instruction card Lokring MTK45
1. check that the set is complete before starting instalation
1.1
delivered as standard
• 1x foam-lined plastic case
• 1x IT-45 Lokring toolhead
• 1x hydraulic pump
• 1x hydraulic hose
• 1x marker pen
• 1x instruction card
1.3
• 1x ½" "GO-NOGO" gage for carbon steel fitting
• 1x ¾" "GO-NOGO" gage for carbon steel fitting
• 1x 1" "GO-NOGO" gage for carbon steel fitting
• 1x ½" "GO-NOGO" gage for Stainless Steel fitting
• 1x ¾" "GO-NOGO" gage for Stainless Steel fitting
• 1x 1" "GO-NOGO" gage for Stainless Steel fitting
• gages for other materials available on request
01
1.2
• 1x insert set for ½" fitting
• 1x insert set for ¾" fitting
• 1x insert set for 1" fitting
• 2x insert retainer screws
• inserts for other materials on request
1.4
not delivered as standard
• 1x hacksaw
• 1x file or deburring tool
• 1x low grade sandpaper (80-120 grade)
• 1x high grade sandpaper (180-400 grade)
questions? +31 343 492 090 • technom.com
Advertisement
Table of Contents
Related Manuals for Technom Lokring MTK45
Summary of Contents for Technom Lokring MTK45
- Page 1 • 1x high grade sandpaper (180-400 grade) • 1x ¾“ "GO-NOGO" gage for Stainless Steel fitting • 1x 1” "GO-NOGO" gage for Stainless Steel fitting • gages for other materials available on request questions? +31 343 492 090 • technom.com...
- Page 2 • no lenghtwise scratches or grooves 4. prepare the pipe Check the external diameter of the pipe: Cut the pipe as squarely as possible the "GO-NOGO" gauge must not fall (< 5 degrees) over the pipe questions? +31 343 492 090 • technom.com...
- Page 3 Mark the "inspect" and "install" areas on both sides of the pipe on both sides of the pipe 6. prepare the Lokring tool place the inserts in the Lokring toolhead Tighten the retainer screws manually questions? +31 343 492 090 • technom.com...
- Page 4 7. put the Lokring fitting in place 8. install the Lokring fitting Slide the Lokring fitting over the pipe Place the Lokring tool over the Lokring using the gage. Check the "install" mark fitting questions? +31 343 492 090 • technom.com...
- Page 5 • the driver is completely up against the body of the fitting; • the Lokring fitting is at the "inspect" mark; • the end of the Lokring fitting's body protrudes from underneath the driver questions? +31 343 492 090 • technom.com...
- Page 6 11.2 12.1 12. stow the Lokring tool Remove the insert from the Lokring tool back in the case Clean the Lokring tool and put all the accessories back in the case questions? +31 343 492 090 • technom.com • TIK00101-2B...
