Taito VEWLIX DIAMOND Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Translated from Japanese to English - www.onlinedoctranslator.com
-For safe and correct use of this product, be sure to read and
· After reading this manual, be sure to keep it in the designated place
Vewlix diamond
fully understand this manual before use.
so that you can use it at any time.
© TAITO CORPORATION 2010 ALL RIGHTS RESERVED.
caution
May be done.
G2003038A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEWLIX DIAMOND and is the answer not in the manual?

Questions and answers

Related Manuals for Taito VEWLIX DIAMOND

Summary of Contents for Taito VEWLIX DIAMOND

  • Page 1 Translated from Japanese to English - www.onlinedoctranslator.com © TAITO CORPORATION 2010 ALL RIGHTS RESERVED. Vewlix diamond caution -For safe and correct use of this product, be sure to read and fully understand this manual before use. · After reading this manual, be sure to keep it in the designated place so that you can use it at any time.

  • Page 2: Introduction

    Introduction This time, Taito Co., Ltd. commercial amusement equipment, Thank you for purchasing "Buurix Diamond". Thank you. teeth character Purpose and handling of the instruction manual This manual describes the handling method and precautions for handling this machine correctly. Please read this manual carefully and keep it in a safe place so that you can refer to it at any time.

  • Page 3: About The Person Used In Our Amusement Equipment

    Important notice for safety This document describes safety issues as follows: Please read it carefully before handling and be sure to follow the precautions. table Record Theory About the person used in our amusement equipment Ming The person and meaning of the operator used in the amusement machine instruction manual are as follows. ●...

  • Page 4: Handling Precautions

    Important notice for safety Handling precautions Pour Treatment Things ● Do not use the product in an abnormal condition such as smoke, strange odor or abnormal noise. On the item It may cause electric shock or fire. Immediately turn off the power switch, unplug the power plug from the outlet, and consult your dealer or our service department.

  • Page 5: About Warning Labels

    Important notice for safety About warning labels Police Announcement caveat stomach hand ● Be careful of the lighting and dirt at the installation site so that the warning label affixed to the machine can be read sufficiently. Also, do not hide it with other game consoles. ●...

  • Page 6: Table Of Contents

    2-3. Installing the game board ........................twenty four 2-3-1 Preparation before installation .............................twenty four 2-3-2 Installation of TAITO Type X ......................twenty five 2-3-3 Installation of TAITO Type X2 ....................27 2-4. Power plug connection ............................ 29 2-5.

  • Page 7: Product Overview

    Product Summary Name of each part each Instruction panel Department Name Name speaker 32 inch wide LCD Monitor Control panel speaker Coin slot Adjuster Serial number sticker Front door Coin return button Coin return port Rejector door Cash box Display card base Handle back door (upper)

  • Page 8: Product Specification List

    Product Summary Product specification list Made External goods Goods Housing specifications Shape Finish Item Outside Specification data Form Hoichi 800 (width) x 800 (depth) x 1,890 (height) mm External dimensions (including instruction panel) View A look When 800 (width) x 525 (depth) x 1,575 (height) mm External dimensions (at the time of delivery) About 105kg Total mass...

  • Page 9: Carry-In Form

    Product Summary ● At the time of delivery Carrying Enter shape Voice (Mm) Carry-in form Dispose of the packaging materials that are no longer needed by a sorting method that suits the area. Packing material Product Summary...

  • Page 10: List Of Accessories

    Audio cable * Used for JVS compatible game boards Stored in a cash box Audio cable * Our products TAITO Type X and TAITO Type X2 Used when assembling NESiCAxLive Four Stored in a cash box Semis screw (W) (trivalent W): M4X18 * This product does not come with a game board or I / O board.

