  • Page 1 VERTX SERVICE MANUAL...
  • Page 2 The information herein disclosed is the property of iCRco, Inc. Information in this docu- ment is subject to change without notice and does not represent a commitment by iCRco to incorporate changes or improvements in units previously sold or shipped.
  • Page 3 Inc. Address: 2580 West 237th Street Torrance, CA, 90503 Telephone: 310.921.9559 FAX: 310.776.7960 Email: info@icrcompany.com Web: www.icrcompany.com VERTX Information Please Enter the details of the VERTX system here: CR Model: Serial Number: Date Purchased: Interface Type: USB 2.0 c 2007-2009...

  • Page 4: Table Of Contents

    2.2 FCC Notification ....... . . iCRco Warranty ........
  • Page 5 VERTX – Service Manual 7.4 Power Switch Locations ......28 7.5 Installing AC Power Cord ......28 7.6 International Power Cable .
  • Page 6 VERTX – Service Manual 13.8 PMT LF Revision E Adjustment/Test Points ....92 13.9 Changing the Brushes ......94 13.9.1 Scan Slot Brushes .

  • Page 7: Safety Information

    The VERTX unit incorporates a Class 3B 658 nm Red 15mw high-power solid-state laser diode. The VERTX covers protect the service person from direct exposure to laser light. These covers will protect a user/service person only if they are properly installed.

  • Page 8: Electrical Hazards

    The equipment must be serviced by properly trained technicians certified by iCRco Inc. Do not connect the VERTX unit with a damaged or sub-standard power cable. Do not use an extension cord with this device. The VERTX unit should be properly grounded and power connections inspected to ensure safe operation.

  • Page 9: Introduction

    (1) year from the date of original shipment from iCRco subject to the limitations set forth herein. iCRco phosphor plates sold with and for use in iCRco...

  • Page 10: Software Limited Warranty/Support

    If a product proves to be defective in material or workmanship during the warranty period, iCRco will, at its sole option, repair or replace the product with a similar product. Repaired and replacement products may be or include refurbished or remanufactured parts.

  • Page 11: Warranty Product Technical Requirements

    If iCRco determines that the product may be defective, is under warranty and necessitates a return to iCRco for service, an RMA number and instructions for return of the product will be given. iCRco is not responsible for any unauthorized returned product, i.e.

  • Page 12: Additional Warranty Limitations And Extent Of Warranty

    This limitation applies even if iCRco cannot or does not repair or replace any defective product and your exclusive remedy fails of its essential purpose.
  • Page 13 This exclusion of damages applies even if the customer advises iCRco or an iCRco dealer of the possibility of such damages.

  • Page 14: Pre-Installation

    A 13A/220V power cord is sufficient. 3.2 Environmental The VERTX unit should not be placed in a room with a film processor present. This will void the warranty. The humidity and temperature limits are 20 to 95% non-condensing, and 59 F to 95 F (15 C to 35 C), operating, respectively. The room should have good ventilation.

  • Page 15: Physical Requirements

    The room needs to have wall power and should not be used with an extension cord. Please use at least a 1500VA (1500W) UPS between the wall power and the VERTX unit. It is also required to have a network connection for fast technical support. Alternatively, the user must have a phone/fax line that can be connected to the PC as a minimum to comply with iCRco warranty terms.

  • Page 16: Packing List

    4. Packing List WARNING: The UPS CAN NOT ship with the battery connected. Upon unpacking the VERTX and its accessories, the UPS will need to have the battery reconnected. Box 1: Scanning 1. (1) VERTX Scanner with AC cord attached 2.

  • Page 17: Unpacking / Setup Instructions

    7. Plug one end of the AC adapter into the Toughbook and the other end into UPS surge protector outlet (the Toughbook has its own battery backup). 8. Connect one end of the USB cable into the VERTX USB plug and the other end into the Acquisition Toughbook USB port.

