- Page 1 Instruction Manual For Built-In Gas Hobs Millar Int’l Ltd Address: 10 Hornby Street, Manchester M8 8DQ United Kingdom info@millargb.com www.millargb.com...
-
Page 2: Table Of Contents
1. General Precaution ..................... 4 2. Close-up view ......................5 2. How to use your appliance ..................6 3. How to keep your cooktop in shape ................7 4. Practical advice ......................8 5. Troubleshooting ......................9 6. Health and Safety ...................... 10 7. - Page 3 Congratulations on choosing Millar product. We are confident that your new appliance, manufactured with top quality materials, will respond perfectly your requirements. Although you will find this appliance dependable and easy to use, we recommend that you read this manual for best performance and to extend the life of your appliance.
-
Page 4: General Precaution
General Precautions Please read this instruction handbook carefully before installing and using the appliance. This handbook must be kept in easy reach of the appliance for future consultation. If this appliance is sold or transferred to another user, please give this handbook to the new user so that they can learn how to use it correctly and be aware of the various warnings This is a Class 3 appliance designed for home use. -
Page 5: Close-Up View
Close-up View ( GH604 ) ( GH705 (GH905) ( GH906) 1. Auxiliary Burners 2. Semi-rapid burner 3. Rapid burner... -
Page 6: How To Use Your Appliance
4. Triple ring wok burner 5. Igniter for Gas Burners (only on certain models) 6. Safety Device (only on certain models) - Activates if the flame accidentally goes out (spills, drafts, etc.), interrupting the delivery of gas to the burner 7. -
Page 7: How To Keep Your Cooktop In Shape
On models fitted with an igniter (D) : Press the knob and turn in the anti-clockwise direction to the "High" setting. The burner will automatically light. Some models are equipped with an ignition switch incorporated into the control knob. If this is the case, the igniter (D) is present, but not the "E"... -
Page 8: Practical Advice
circumstances. This holds true for chemically aggressive cleaners, like oven sprays and stain removers (Fig.2); Fig.1 Fig.2 When cleaning the grill, it is recommended that you do so while it is still hot, using the handles provided ● to move it from the cooktop to the sink. To remove the pan beneath the grill, it is a good idea to wait until the heating element has cooled (roughly after 15 minutes) Greasing the Gas Valves Over time, the gas valves may stick or become difficult to turn. -
Page 9: Troubleshooting
Use cookware the diameter of which is at least as large as the cooking area so that all of the heat produced by the heating element is used. Make sure that the bottom of tile pot is always dry and clean to ensure good contact between the ●... -
Page 10: Health And Safety
The gas holes are not clogged. ● There are no draughts near tire cooking surface. ● The minimum has been adjusted correctly (see the section entitled, "Minimum Regulation"). ● The cookware is not stable. Check to make sure that: The bottom of the cookware is perfectly flat. ●... - Page 11 - Using the appliance with bare feet; - Pulling on the appliance or the power supply cord to Improper and/or dangerous use; Obstructing the ventilation or heat dissipation slots; Allowing the power supply cord of small appliances to come into contact with the hot parts of the cooktop; Exposure to atmospheric agents (rain, sun);...
-
Page 12: Installation Instructions
Installation Instructions for built-in Hobs IMPORTANT NOTICE: THE OPERATIONS INDICATED BELOW MUST BE CARRIED OUT BY QUALIFIED PERSONNEL ONLY, IN CONFORMITY WITH STATUTORY LEGISLATION. THE MANUFACTURER DECLINES ALL LIABILITY FOR INJURY TO PERSONS OR ANIMALS OR DAMAGE TO PROPERTY DUE TO FAILURE TO COMPLY WITH THESE PRESCRIPTIONS. Important: Unplug the electrical connection before performing any maintenance or regulation upkeep work. - Page 13 Detail A Adjacent Room Room to be Vented Examples of ventilation holes for comburant air. Enlarging the ventilation slot between window and floor Fig.3 Fig.4 c) Intensive and prolonged use of the appliance may necessitate supplemental ventilation, e.g. opening a Window or increasing the power of the air intake system (if present).
- Page 14 d) Should the hob be installed directly under a cupboard or extractor hood, the latter should be at least 650mm from the worktop, as shown in Fig. 5. Should the hob be installed directly under a cupboard, the latter should be at least 700mm from the worktop. e) The dimensions of the room for the furniture must be those indicated in the figures in the last two pages of the cover.
- Page 15 The Cooker should be connected to the gas-supply by a Gas Safe registered installer. During installation of this product it is essential to fit an approved gas tap to isolate the supply from the appliance for the convenience of any subsequent removal or servicing. Connection of the appliance to the gas mains or liquid gas must be carried out according to the prescribed regulation in force, and only after it is ascertained that it is adaptable to the type of gas to be used.
- Page 16 Important: the wires in the mains lead are coloured in accordance with the following code: Green & Yellow - Earth - Neutral Blue - Live Brown As the colours of the wires in the mains lead may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: Connect the Green &...
- Page 17 After you have converted the cooktop to another gas type, make sure you have placed a label containing that information on the appliance. Adjustment of the reduced valve flow TABLE2: How to convert gas source Burners Flame Converting the Converting the cooktop from LPG Cooktop from natural to natural gas...
- Page 18 -Burner ON，large flame -Burner ON，small flame（saxing mode） -Burner OFF Fig.8 See also fig.8 for various operating options (flame size selection); the burner should be set at a large flame during the initial phase of cooking to bring the food to boiling, and then the knob should be turned to the saving flame position to maintain the cooking.
- Page 19 72.6 — 0.40 Butane G31 72.6 — 0.40 Natural — 1548 0.60 Natural 1548 — 199.4 0.60 Natural 1548 — 199.4 0.60 G25.1 Natural 1548 — 0.60 Semi-rapid Natural 1548 — 238.2 0.60 G2.350 1548 130.8 — 0.60 Butane G30 130.8 —...
- Page 20 TABLE 4: Gas source and national comparison table Gas group Supply pressure Country 20mbar AT, BG, CZ, DK, EE, FI, GR, HR, HU, IS, IE, IT, LV, LT, NO, PT, RO, SK, SI, ES, SE, CH, TR, GB 20mbar DE, LU I2E+ G20/G25 at 20/25 mbar BE, FR...
-
Page 21: Notice
NOTICE： A.”prior to installation，ensure that the local distribution condition (nature of the gas pressure) and the adjustment of the appliance are compatible.” B. “The adjustment conditions for this appliance are stated on the label.” C. “This appliance is not connected to combustion products evacuation device. It shall be installed and connected in accordance with current installation regulations. - Page 22 This product complies with EU Directive 2002/96/EC. The crossed-out dustbin symbol reported on the appliance indicates that the appliance must be disposed of separately from other domestic refuse at the end of its useful life. It must therefore be delivered to a waste recycling centre specifically for electric and electronic equipment or returned to the retailer at the moment of purchase of a new equivalent appliance.
