning wood
3. Conventional smoke
which is applied to bees during the beekeepers' visits to the apiary.
The device is designed to work:
1) As a vaporizer in combination with the Vapor Pad vapor production material ref... AN1040VAP , which produces vapor
with the common method of heating vaping materials.
2) As a hybrid vaporizer in combination with the Cool Smoke hybrid vaping material ref... AN1040CS, an ANEL-patented
formula that produces vapor with the smell of burning wood, making it more effective for bees.
3) As a smoker in combination with conventional smoking materials for their safe ignition with a closed device lid instead
of using a match or lighter.
Both the Vapor Pad and Cool Smoke products contain substances that have been used for decades in various forms in
beekeeping. Both products have successfully passed extensive tests, both in the laboratory and in apiaries, for their effect on
bees or residues in honey.
Both VP and CS products contain extinguishing agents that prevent flame development. Their use, according to the instructions
for use, is extremely safe and does not pose a risk of fire when they are used according to the instructions for use of the device.
Even with the use of conventional smoking materials (e.g., pine needles), due to the fact that the materials are ignited in an
entirely closed environment, it is safer than conventional smokers.

Device description

The device consists of:
1. Bellow
2. Fire chamber
3. Nozzle
4. Heat shield
5Α. Battery adapter, female
5Β. Heating element-resistor power adapter, male
6. Heating element (R1)

Accessories

The battery (-ies) and chargers, which are not included with the device, are chosen when ordering the device and depend on
the use and duration you wish to use the device. The device does not operate without a:
14. Battery
15. Battery charger

Instructions for use and maintenance

Electric heated hybrid vaporizer/smoker

ANEL LTD PANTELAKIS GP
th
6, 45 Odos Street, Industrial Park
Ano Liosia, 13341
Greece
Tel.-Fax +30 2102771180/2102771101/2102483870
info@anel.gr www.anel.gr
7. Fuse box with 15A fuse
8. Fire chamber air inlet
9. Velcro battery strap
10. Aeration grate A
11. Aeration grate B
12. Negative polarity contact pin with smoker body
13. Grabber for Vapor Pads