  • Page 18: Driver And Software Installation

    VERTX – Service Manual 6. Driver and Software Installation The computer hardware necessary to interface with the VERTX is shipped to the customer with all needed drivers and software installed. If the need arises, the following section describes how to install the software.
  • Page 19 VERTX – Service Manual 4. Click Yes to agree to the Software License Agreement. 5. Make sure both QPC XSCAN32 Software and Software Key Driver boxes are checked, then click Next. 6. Select Scanning Station or Reading Station depend on the use, then click Next to continue.
  • Page 20 VERTX – Service Manual 7. Select the appropriate modality, then click Next to continue. 8. The Destination Folder should be set to C:\Xscan32 then click Next to continue. 9. The Program Folder name should be set to QPC XSCAN32, then click Next.

  • Page 21: Initializing The Vertx Driver

    Note: This process will need to be repeated for each USB port on the laptop. There are 4 USB ports on each laptop. 1. Make sure the VERTX unit is powered on and has the proper USB cable installed. 2. Plug the USB cable into the laptop.

  • Page 22: Installing Ampronix External Monitor Drivers

    VERTX – Service Manual 4. A driver signing warning will appear. Click Continue Anyway. 5. The installation process is finished. Click Finish to finish the installation. 6.4 Installing Ampronix External Monitor Drivers 1. Insert the installation media into the computer.
  • Page 23 VERTX – Service Manual 4. At the license agreement screen, select the radio dialog box next to I accept the terms in the License Agreement, then click Next. 5. Click Install to begin the installation. 6. Click Finish to complete the installation.

  • Page 24: Monitor Configuration

    VERTX – Service Manual 6.5 Monitor Configuration 1. Ensure that the external monitor is powered on and is connected to the laptop via the USB cable. 2. Go to Start Control Panel Display. 3. In the Display Properties, click on the Settings tab.

  • Page 25: Network Configuration

    VERTX – Service Manual 8. To rotate the external monitor to portrait mode, right click on the monitor icon in the system tray, then select Screen Rotation, then click Rotated Right. 9. Select Monitor 1, then uncheck Extend my Windows desktop onto this monitor.
  • Page 26 VERTX – Service Manual 2. Select Internet Protocol (TCP/IP), then click Properties. 3. Select the check box Use the following IP address. 4. If the laptop is an Acquisition station, enter the following: IP Address: 192.168.0.1 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.0.1...
  • Page 27 VERTX – Service Manual 5. Click OK. c 2007-2009 26 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 28: Hardware Installation

    VERTX – Service Manual 7. Hardware Installation 7.1 Hardware Setup Diagram c 2007-2009 27 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 29: Pc Specifications

    7.3 VERTX USB 2.0 Installation The USB 2.0 port is located on the upper, right-hand side of the operator when facing the front of the VERTX unit. Plug a standard USB 2.0 cable into the VERTX USB port and then into the PC.

  • Page 30: International Power Cable

    6. Turn the VERTX unit switch to the on position. 7.6 International Power Cable The VERTX unit utilizes an international IEC grade connector for the power cable. Systems are shipped with a standard NEMA 5-15 hospital grade cable. The cable needs to be changed depending on the male end, which varies from country to country.
  • Page 31 VERTX – Service Manual c 2007-2009 30 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 32 VERTX – Service Manual c 2007-2009 31 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 33 VERTX – Service Manual c 2007-2009 32 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 34 VERTX – Service Manual c 2007-2009 33 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 35 VERTX – Service Manual c 2007-2009 34 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 36 VERTX – Service Manual c 2007-2009 35 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 37 VERTX – Service Manual c 2007-2009 36 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 38: Unpacking / Setup Instructions

