Summary of Contents for Elseta IOMOD 16DI

  • Page 1 ELSETA IOMOD 16DI User manual Elseta 4/14/2017 V1.1...
  • Page 2: Copyrights And Trademarks

    IOMOD 16DI COPYRIGHTS AND TRADEMARKS Elseta is UAB “Aedilis” trademark that identifies UAB “Aedilis” manufactured products. All of the products copyright belongs to "Aedilis”. These documents and the product properties can not be changed without company “Aedilis'” knowledge and written consent. User manual may be modified by company “Aedilis'”...
  • Page 3: Safety Requirements

    In areas where equipment failure can result in of nature and human injury. Do not operate the equipment in extreme weather conditions, as they may affect the operation of the equipment. V1.1 | ELSETA | SAFETY REQUIREMENTS...
  • Page 4: Table Of Contents

    Modbus registers ............................6 Testing With “THE VINCI” software ......................6 Technical information ..........................8 Mounting and installation guide ....................... 9 IOMOD 16DI RS485 interface ......................... 9 IOMOD 16DI inputs ..........................10 Configuration over USB ........................... 12 Driver installation ..........................12 IOMOD configuration with PuTTY terminal ..................
  • Page 5: Introduction

    IOMOD 16DI 4/14/2017 1. Introduction IOMOD 16DI is small sized stand-alone Modbus (RTU) or IEC 60870-5-103 digital input controller. IOMOD is used for industrial applications, where digital signaling is used and robust communication is needed. IOMOD is ideal solution for applications such as data acquisition, observation, process monitoring, testing and measurement at remote places.
  • Page 6: Supported Modbus Functions

    02 (0x02) Read Discrete Inputs Reads status of digital inputs (Off or On). IOMOD 16DI has 16 digital inputs from address 0 to address 15; These inputs are active-high or active-low according to supply given to reference input. User can turn on logical input inversion (through USB).
  • Page 7 IOMOD 16DI 4/14/2017 Fig. 3.1 V1.1 | ELSETA | MODBUS working information...
  • Page 8: Technical Information

    Recommended operating conditions Configuration USB – mass storage device Firmware upgrade Electrical specifications 16 X 2kV isolated 12-24VDC; Inputs ESD protected; Selectable inversion. Power Power Supply 9V to 33V Current consumption 100 mA @ 24VDC V1.1 | ELSETA | Technical information...
  • Page 9: Mounting And Installation Guide

    Fig. 5.1. Fig. 5.1 IOMOD 16DI has 1/8 Unit load receiver which allows to have up to 256 units on line (compared to standard 32 units). To reduce reflections, keep the stubs (cable distance from main RS485 bus line) as short as possible when connecting device.
  • Page 10: Iomod 16Di Inputs

    IOMOD 16DI inputs Typical application of IOMOD 16DI inputs is shown on Fig. 5.2. When default configuration for inputs is applied, user will see inputs connected to +12/24V as “high” or state “1” and input status LED will glow.
  • Page 11 User can setup inputs to be driven by 0V (Active low) signal (see Fig. 5.3). With this configuration, user will see inputs connected to 0V as “high” or state “1”, input status LED will glow. Fig. 5.3 V1.1 | ELSETA | IOMOD 16DI inputs...
  • Page 12: Configuration Over Usb

    Press “Update driver software”; following screen should appear: Fig. 6.2 Select “x86” driver for 32bit machine, or x64 for 64bit machine. If not sure, select root folder (folder in which x64 and x86 lays inside). V1.1 | ELSETA | Configuration over USB...
  • Page 13: Iomod Configuration With Putty Terminal

    (exit) before disconnecting device. Default values is set by pressing [6] on main screen, and confirming changes [1]. If accidentally closed the terminal window, user can connect terminal program again, and press any key on keyboard to show up main menu. V1.1 | ELSETA | Configuration over USB...
  • Page 14: Main Menu

    USB port rather than RS-485 line. Communication on RS-485 line is closed and all Modbus commands will be accepted only from USB. To exit this mode user must restart device. V1.1 | ELSETA | Configuration over USB...
  • Page 15: Firmware Upgrade Over Usb

    Device reconnects as mass storage device: Fig. 6.5 User then must delete existing file “firmware.bin”, and simply upload new firmware file by drag and drop. Fig. 6.5 Reconnect device and check firmware version. V1.1 | ELSETA | Configuration over USB...
  • Page 16: Information Of The Equipment Manufacturer

    7. Information of the equipment manufacturer Office address: L. Zamenhofo st. 5 LT-06332 Vilnius Lithuania Tel.: +370 5 2742707, +370 5 2032302 Fax: +370 5 2058584 Email: support@elseta.com In the web: www.aedilis.lt Work hours: I-V 8:00-17:00 V1.1 | ELSETA | Information of the equipment manufacturer...
  • Page 17: Document History

    Major update. Added IEC-103 Description. Minor updates. Added protocol simulator V0.9 2017.01.13 L.S. description. V0.99 2017.03.22 J.S. Added connection diagrams V1.0 2017.03.23 L.S. Minor updates V1.1 2017.04.14 L.S. Added pulse count and ON time count descriptions V1.1 | ELSETA | Document history...