  • Page 11: About Various Service Keys

    Product Summary ■ Various control panel mounting parts Attached Name [Part number] Genus remarks Number of deliveries Goods Stored in a cash box Carriage bolt (chrome): M4X16 View * For fixing EG3 / other companies' control panels (EG3 = our product Eaglet 3) Four Stored in a cash box Button cover (D = 30)

  • Page 12: Chapter 1 Transportation

    Chapter 1 Transportation ■ 1-1. Moving the housing (moving the floor) caution ● Store the power cord inside the housing before moving it. ● Please raise the adjusters (2 places) to the maximum before moving. Open the ejector door, turn off the power switch, and unplug the power plug from the outlet.
  • Page 13 Chapter 1 Transportation Support the housing with both hands and push or pull at walking speed. You can also move it by holding the handle. ● Direction of movement from the front side Slowly with both hands Please press. ● Direction of movement from the back side Slowly with both hands Please press.

  • Page 14: Carrying The Housing

    Chapter 1 Transportation ■ 1-2. Carrying the housing caveat ● When carrying this machine (approx. 105 kg), be sure to carry the back with 5 or more people. Even if 5 or more people carry it, the balance may be lost due to floor conditions, etc., resulting in an accident or injury. Therefore, please work carefully.

  • Page 15: Re-Transportation Method

    Chapter 1 Transportation ■ 1-3. Re-transportation method caveat This machine cannot be transported by forklift. Do not carry it with a forklift as it may cause an unexpected accident such as a fall. caution ● Be sure to attach accessories and instruction manuals before re-transporting. ●...

  • Page 16: How To Load The Vehicle

    Chapter 1 Transportation ■ 1-4. How to load the vehicle caveat This machine cannot be transported by forklift. Do not carry it with a forklift as it may cause an unexpected accident such as a fall. caution ● On the vehicle, lower the adjusters (2 places) of the housing and fix them firmly. ●...

  • Page 17: Chapter 2 Installation

    Chapter 2 Installation ■ 2-1. Installation · Installation conditions caveat ● Be sure to observe the following installation conditions. · Limited to indoors · Ambient temperature is 5 ℃ 〜 35 ℃ · Humidity is 10% to 70% and no condensation ·...
  • Page 18 Chapter 2 Installation Installation space A 500mm space is required on the front for the player's play space and maintenance work space. Please do not use this space as a passage. There is a power cord on the back, so make sure there is 100mm of space so that it does not get caught between the housing and the wall.

  • Page 19: Installation Of Housing

    Chapter 2 Installation ■ 2-2. Installation of housing 2-2-1 Fixing the housing Bring this product to the installation location and lower the adjusters (2 places) using a monkey wrench so that the casters float 3 mm. After fixing, attach the attached hole plugs (2 places) and close the holes in the adjuster.

  • Page 20: Assembling The Control Panel Assembly

    Chapter 2 Installation 2-2-2 Assembling the control panel assembly Loosen the bolts (2 places) on the upper side of the shipping bracket and remove the lower side (2 places). Lift the control panel assembly up and remove it. After removing, remove the bolts (2) remaining on the back of the control panel assembly.[Sems Upset Bolt (W) (Trivalent W): M6x20] 4 places Control panel assembly Loosen...
  • Page 21 Chapter 2 Installation Temporarily fix the bolts (2) removed in step 1 to the positions shown in the figure. Temporarily fix Temporarily fix Use the service key to unlock the key on the back of the control panel assembly and open the control panel toward you.
  • Page 22 Chapter 2 Installation Insert the notch hole of the control panel assembly into the head of the bolt temporarily fixed with, slide it toward you, and hook the control panel assembly with the bolt. Tighten the temporarily fixed bolts, and then fix them with the bolts (2) that were removed. Control panel assembly Bolts (4 places) are tightened Up to control panel assembly,...
  • Page 23 Chapter 2 Installation Control cover (rear) Install with the screws removed in. [Knurled screw with cross hole: M4x7] 2 places * If NESiCAxLive is installed, connect the USB cable to the control panel. Pull it out of the hole in the ASSY and connect it to the RFID R / W unit ASSY. Also, connect the RFID power harness to the FAST I / O AMP PC board.

  • Page 24: Installation Of Instruction Panel

    Chapter 2 Installation 2-2-3 Installation of instruction panel Loosen the screws (2 places), insert the instruction panel from above, and tighten the screws to fix them. Instruction panel loosen loosen twenty three Chapter 2 Installation...