    2. Choose the cassette size (10x12” or 14x17”) by moving the metal rod on the right side of the scan slot to the appropriate position. Position the metal rod towards the inside of the VERTX for a 10x12” cassette. Position towards the outside of the VERTX for a 14x17” cassette.
  • Page 39 VERTX – Service Manual 3. Load the cassette into the VERTX. The black, carbon fiber side of the cassette faces towards the front of the VERTX unit. CAUTION: Do not use excessive force when loading the cassette! The cassette will not fit if the orientation is incorrect.
  • Page 40 VERTX – Service Manual 6. If creating a new patient, enter the relevant patient info, or if editing a patient, change the information accordingly (required fields are: Last name, First name, & DOB), then click Save and View. 7. Click on Scan to bring up the Quality Processing Center Scan dialog. (if it is a patient with no images the scan dialog will automatically appear).
  • Page 41 VERTX – Service Manual 9. Select the anatomy by mousing over the skeleton on the left hand side of the Quality Processing Center dialog. 10. To begin scanning, select the cassette size by clicking the correct button (i.e. 14x17 in, 10x12 in).
  • Page 42 VERTX – Service Manual 15. Enhance image by using one of the tools in the Image Processing dialog. 16. Window/Level(W/L) the image using the Window/Level or Smart Box tools. Note: Simultaneously hold down Ctrl + Right mouse button, then adjust the W/L on the touch pad.
  • Page 43 VERTX – Service Manual 17. Accept and Save the image to save the processing and W/L settings by clicking the Save and Accept button in the upper left hand corner of the image. c 2007-2009 42 of 106 Document # VTX-02A Rev C Confidential and Proprietary...
  • Page 44 VERTX – Service Manual 18. Return to the Patient Information window. Select the patient(s) to send to the Viewing station. If you wish to send more than one patient, press the Ctrl key and left mouse click to select multiple patients.

  • Page 45: Quick Start Guides For Service

    In this series of Quick Start Guides, we will demonstrate how to diagnose and fix any issues that might arise in the lifetime of a VERTX unit. The VERTX represents a step function improvement over any other CR unit in the field today, as it is extremely portable, and designed to be completely modular, allowing for fast, in-field service.

  • Page 46: Quick Start: Software Diagnosis

    Note: To use this quick start, you must have a VERTX connected to an acquisition computer using a USB 2.0 cable. Both the PC and the VERTX unit must be powered on, with the software scan interface up and running on the computer. The VERTX must be able to scan an image, and the software must be able to display the image that is scanned.
  • Page 47 VERTX – Service Manual Introduction: As in any service situation, it is important to analyze the issue before disassembling the machine. The scanner interface can provide a high level of feedback regarding any issues that the machine might have. The Focus Tool provides a digital oscilloscope output of the scanner.
  • Page 48 VERTX – Service Manual 3. Enter the password earl in the dialog box. 4. Click on the Focus Tool Button along the bottom edge of the settings window. 5. A new window will come up, indicating the settings for the FOCUS tool. Use the standard settings in the focus tool.
  • Page 49 2,500, you may need to re-adjust the zero point of the scanner. 7. Open the dust cover of the VERTX unit, the Data line should rise and lower slightly according to the position of the dust cover. If the room is illuminated by high frequency fluorescent lights, the line may become sinusoidal (Wavy) and move...

  • Page 50: Quick Start: Cleaning The Mirrors

    Causes include: Bad cable, incorrect or missing driver, bad software interface, incorrect CR model selected in scanner interface, bad settings on the VERTX unit, unsuitable USB 2.0 connection to PC. In addition, it can mean that the laser is not functioning, or laser power is set too low in scanner interface settings.
  • Page 51 VERTX – Service Manual 2. Remove 10 4-40 x ” flat head undercut screws from the scan head cover. 3. Apply glass cleaner on the soft/lint free tissue directly. Do not put cleaner directly on the mirrors. Clean the mirrors in a circular motion and do not apply a lot of force.

