Z Spindle Mount Assembly:
Required Wood Components
Part # Description
QZ1
Back Frame
QZ2
Side Support
QZ3
Top Brace
QZ4
Top Spindle Mount
QZ5
Inner Spindle Mount
QZ6
Mid Spindle Mount
QZ7
Outer Spindle Mount
Qty
1
2
1
1
1
2
2
24