  • Page 25: Installing The Game Board

    Chapter 2 Installation ■ 2-3. Installing the game board 2-3-1 Preparation before installation caution Make sure the power switch is off before installing the game board. Open the ejector door and turn off the power switch. Power switch Rejector door Unlock and remove the front door with the service key.
  • Page 26 2-3-2 Installation of TAITO Type X * Only when the optional Burix JVS board is installed Fix TAITO Type X to the PCB baseboard with the screws (4 places) attached to this machine. [Sems screw (W)-(trivalent W): M4x18] 4 places...
  • Page 27 Chapter 2 Installation Connect the audio cable supplied with this unit to the audio output terminal (green) of TAITO Type X and the AMP PCB ASSY. A arrow view Audio cable green AMP PCB ASSY Connect the power cord and JVS cable connected in step 2 to TAITO Type X. The video cable uses the "DVI →...

  • Page 28: Installation Of Taito Type X

    2-3-3 Installation of TAITO Type X 2 * Only when the optional Burix JVS board is installed Fix TAITO Type X 2 to the PCB baseboard with the screws (4 places) attached to this machine. [Sems screw (W)-(trivalent W): M4x18] 4 places...
  • Page 29 AMP PCB ASSY Connect the power cord and JVS cable connected in step 2 to TAITO Type X 2. For the video cable, use the "DVI → D-SUB" conversion connector included with "TAITO Type X 2" and connect it to the lower DVI. Secure the video cable with a clamp.

  • Page 30: Power Plug Connection

    Chapter 2 Installation ■ 2-4. Power plug connection caution ● Do not let the power cord stick out of the aisle. Players and galleries cause her to stumble. ● Be sure to connect the ground wire to the ground terminal. Remove the power cord that came with the unit from the cash box.

  • Page 31: Communication Cable

    Chapter 2 Installation ■ 2-5. Communication cable caution ● Do not let the communication cable stick out of the passage. Players and galleries cause her to stumble. ● After pulling in the communication cable, close the run cover plate to the width of the cable and fix it.

  • Page 32: Chapter 3 Operation

    Chapter 3 Operation ■ 3-1. Operation check ■ Operation check procedure To check the operation, follow the procedure below and prepare before operation. 1) Turn on the power switch 2) Check the coin meter 3) Check on the game 1) Turn on the power switch With the game board connected to the chassis, open the ejector door and turn on the power switch.
  • Page 33 Chapter 3 Operation 2) Check the coin meter Insert coins and check if the coin meter works properly. The coin meter can be checked from either the cash box side or the rejector door side. (Check the coin meter with the I / O board and the game board connected.) Coin meter coin Inside the rejector door...

  • Page 34: Function Explanation

    Chapter 3 Operation ■ 3-2. Function explanation ■ Central control The central control is inside the ejector door. Monitor adjuster EXIT ENTER － + MENU AUTO SOUND TEST SERVICE VOLUME SWITCH SWITCH OFF OFF [Central Control Department] ① SERVICE SWITCH (service switch) You can increase your credit without counting the coin meter.

  • Page 35: About Service Outlets

    Chapter 3 Operation ■ 3-3. About service outlets The total current capacity of the service outlet of this machine is 4A. Never use a service outlet for equipment with a total maximum current of more than 4A, as it may cause overheating and fire.

  • Page 36: Replacement Of Instruction Sheet

    Chapter 3 Operation ■ 3-4. Replacement of instruction sheet Remove the two screws, remove the instruction panel from the machine, and remove and replace the instruction sheet as shown in the figure below. [Trust screw (chrome) M4x10] 5 places / [Cap nut (chrome) M4] 5 places Instruction plate Instruction sheet ■...

  • Page 37: Replacing The Display Sticker

    Chapter 3 Operation ■ 3-6. Replacing the display sticker caution Be sure to turn off the power switch when attaching the display sticker. Open the ejector door with the service key and turn off the power switch. Use the service key to unlock the key on the back of the control panel assembly and open the control panel toward you.