  • Page 52: Quick Start: Repairing Or Replacing The Scan Head

    field. It is hoped that the in-field repair of the Scan Head will never be necessary, and it is iCRco policy to provide a service Scan Head kit, rather than send component parts to the field. A clear understanding of the functionality and error conditions that may occur can often provide insight that will lead to another source of the issue, and avoid costly replacement of the scan head itself.
  • Page 53 The scan head has one cover that can be removed without removing the scan head from the VERTX itself. The bottom mirror cover allows access to the two long mirrors for cleaning. White, out of focus, vertical lines parallel to the 17 inch axis on a 14X17 imaging cassette indicate that there is dust or particulates on one of the two long mirrors.
  • Page 54 VERTX – Service Manual (d) Slide the cover up and out of the slots. 2. Remove the wire connectors as shown. Be careful not to damage the phone jack connection wire, and the other wiring harnesses or plugs when removing them from the power distribution board.
  • Page 55 VERTX – Service Manual 4. Cover the cylinder slot with masking tape to prevent dust entry. 5. Remove 6 4-40 x ” pan head screws with washer and lock washer from the Eraser Plate. c 2007-2009 54 of 106 Document # VTX-02A Rev C Confidential and Proprietary...
  • Page 56 6. Remove screws holding up scan head: 2 8-32 x ” truss head screw with lock washer. 7. On a clean, flat surface, gently orient the VERTX unit so that the unit is laying with the front of the VERTX facing down.

  • Page 57: Quick Start: Electrical Bracket Testing & Replacement

    CAUTION: Make sure the VERTX unit is powered off and the power cord is re- moved from the unit before handling electrical components. WARNING: The VERTX unit uses a laser. Do not look into scan slot with the VERTX unit turned on. Avoid looking at the laser, as it can cause eye damage.
  • Page 59 VERTX with the covers off is dangerous to the user and the machine, and can cause harm. 2. Orient the VERTX on a table top, or on the ground. Be sure that the unit is stable, so that it will not fall over during this service.

  • Page 60: Quick Start: Turning Unit On With Covers Removed

    60 for a diagram. 9.5 Quick Start: Turning Unit on with Covers Removed WARNING: Removing covers of VERTX unit while unit is on, or turning unit on while covers are removed can result in permanent damage to the unit. The following safeguards must be in place before turning a unit on.
  • Page 61 VERTX – Service Manual Figure 9.1: Power Distribution Board & Motor Controller Board 2. Click on the Settings Button (enter the password earl), and Turn the PMT Voltages 1 & 2 to 0. Select Save Settings. WARNING: Failure to set the PMT Voltages to zero (0) may cause damage to the PMTs.
  • Page 62 Check that the power switch on the VERTX unit is on, and that the green Ready light on the front of the machine is on and steady. If the Orange scan light is off, the unit is at the home position.
  • Page 63 This means that the unit is not passing data to the PC through the USB 2.0 connection. This can be due to bad cable between computer and VERTX, Bad or cable unplugged inside the VERTX unit, malfunctioning scan head.

  • Page 64: Theory Of Operation

    10.2 System Configuration Optical Beam Path The VERTX unit contains a 664 nm 15 mW laser, Lens optic and four mirrors, a scanning galvanometer, and a light collection system. The round laser spot is focused through a focusing lens to produce a round output beam.
  • Page 65 VERTX – Service Manual system sensitivity across the width of the screen, and then digitized by an A/D converter. Optical Cavity Overview c 2007-2009 64 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.
  • Page 66 VERTX – Service Manual Digital and Electrical Systems Major Components of the VERTX Optical Cavity Galvonometer Board The Galvo Servo board contains a feedback amplifier that results in extremely accurate control of the mirror mounted on the shaft of the scanning galvanometer.
  • Page 67 PMT Board The photomultiplier tube amplifies the photons from the CR plate and converts them into electrical signals. Electrical Overview Power Distribution Board The VERTX Unit Uses Four Power Supplies: Large supply: , +5 V. c 2007-2009 66 of 106 Document # VTX-02A Rev C Confidential and Proprietary...
  • Page 68 The LED Eraser board provides single wavelength light to erase CR plate. Motor Controller Board This section of the VERTX unit controls the stepping motor to drive the plate past the scan head and return it to the “home” position.
  • Page 69 VERTX – Service Manual Note: If an image is canceled during the scan process, the plate will have to be erased again to ensure that the plate is entirely erased. Calibration Gain Adjustment Gain Control is used to compensate for reduction in sensitivity of the PMT detectors due to age.

