- Page 1 OPERATING & MAINTENANCE MANUAL MODEL : SLL series OPERATION & MAINTENANCE MANUAL SLL- LED : UNSERVICEABLE AREA LIGHT(LED) YOUYANG AIRPORT LIGHTING EQUIPMENT INC. 유 양 산 전 주 식 회 사 페이지 1/21...
-
Page 2: Revision Record
OPERATING & MAINTENANCE MANUAL MODEL : SLL series REVISION RECORD This Revision Record of Manual is written in below Table and we supply new updated Manual with product. This Manual can be revised anytime for better improvement of products and its Revision contents are made by company production process regulation and will give to customers as newly updated Hard copy and Soft copy by CD. - Page 3 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 목 차 1. General 1.1 Knowledge before Operation(use) 1.2 Cautions for Safety 1.3 Quality guaranty 2. Product specification 3. Installation 4. Maintenance & Repair Procedure 5. Transportation & Storage Drawings & Part List 유...
- Page 4 Please transfer this Manual to person in charge of end user and maintenance person and Duty maintenance manager. Please store this Manual where can see easy by person in charge always and use anytime when required. Company: YOUYANG AIRPORT LIGHTING EQUIPMENT INC. KOREA Department: Quality Assurance Team Tel: +82-31-422-0021...
- Page 5 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 1.2 Cautions for Safety Keep this Caution to use products at safely and correctly to prevent before any troubles and dangerous cases are occurred. Use this product function as sufficiently and safely after carefully reading of this Manual.
- Page 6 OPERATING & MAINTENANCE MANUAL MODEL : SLL series WARNING 1. If the product is watered, do not repair it. This will make electrical shock to user. 2. Do not use when a Cable is peeled off and damaged. This will make Electrical shock to user.
- Page 7 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 1.3 QUALITY GUARANTY The product guaranty under this manual applied is 2 years after supply to site. The consumable parts are excluded from guaranty period. The troubles caused by products defects will be free of charge during guaranty period, but, user mistakes and mis-use will be charged.
-
Page 8: Product Specification
OPERATING & MAINTENANCE MANUAL MODEL : SLL series 2. PRODUCT SPECIFICATION 2.1 UAL : UNSERVICEABLE AREA LIGHT Item Specification In compliance with Operating -40 ～ +60℃ FAA: AC 150/5345-46C temperature Storage -55 ～ +55℃ FAA: AC 150/5345-46C temperature Exposure to rain, snow, ice, and standing... - Page 9 OPERATING & MAINTENANCE MANUAL MODEL : SLL series Item Specification In compliance with Frangibility of Breakable under 230kg pressure on 30cm FAA : AC 150/5345-46 coupling from breakable points Wind Velocity 300Not Treatment powder electrostatic painting Surface Treatment Color Aviation yellow...
-
Page 10: Installation
3. INSTALLATION 3.1 General The light is supplied at a condition of assembled and tested by YOUYANG. The Light product is supplied under KS, ICAO and FAA regulation requirement and Light capacity, color and intensity can be decided with user to meet with airfield site condition. - Page 11 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 3.4 LIGHT INSTALLATION Light is installed on earth with anchors and refer to below procedure. 3.4.1 SHALLOW BASE INSTALLATION Light Anchor Bolt(1/2”*100L) Concrete Light Installation Procedure 1) Mark bolts’ right position of light on concrete floor.
-
Page 12: Maintenance And Repair Procedure
OPERATING & MAINTENANCE MANUAL MODEL : SLL series < NOTE > -. To fasten bolts should be used by torque wrench. (Torque Pressure: 30 N.m) 4. MAINTENANCE and REPAIR PROCEDURE 4.1 CHECK PERIOD and CHECK POINTS This Precaution, Maintenance and Repair works are very important for Aircraft safety operation. -
Page 13: Troubleshooting
OPERATING & MAINTENANCE MANUAL MODEL : SLL series ALL PACKING & SEALING ● SNOW & ICE REMOVAL ● 4.2 TROUBLE SHOOTING Please follow up as below action for trouble shooting. *Do change assembly of light at site and then, troubled light must be repaired at maintenance shop to prevent runway shut-down time. - Page 14 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 4.3 REPAIR WORK METHOD 4.3.1 LAMP ASSEMBLY REPLACEMENT 1) TOOL & MATERIAL TOOL MATERIAL 1. LED Assembly 1. Screwdriver 2. Flat head screwdriver 2) WORK METHOD PHOTO WORK METHOD -. Power off the light 1.
- Page 15 OPERATING & MAINTENANCE MANUAL MODEL : SLL series -. Un-fasten 4 bolts fixing lens by screwdriver. -. Un-fasten bolts fixing lamp assembly by screwdriver. -. This photo shows that faulty LED Assembly is separated from light. -. Assemble a new LED Assembly in revert of dis- assembly order.
- Page 16 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 4.3.2 BATTERY REPLACEMENT 1) TOOL AND MATERIAL TOOL MATERIAL 1. Screwdriver 1. BATTERY 2) WORK METHOD PHOTO WORK METHOD -. Un-fasten round headed bolts with screwdriver. 1. Optical Assembly, 2. Power Assembly 3.
- Page 17 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 4.3.3 POWER ASSEMBLY REPLACEMENT 1) TOOL AND MATERIAL TOOL MATERIAL 1. Screwdriver 1. Power assembly 2) WORK METHOD PHOTO WORK METHOD -. Un-fasten round headed bolts with screwdriver. 1. Optical Assembly, 2. Power Assembly 3.
- Page 18 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 4.3.4 COUPLING REPLACEMENT 1) TOOL AND MATERIAL TOOL MATERIAL 1. SPANNER(13mm) 1. COUPLING 2) WROK METHOD PHOTO WORK METHOD -. When replacing broken coupling, un- fasten 2 hexagon bolts with spanner (13mm).
- Page 19 OPERATING & MAINTENANCE MANUAL MODEL : SLL series 5.3 TRANSPORTATION 1) Arrange as low load box to be upper side and heavy load box to be lower side. 2) Marking at outside of big box when several small boxes input in big box what is content in big box.
- Page 20 OPERATING & MAINTENANCE MANUAL MODEL : SLL series Part of name quantity Ordering NO Optical Assembly Globe O-Ring Upper cover O-Ring Upper Cover support Bolt Bolt spring washer Lamp support 1-10 LED PCB 1-11 LED Lens 1-12 Bolt 1-13 spring washer...
- Page 21 OPERATING & MAINTENANCE MANUAL MODEL : SLL series Bolt Power supply assembly Toggle switch cap Power supply bracket Bolt Support PCB box Bolt Spring washer Support Power supply PCB 4-10 Bolt 4-11 Switch PCB 4-12 Switch 4-13 Battery 4-14 Spring washer...