  • Page 38: Chapter 4 Maintenance

    Chapter 4 Maintenance About maintenance Maintenance and inspection must be performed by a maintenance man and a technician. Contents of Chapter 4 ■ 4-1. Inspection ________________________________________________________________________38 ■ Daily inspection ............................38 ■ Inspection items (7 items in total) ......................38 ■...

  • Page 39: Inspection

    Chapter 4 Maintenance ■ 4-1. Inspection Be sure to perform daily inspections. ■ Daily inspection Please inspect or clean according to the following items before the start of business and at the end of business. Pay particular attention to the areas where the player touches. ■...

  • Page 40: Cleaning

    Chapter 4 Maintenance ■ 4-2. Cleaning 4-2-1 Cleaning the LCD monitor Use a soft cloth such as cotton to wipe off dirt. Gently wipe off any dirt that is difficult to remove with a cloth dampened with a small amount of water. After wiping it off, wipe it again with a dry cloth.

  • Page 41: Optional Items

    ■ VL Control Panel 2J14B This kit is a control panel kit for Burix. [2 joysticks, 14 buttons] ■ VL 1P-2P connector conversion harness Used to change the control panel signal to the 2P side when using the "TAITO TypeX2 Battle Kit". Chapter 4...

  • Page 42: Adjustment Of Switching Regulator (Power Supply Board)

    Chapter 4 Maintenance Only if you have installed the optional "Buurix New JAMMA Power Kit" 4-3-1 Adjustment of switching regulator (power supply board) ● A store maintenance man or a technician should adjust the switching regulator. ● Do not make the output voltage higher than the specified value by adjusting the voltage of the switching regulator. There is a risk of destroying the IC on the game board.

  • Page 43: Installation Of Jamma Video Standard (Jvs) Compatible Game Board

    Chapter 4 Maintenance -With the optional "Buurix New JAMMA Power Supply Kit" Only if you have the "Buurix JVS Board" installed 4-3-2 Installation of JAMMA VIDEO standard (JVS) compatible game board caution ● This unit does not support the monitor horizontal synchronization frequency of 15.75kHz.
  • Page 44 Chapter 4 Maintenance Connect the A, B7, and B8 connectors (3 locations) of the power supply board harness that you removed in step 1 On the power supply board Connect A3 unused Power supply board Harness removed in Game board connection example When connecting the cable to the game board, refer to the instruction manual that came with the game board.

  • Page 45: How To Remove And Replace Parts

    Chapter 4 Maintenance ■ 4-4. How to remove and replace parts caveat ● Only store maintenance personnel and technicians can perform the removal work. In addition, never perform any work other than that described in this manual. If you work with non-genuine parts, it will be considered as unauthorized modification.

  • Page 46: Replacing The Control Panel

    Chapter 4 Maintenance 4-4-1 Control panel replacement Be sure to turn off the power switch before performing the replacement work. ■ Installation of the control panel for our product "Eaglet 3" Open the ejector door and turn off the power switch. Unlock the control panel with the service key and open it toward you.
  • Page 47 Chapter 4 Maintenance Connect the J / K connector, close the control panel, and lock with the service key. J, K connector ■ Installation of NAOMI CABINET, NET CITY, VERSUS CITY compatible control panel Unlock the control panel with the service key and open it toward you. Disconnect the control panel connectors (2 places).
  • Page 48 Chapter 4 Maintenance Fix the control panel to be replaced with the control plate cover L / R (SG), carriage bolts (6 places) and locknuts (10 places) attached to this unit. [Carriage bolt (chrome): M4X16] 6 places [Locknut (trivalent): M4] 10 places Lock nut (10 places) Control cover plate L...

  • Page 49: Replacing The Joystick And Push Button

    Chapter 4 Maintenance 4-4-2 Replacing the joystick and push button Be sure to turn off the power switch before performing the replacement work. ■ Replacement of each button Open the ejector door and turn off the power switch. Unlock the control panel with the service key and open it toward you. From the back of the control panel, remove the terminal of the push button to be replaced, and pull it up while pressing the claw on the side of the push button.
  • Page 50 Chapter 4 Maintenance ■ Replacing the joystick Open the ejector door and turn off the power switch. Unlock the control panel with the service key and open it toward you. From the back of the control panel, disconnect the joystick connector (one place). Remove the E-ring on the shaft and remove each part.