  • Page 70: Diagnostics

    1. Make sure the VERTX is powered by at least a 1500W/1500VA UPS (uninteruptable power supply). 2. Make sure that the VERTX is connected to the acquisition computer using a USB 2.0 cable. 3. Check that the VERTX unit is powered by a standard NEMA 5-15 hospital grade cable.

  • Page 71: Vertical Lines In Images

    VERTX – Service Manual Symptoms and Their Causes 11.2 Vertical Lines in Images: Vertical lines in the images are most often caused by something in the scan path, that maybe stopping the laser from reaching the plate. If the lines are random within an image, but repeatable in each successive image, there is likely lint/dust blocking the beam near the focal point of the Laser.

  • Page 72: Horizontal Lines & Banding In Images

    VERTX – Service Manual done with the 45 degree roof mirror. 11.3 Horizontal Lines & Banding in Images Lines that appear on an image are caused by several different sources. It can be quite difficult to separate these causes and find the cure. Because light can interact with the scanning laser capture system, it is important to remove the possible causes of lines in a systematic manner to find the solution.

  • Page 73: Lines Caused By Light

    11.3.4 Lines caused by bad power: The VERTX unit is susceptible to surrounding electronic noise. If the power source is not stable, this could cause line artifacts in the image. Please be sure to use a UPS (Uninterruptible Power Supply) of at least 1500VA or 1500W.

  • Page 74: No Galvanometer Movement

    VERTX – Service Manual To determine if the laser is functioning, remove the back cover, cover the scan slot with tape, remove power from the eraser lights, then turn the laser on and visually determine if the laser is functioning. Ensure that the interior of the scanner is not exposed to ambient light, as this will damage the Photo-Multiplier Tubes (PMT).
  • Page 75 VERTX – Service Manual 7. Attempt to make a scan. After clicking the Scan, listen for the motor and watch to see if the slide moves at all. If the motor doesn’t move at all, check the motor controller board.

  • Page 76: Preventative Maintenance

    Close Dust Flap Closing the dust flap on the VERTX, when not in use, is the easiest way to help prevent dust from entering the system. It is good operating practice to keep the dust flap closed when the VERTX is not in use.
  • Page 77 VERTX – Service Manual Cassette Storage All cassettes should be stored in the cleanest, driest conditions possible. Always store the cassettes in a location where they are not likely to be knocked over or damaged. Cassette Cleaning The outside of the cassette can be cleaned with Simple Green .

  • Page 78: Service & Maintenance Procedures

    VERTX – Service Manual 13. Service & Maintenance Procedures Figure 13.1: VERTX system overview. 13.1 Removing Front Cover 1. Remove 5 8-32 x ” flathead screws from the laptop mount. c 2007-2009 77 of 106 Document # VTX-02A Rev C Confidential and Proprietary...
  • Page 79 VERTX – Service Manual 2. Remove 2 8-32 x 1 ” flathead screws to remove the front power cowling. 3. Remove 2 8-32 x ” from the top the lip and 1 8-32 x ” from the bottom of the front cover.
  • Page 80 VERTX – Service Manual 4. Slide the cover up and out of the slots. c 2007-2009 79 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 81: Remove

    VERTX – Service Manual 13.2 Remove Back Cover 1. Remove 10 8-32 x ” truss screws and tooth lock washers from the back panel. There are three on each side, two on the top, two on bottom. 2. After removing the back cover, cover the cylinder slot with masking tape to prevent dust from entering the system.

