instruction card Lokring MTK400
Check that everything is in the case before starting assembly
1.1
delivered as standard
• 1x foam-lined plastic case
• 1x IT-400 Lokring toolhead
• 1x hydraulic pump
• 1x hydraulic hose
• 1x Jaw Retraction Tool (JRT)
• 1x marker pen
• 1x instruction card
1.3
• 1x 4" GO-NOGO gage
01
1.2
• 2x 4" insert blocks
1.4
not deliverd as standard
• 1x hacksaw
• 1x file or deburring tool
• 1x low grade sandpaper (80-120 grade)
• 1x high grade sandpaper (180-400 grade)
questions? +31 343 492 090 • technom.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Technom Lokring MTK400
Summary of Contents for Technom Lokring MTK400
- Page 1 • 1x instruction card not deliverd as standard • 1x 4" GO-NOGO gage • 1x hacksaw • 1x file or deburring tool • 1x low grade sandpaper (80-120 grade) • 1x high grade sandpaper (180-400 grade) questions? +31 343 492 090 • technom.com...
-
Page 2: Installation
(< 5 degrees) Deburr the end of the pipe Use the Go-NoGo gauge to check the squareness of the cut. The bevel angle of the pipe must fall within the 5° tolerance questions? +31 343 492 090 • technom.com... - Page 3 Lokring tool 6. put the Lokring fitting in place 7. install the Lokring fitting Slide the Lokring fitting over the pipe. Place the Lokring tool over the Lokring Check the "install" mark fitting questions? +31 343 492 090 • technom.com...
- Page 4 • the driver is completely up against the body of the fitting; • the Lokring fitting is at the "inspect" mark; • the end of the Lokring fitting's body protrudes from underneath the drive questions? +31 343 492 090 • technom.com...
- Page 5 Lokring tool and the hydraulic pump. Clean the Lokring tool if necessary Press the protective caps firmly in place and stow all the part back in the case questions? +31 343 492 090 • technom.com • TIK00104-2B...