  • Page 51: Replacing The Rejector

    Chapter 4 Maintenance 4-4-3 Replacing the rejector Be sure to turn off the power switch before performing the replacement work. Open the ejector door and turn off the power switch. Remove the wing bolt and remove the ejector plate. Remove the ejector while tilting it sideways. [Butterfly bolt (trivalent): M4x10] 1 place lever Butterfly bolt...

  • Page 52: Replacement Of Various Boards

    Chapter 4 Maintenance 4-4-4 Replacement of various boards Be sure to turn off the power switch before performing the replacement work. ■ Replacing the AMP PCB ASSY Open the ejector door, turn off the power switch, and unplug the power plug from the outlet.
  • Page 53 Chapter 4 Maintenance -Only when the optional "Buurix JVS Board" is installed- Please. Be sure to turn off the power switch before performing replacement work. ■ Replacing the JVS PCB ASSY Open the ejector door and turn off the power switch. Open the control panel toward you with the service key.

  • Page 54: Fuse Replacement

    Chapter 4 Maintenance 4-4-5 Fuse replacement Be sure to turn off the power switch and unplug the power plug from the outlet before performing the replacement work. Open the ejector door, turn off the power switch, and unplug the power plug from the outlet.

  • Page 55: Adjusting The Lcd Monitor

    Chapter 4 Maintenance ■ 4-5. Adjusting the LCD monitor 4-5-1 About adjustment of LCD monitor The screen adjustment of the LCD monitor is performed by the adjuster inside the ejector door. EXIT ENTER － AUTO + MENU EXIT --- Used when exiting an item. ENTER--- Decide the item on the menu screen.
  • Page 56 Chapter 4 Maintenance 4-5-2 How to adjust the LCD monitor Press the MENU button to display the menu screen. PICTURE W / B SCREEN FUNCTION * * * * × * * * * * Hz Use the + and-buttons to select, increase or decrease the value, and the ENTER button to confirm. Press the EXIT button to exit the item.

  • Page 57: Rotation Of Lcd Monitor

    Chapter 4 Maintenance ■ 4-6. Rotation of LCD monitor ● Before rotating the LCD monitor, be sure to turn off the power switch and unplug the power plug from the concentric. ● When rotating the LCD monitor, use two or more people. Failure to do this will cause the LCD monitor to fall, resulting in damage or injury.
  • Page 58 Chapter 4 Maintenance Disconnect the connectors (2 places) connected inside the control panel assembly and the LAN cable or JVS cable. Remove the harness from the clamp and store it in the hole. * The optional Burix JVS board or NESiCAxLive is installed. If not, this is not necessary.
  • Page 59 Chapter 4 Maintenance Remove the screws (2 places) and remove the back door (upper). Disconnect the monitor cable, electron microscope harness, and connector that are connected internally, and pull it out. [Trust screw (chrome) : M4x8] 2 places D-SUB Video cable back door (upper) connector...
  • Page 60 Chapter 4 Maintenance Remove the screws (3 places) and remove the front stopper (upper). [Truss screw (trivalent black): M4x8] 3 places A arrow view Front stopper (upper) Loosen the upper speaker fixing screws (2 places each), slide the speaker up, and tighten the fixing screws.
  • Page 61 Chapter 4 Maintenance Be sure to have two or more people remove the LCD monitor. Remove the bolts (4 places) on the back, and be sure to remove the LCD monitor with two or more people.[Sems upset screw (W) trivalent: M6x10] 4 places LCD Monitor Remove the screws (3 places) and remove the front stopper (lower).
  • Page 62 Chapter 4 Maintenance Remove the wing bolts (4 places each) and remove the space plate base. [Butterfly bolt (trivalent): M4x16] 4 places each Space plate base Attach the space plate base with wing bolts as shown. After installation, loosen the screws on the upper speaker, lower the speaker, and fully tighten it.
  • Page 63 Chapter 4 Maintenance Be sure to have two or more people install the LCD monitor. Two people have an LCD monitor,Connector connection facing downPlace it towards. Fix with bolts (4 places). [Sems upset screw (W) trivalent: M6x10] 4 places [Connector connection facing down] Attach the front stopper (lower) with the screws (3 places).
  • Page 64 Chapter 4 Maintenance Install the side cover ASSY L / R and the top side cover L / R. Side cover assembly upper side [Sems screw (W) trivalent: M4x6] 2 places Side cover assembly lower side [Bind low head screw (stainless steel): M4x6] 2 places Top side cover [Truss screw (chrome): M4x35] 2 places Top side cover R Top side cover L...
  • Page 65 Chapter 4 Maintenance Connect the accessory AC joint harness to the power harness connected to the LCD monitor. AC joint harness Power harness Connect the monitor cable, connector, and AC joint harness connected to the power supply harness to the LCD monitor. Please install the back door (upper). [Trust screw (chrome) : M4x8] 2 places Backdoor (upper)