  • Page 82: Cleaning The Filter

    VERTX – Service Manual 13.3 Cleaning the Filter 1. Remove 2 8-32 x 1 ” flathead screws to remove the front power cowling. 2. There is access to the front fan. The fan cover pops up with minimal force.
  • Page 83 VERTX – Service Manual 2. Remove 10 4-40 x ” flat head undercut screws from the scan head cover. 3. Apply the cleaner on the soft/lint free tissue directly. Do not put cleaner directly on the mirrors. Clean the mirrors in a circular motion and do not apply a lot of force.

  • Page 84: Removing The Scan Head

    VERTX – Service Manual 4. The location of the mirrors is shown in the graphic: 13.5 Removing the scan head 1. Remove the front cover, as covered Section 13.1. c 2007-2009 83 of 106 Document # VTX-02A Rev C Confidential and Proprietary...
  • Page 85 VERTX – Service Manual 2. Unplug the cables that run out of the scan head: Power Distribution board: J8 J9 J5 J3 J2 Phone cable (on the Motor Controller board) USB plug 3. Remove 10 8-32 x ” truss screws and tooth lock washers from the back panel.
  • Page 86 VERTX – Service Manual 4. After removing the back cover, cover the cylinder slot with masking tape to prevent dust from entering the system. 5. Remove eraser plate 6 4-40 x ” pan head screws with washer and lock washer.

  • Page 87: Check Motor / Motor Drive

    7. Now the scan head is free. 8. Pivot the bottom of the scan head out of the back of the VERTX. 9. Slide the scan head towards the bottom of the VERTX unit, then lift out. 13.6 Check motor / motor drive 1.
  • Page 88 VERTX – Service Manual 2. Remove 4 8-32 x ” flat head screws from the top of the top end cap. This also removes the top bumper. 3. Remove the base plate: 4 10-32 x ” truss head screws.
  • Page 89 VERTX – Service Manual 4. Remove 4 final screws attached to shoulder extrusion. 5. Remove the 4 8-32 x ” flat head screws along the length of the shoulder extrusion. 6. Remove the shoulder extrusion. c 2007-2009 88 of 106 Document # VTX-02A Rev C Confidential and Proprietary...

  • Page 90: Checking The Fuses

    VERTX – Service Manual 7. This gives you access to motor, home position sensor, & cassette motor drive system. 13.7 Checking the Fuses WARNING: Make sure the VERTX unit is powered off and unplugged before removing the fuses and/or cover. 13.7.1 Power Fuses 1.

  • Page 91: Power Distribution Board Fuses

    VERTX – Service Manual 4. The fuses are 3A/250V. 13.7.2 Power Distribution Board Fuses WARNING: Make sure the VERTX unit is powered off and unplugged before removing the cover. 1. Remove the front cover, as covered in Section 13.1.
  • Page 92 VERTX – Service Manual 2. There are five fuses located on the power distribution board. Remove & check them: c 2007-2009 91 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 93: Pmt Lf Revision E Adjustment/Test Points

    VERTX – Service Manual 13.8 PMT LF Revision E Adjustment/Test Points 1. LASER POWER (a) TRIMPOT R450 ‘LSP’ (b) TEST POINT REGULATOR TAB U55 2. ZERO OFFSET (a) TRIMPOT R272 ‘OFS’ (b) TEST POINT TP15 ‘VAD’ 3. HIGH VOLTAGE 2 (a) TRIMPOT R318 ‘PMT#2 BAL’...
  • Page 94 VERTX – Service Manual PMT Board Test Points c 2007-2009 93 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 95: Changing The Brushes

    WARNING: Make sure the VERTX unit is powered off and unplugged before removing the cover. 1. Remove 9 8-32 x ” screws from the top end cap assembly of the VERTX 2. Remove 2 8-32 x ” truss head screws and tooth lock washers from the back panel of the VERTX 3.

