- Page 1 AIRFRAME ATX HELMET ™ OPERATOR’S MANUAL...
- Page 2 SUSTAINING SERIOUS PERSONAL INJURY AND/OR DEATH. Any warranties made by Crye Precision LLC with respect to this product are voided if the product is not used and maintained in accordance with the instructions in this manual. For any questions relative to the use or repair of this product, please write Crye Precision LLC or call 1-718-246-3838 during regular business hours.
-
Page 3: Table Of Contents
CONTENTS EQUIPMENT INFORMATION INTRODUCTION COMPONENT DESCRIPTIONS OPERATOR INSTRUCTIONS NVG MOUNTING OPTIONS SHELL SIZING PAD PLACEMENT DONNING FIT ADJUSTMENT CLEANING INSTRUCTIONS PREVENTIVE MAINTENANCE CHECKLIST REASSEMBLY SERIAL NUMBERS... -
Page 4: Introduction
AIRFRAME ™ ATX HELMET INTRODUCTION The AirFrame™ ATX is our law enforcement focused ballistic helmet—designed to offer the same advantages of our original AirFrame™ helmet while meeting IIIA ballistic requirements. The unique overlapping shell design of the AirFrame™ creates an integrated vent that provides passive cooling and can reduce the damaging effects of explosive blast waves. -
Page 5: Component Descriptions
EQUIPMENT INFORMATION COMPONENT DESCRIPTIONS (IMAGES NOT TO SCALE) FRONT SHELL REAR SHELL SHELL SCREW SHORT SHELL SCREW LONG SMALL T-NUT NYLON INSERT HELMET STRAP BOLTS LARGE T-NUT HELMET STRAP OBLONG PADS TRAPEZOIDAL PADS... -
Page 7: Operator Instructions
OPERATOR INSTRUCTIONS... -
Page 8: Nvg Mounting Options
OPERATOR INSTRUCTIONS NVG MOUNTING OPTIONS AirFrame™ ATX helmets can be ordered with pre-drilled mounting holes for standard 3-hole or 4-hole night vision mounts. This must be specified at the time of order. Standard 3-hole configuration for night vision mounts 3-hole night vision mount installed Standard 4-hole configuration for night vision mounts 4-hole night vision mount installed... -
Page 9: Shell Sizing
AIRFRAME ATX HELMET ™ SHELL SIZING Follow the instructions below in order to ensure a correct shell size selection. Select the proper helmet size based on your head circumference. If a measurement falls directly in between two sizes, select the larger size. See the note at bottom of the page for exceptions. Whenever possible, try on a helmet and allow the pads to adjust for five minutes in order to determine which size has the best fit. -
Page 10: Pad Placement
AIRFRAME ™ ATX HELMET PAD PLACEMENT Standard AirFrame™ pad placement is shown below. The number of oblong pads varies with helmet size. helmets require 6 oblong MEDIUM pads, helmets require 7 oblong pads, and helmets require 8 oblong pads. All helmets require two trapezoidal pads. LARGE EXTRA LARGE MEDIUM... -
Page 11: Donning
OPERATOR INSTRUCTIONS DONNING *Straps may need to be retightened after a few minutes of wear as helmet pads can soften. Ensure the chinstrap is unbuckled and all Don the helmet and ensure that the nape Buckle the chin strap. straps are loosened. pad is positioned correctly. -
Page 12: Fit Adjustment
AIRFRAME ™ ATX HELMET FIT ADJUSTMENT HELMET IS TOO TIGHT OR TOO HIGH It is extremely important that the helmet not be sized and fitted to sit too high on the head. If the crown pads do not hit the head (wearer cannot feel pads), then the helmet may be too high. -
Page 13: Cleaning Instructions
OPERATOR INSTRUCTIONS CLEANING INSTRUCTIONS HELMET SHELL Remove helmet pads from helmet shell and clean separately. Helmet shell can be washed with a mild soap and water using a soft brush or cloth. Towel dry the helmet shell and allow to air dry completely indoors or in a shaded area. HELMET PADS Helmet pads should be washed by hand using a mild soap and cold water. -
Page 14: Reassembly
OPERATOR INSTRUCTIONS REASSEMBLY Instructions for reassembly of helmet shell halves. *If assembling AirFrame™ accessories such as Chops, Ears, or Rails, refer to their instructions for greater detail. With the held upside down, install the two Place the onto the and loosely FRONT SHELL LONG REAR SHELL... - Page 15 AIRFRAME ™ ATX HELMET Table 1: Torque Values Once all helmet SHELL SCREWS Helmet Shell Screws 6 in. Lb. (.7 Nm) installed, tighten by hand to torque Strap Bolts 20 in. Lb. (2.3 Nm) values specified in Table 1. Insert through plastic LARGE T-NUTS strap anchors and loosely thread...
-
Page 16: Serial Numbers
Front and rear helmet shells each have a unique serial number located on the inner shell surface. Write your helmet serial numbers below for future reference. Serial numbers should be included when contacting Crye Precision about issues with your helmet or for replacement parts. - Page 17 NOTES NOTES...
