- Page 1 SURGICALL Y CLEAN AIR JADE™2.0 (SCA5100C) OPERATION MANUAL AUTO Read the manual thoroughly before operation and retain for future reference. E520581 Establishment# 100231-CHN-001...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS HOW IT WORKS FEATURES AND SPECIFICATIONS PART NAME INSTALLATION 12-14 OPERATION 15-17 CARE AND MAINTENANCE TROUBLESHOOTING... -
Page 3: Safety Precautions 1
SAFETY PRECAUTIONS 1 WARNING Be sure to follow all precautions below: The internal UV-C+ lamp contains a small amount of mercury which is contained inside the lamp unless Running Environment Cautions broken. Mercury and mercury compounds are known to the State of California to cause birth defects or other reproductive harm. - Page 4 SAFETY PRECAUTIONS 2 This product complies with the maximum allowable concentration of ozone of 0.050 parts per million by volume (ppmv) in a 24-hour period. The Health Canada Guideline 2010 recommends that the maximum exposure limit, based on an averaging time of 8 hours, is 0.020 ppmv or less when tested in a sealed, controlled room approximately 30 m³.
- Page 5 SAFETY PRECAUTIONS 3 WARNING - The internal UV-C lamp contains a small amount of mercury which is contained inside the bulb unless broken. Mercury and mercury compounds are known to the State of California to cause birth defects or other reproductive harm.
- Page 6 SAFETY PRECAUTIONS 4 FCC Warning statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 7: How It Works
HOW IT WORKS When the DC fan motor is running, the indoor air will be drawn through the bottom of the unit. The air will then pass through the HEPA-Rx Filter, the Activated Carbon Filter, the UV-C+ chamber. The purified air is then released through the outlet on the top of the unit. -
Page 8: Features And Specifications
FEATURES AND SPECIFICATIONS The unit has five stages of filtration. A Pre Filter, HEPA-Rx Filter, Activated Carbon Filter, UV-C+ lamp, and two Revitalizing Negative Ion Generators. Touch-free hand gesture operation The JADE™2.0 can be operated completely with the wave of your hand, making it suitable in medical settings to avoid cross contamination. -
Page 9: Part Name
PART NAME 01- Unit body 9- Particle laser sensor 02- Unit housing 10- HEPA-Rx filter 03- Air outlet 11- Activated carbon filter 04- Fan motor 12- UV-C+ lamp holder 05- Fan blade 13- Photo catalytic filter 06- Ion generator 14- Unit lock 07- LED display 15- Bottom plate circuit board... -
Page 10: Installation
INSTALLATION 1. Power supply condition: Use only a 120-volt outlet with grounding wire receptacle. 2. Operational conditions: Temperature: 0℃~40℃; Relative humidity: <75%. 3. The unit should be installed in an indoor area with less personnel activities, and the unit should be set up against the wall. -
Page 11: Operation 1
OPERATION 1 Hand Gesture Operation Plug the power cord in, the inner circle will turn blue, indicating the air purifier is in standby mode. Use your hand to wave over the sensor, this waving motion turns the unit on & off, and can also adjust the fan speed. - Page 12 OPERATION 2 1 POWER Button Button Operation - When the unit is plugged into an electrical outlet, the display panel shows the indoor PM2.5 concentration (μg/m³), temperature and humidity. Press the button, turns the unit On and Off. - Hold the button for 3 seconds to reset the filters indicator light. PM2.5 2 TIMER Button: Press this button to select the time for operation.
- Page 13 OPERATION 3 Remote Control Operation Before using the RF remote control 1. As soon as the unit is plugged in, press and hold the POWER button on the remote control for 5 seconds. TIME 2. The indicator light will start flashing and this means the configuration is succcessful.
-
Page 14: Care And Maintenance 1
CARE AND MAINTENANCE 1 To maintain optimum performance of this air purifier, the HEPA-Rx Filter, the Activated Carbon Filter and the UV-C+ Lamp need to be replaced when the indicator lights are flashing. If the device is operating in an atmosphere with heavy dust, particulate or pet dander, you may need to periodically vacuum the pre filters for optimal performance. - Page 15 CARE AND MAINTENANCE 2 Replacing the HEPA-Rx filter When the 3 circle on the sensor plate flashes, the HEPA-Rx filter needs to be replaced. 1. Stop the operation and unplug the unit. The 3 circle 2. Open the bottom plate, take off the unit lock. flashes, replace 3.
- Page 16 CARE AND MAINTENANCE 3 Replacing the UV-C+ Lamp When the inner circle on the sensor plate flashes, the UV-C+ lamp needs to be replaced (See page16). 1. Stop the operation and unplug the unit. 2. Open the bottom plate and the unit lock, take out all filters. Replace UV-C+ lamp, as shown below: 1.
-
Page 17: Troubleshooting
Activated carbon filter. work properly UV-C+ lamps should only be purchased from Surgically Clean Air or an authorized dealer at Surgically Clean Air. This will ensure that you are receiving UV-C+ lamp that do not generate ozone. Many after-market sellers are selling ozone-generating UV-C+ lamp. - Page 18 SURGICALL Y CLEAN AIR 1A - 6300 Viscount Road Mississauga, Ontario Canada, L4V 1H3 Tel: 1-877-440-7770 www.surgicallycleanair.com info@surgicallycleanair.com...