  • Page 96: Back Cover Brush

    13.9.2 Back Cover Brush WARNING: Make sure the VERTX unit is powered off and unplugged before removing the cover. 1. Remove the back cover, as covered in Section 13.2.

  • Page 97: Jammed Carriage

    2. Orient the VERTX unit so that the unit is laying on its front. 3. Remove 4 8-32 x ” flat head screws from the top end cap. 4. Remove 4 8-32 x ” flat head screws from the base of the VERTX unit. c 2007-2009...
  • Page 98 8. Remove the 2 screws from the lead screw angle. The carriage should slide smoothly. 9. If there is no physical blockage, or if the carriage continues to resist moving smoothly, the VERTX unit is out of alignment. Continue: c 2007-2009...
  • Page 99 VERTX – Service Manual 10. Loosen 2 ” Allen socket head screws on the motor coupling. 11. Gently pull the lead screw up, then out. 12. Note the point where the carriage is sticking. c 2007-2009 98 of 106 Document # VTX-02A Rev C Confidential and Proprietary...
  • Page 100 VERTX – Service Manual 13. Loosen the screws around the area where the carriage is sticking. c 2007-2009 99 of 106 Document # VTX-02A Rev C Confidential and Proprietary August 3, 2009 Property of iCRco, Inc.

  • Page 101: Jammed Cassette During Scan

    VERTX – Service Manual 14. With minimal force, pull the carriage shaft towards the outside of the VERTX unit, and while still applying force, re-tighten the screws. 15. Check to see if the carriage moves smoothly. 16. If the carriage continues to stick, repeat the last four steps until the unit is back in alignment.

  • Page 102: Cleaning The Ip Plate

    The IP plate will then be exposed. The IP plate can be cleaned with iCRco plate cleaner (Agfa CR Phosphor Plate Cleaner), using a soft, lint-free cloth. Spray the plate cleaner on the cloth, then gently wipe the IP...
  • Page 103 VERTX – Service Manual plate clean. If iCRco plate cleaner is not available, use Taskmate all-purpose wipes or Kimtech Kimwipes. CAUTION: At no time should any abrasive cleaners or chemicals be used to clean the cassette or plate, as this will void the warranty.

  • Page 104: Parts List

    VERTX – Service Manual 14. Parts List Lead Screw with Nut 900-0232-01 Shaft Support Rail 900-0242-01 1/2” Shaft 900-0241-01 10mm Guide Rail 100-0867-02 Magnet Switch Harness 040-0013-0001 1 900-0061-01 Fan Filter Assembly 900-0061-03 USB Adapter Mount 100-0952-01 USB Board...
  • Page 105 VERTX – Service Manual Nylon Spacer Mounts 900-0013 Carriage Assembly 500-0191-01 Pillow Block Assembly 500-0196-01 Pillow Block Extrusion 100-0852-03 Magnet 900-0007 4-40 x 7/16” Flat Head Screws 1/2” Open Bearing 900-0240-01 Push Rod Assembly 500-0190-01 Push Rod Holder 100-0851-01...
  • Page 106 VERTX – Service Manual Anti Jitter Bracket 100-0824-03 End Cap, Cylinder 100-0770-01 Machined Scan Head Cylinder, PMT Side 100-0744-01 Machined Scan Head Cylinder, Blank Side 100-0745-01 Machined Heat Sink Extrusion 100-0805-01 Molded PMT Block 100-0775-03 Cambridge Galvo & Controller...
  • Page 107 VERTX – Service Manual Turning Mirror Assembly 500-0158-01 Adjustable Mirror Mount 100-0785-01 Adjustable Mirror, Middle Mount 100-0885-01 Side Spring, Adjustable Mirror 100-0210-01 Top Spring, Adjustable Mirror 100-0211-01 3mm Small Mirror 100-0804-02 Mirror Clamp, H-Bracket 100-0779-01 Rubber Mounts 900-0224-01 Fine Adjustment Screw, 1/4-80...