  • Page 66: Fixing The Control Panel Assembly

    Chapter 4 Maintenance ■ 4-7. Fixing the control panel assembly When re-transporting the machine, be sure to fix the control panel assembly with the shipping bracket. Failure to do this may cause an unexpected accident. Open the ejector door and turn off the power switch. Open the control panel toward you with the service key.
  • Page 67 Chapter 4 Maintenance Remove the bolts (2 places) on the front side that fix the control panel assembly, and loosen the bolts (2 places) on the back side. Slide the control panel assembly to the back and remove it. Remove the bolts (2 places) left on the machine. Control panel assembly Control panel ASS After removing, remove...

  • Page 68: Simple Troubles And Countermeasures

    Chapter 4 Maintenance ■ 4-8. Simple troubles and countermeasures trouble Possible causes handle can not turn on ● Connect the power plug to this unit or an outlet ● The power plug can be removed from the outlet or this unit. Isn't it missing? Please plug it in.

  • Page 69: Chapter 5 Disposal

    Chapter 5 Disposal ■ 5-1. Disposal When disposing of the housing or parts, the owner of this machine is responsible for handling it as industrial waste. Packing material At the time of shipment, this machine is protected by packing materials. Please dispose of the packing materials according to the sorting method according to the area.

  • Page 70: Main Component Material Table

    Chapter 5 Disposal ■ 5-2. Main component material list part number Part name Material Classification C0300022L ACTUATOR- (ROHS) SUS304-WPB metal D2001972B wood SPEAKER BOX wood D2002015A NOISE FILTER BASE wood D2002016A PCB BASE BOARD wood D2002047A UPPER SPEAKER BOX E1000928A CANCEL ROD SGD290 metal...
  • Page 71 Chapter 5 Disposal part number Part name Material Classification E3101522B MIDDLE SIDE COVER-L SUS430 metal E3101523B MIDDLE SIDE COVER-R SUS430 metal E3101525B TOP SIDE COVER-L SUS430 metal E3101526B TOP SIDE COVER-R SUS430 metal E3102110A CONTROL PLATE-(1J7B) SUS430 metal E3102129A FRONT STOPPER-(LOWER) metal Electrogalvanized steel sheet E3102130A...
  • Page 72 Chapter 5 Disposal part number Part name Material Classification F0100095A DK CRAMP resin F9001053A BUTTON COVER D = 30 resin PULL F9006283B resin F9006726A CANCEL CUP resin F9006850A RES LOCK ABS / steel Resin / metal F9007032A SPEAKER COVER resin F9007069B DUCT SPONGE EPDM...
  • Page 73 Chapter 5 Disposal part number Part name Material Classification G1501787A CONNECTOR STICKER SHEET-(TYPE RA) High-quality paper paper G1504540A SIDE STICKER SHEET resin PMMA G4500463A TITLE PANEL resin G5500517A CONTROL STICKER-(1J7B) resin G6000373A INDICATION STICKER SHEET resin H1005095A LCD GLASS- (WITH AG COATING) Glass Tempered glass H1005097A...

  • Page 74: Parts Catalog

    Parts catalog Parts catalog...
  • Page 75 E3103009A CABINET-(WHITE)-(WITH PARTS) F9001053A BUTTON COVER D = 30 DP-1187- F9006283B BLACK PULL E9100166A LEG-L- (SUS) E9100167A LEG-R- (SUS) E5060768A ADJUSTER ADP- (BLACK) M12X86 E3018834A WASHER ZB / 8.5X20X1.6T SEMUTH UPSET BOLT-W- (Trivalent) M8X20 M9008280A SIDE COVER LOWER ASSY-L PAN HD SEMUTH SCREW-W- (Trivalent) M4X8 M9008281A SIDE COVER LOWER ASSY-R Four 11 11...
  • Page 76 C0550633P AC OUTLET SOCKET-(PBF) M1743 E3018361A OUTLET BRACKET-2P L9005613B OUTLET HARNESS THERMAL SHIRINKAGE TUBE-(D = 25) 0.06 RSFR-H VW-1- (25DIA) DK CRAMP-(17.5X19) TS-0607 F9007074A (DKN-5G) OUTLET CAP Four Four Five...
  • Page 77 E3019430B SWITCH BOX C0551019P AC INLET- (ROHS) C0550144P FUSE NC-179-F4.8 Four HOLDER-(ROHS) C1600167P FUSE- (8A 250V)- MF526 (ROHS) (6.3X31.75)-(PBF) MGC 8A / 250V L9006019A AC HARNESS UL CRAMPA TC-17 (UL-13G) FLANGE NUT- (Trivalent) M4 C1700054L COUNTER- (DC 5V)-(ROHS) NX-06R054-MY8K F9007600A COUNTER COVER PAN HD SEMUTH SCREW-S- (Trivalent) M3X6 PETTEPLE JFW-5 (SD10) 11 11...
  • Page 78 Five F9007075A SHEET-A Four F9007069B DUCT SPONGE 230X10X5 E5000689A Four 120MM FAN GUARD-(ROHS) C1200619P DC BRUSHLESS FAN-(12V)-(ROHS) A12038L12B TRUSS HD SCREW- <CHROME> M4X50 SELF LOCKING NUT-U- (Trivalent) M4 F9008174B PLASTIC SPACER ZB / 4X8X27 PAN HD SEMUTH SCREW-W- (Trivalent) M3X8 Four PAN HD SEMUTH SCREW-W- (Trivalent) M4X8 TRUSS HD SCREW- (CHROME) M4X8...
  • Page 79 Four L9006463A CABINET DC HARNESS 2 L9005616D SPEAKER HARNESS PETTEPLE JFW-5 (SD10) DK CRAMP TS-0607 (DKN-5G) UL CRAMP ATC-17 (UL-13G) UL CRAMP ATC-22 (UL-18G) TERMINAL & CONNECTOR-S- (12A) CE-2 CONVEX- (milky white) CV-100K (SKB-100) Five A arrow view Five Four B arrow view Five Four...
  • Page 80 Five NOISE FILTER-(250V 10A) C1800081P -(ROHS) SUP-ET10-ER-0 Four Four BIND HD SELF TAP- (Trivalent) 3.5X12-1 D2002015A NOISE FILTER BASE PLAIN WASHER- (Trivalent) 4.5X18X1.6T PAN HD M4X25 SEMUTH SCREW-W- (Trivalent) M1300079A SWITCHING REGULATOR -(ROHS) VS75B-12 (HFP) F9006850A RES LOCK LCM3-20 Four M3X8 Four PAN HD SEMUTH SCREW-W- (Trivalent)
  • Page 81 L9005604B CABINET AC HARNESS L9005617A USB CABLE-(AB)-(1.0M) Five DK CRAMP TS-0607 (DKN-5G) UL CRAMP ATC-17 (UL-13) TL CRAMP TL-18A Four Five Five Five...
