- Page 1 Ceramic Tea Mill Take pieces apart ・ Assembling User Guide Tea Recipe...
- Page 2 Ceramic Green tea mill Ceramic blade without losing natural flavor Granularity adjusting style you can choose your own granularity Cautions You can grind the tea leave for about 20g. (※ Body : Capacity of tea leave 52g /Body Capacity of ground tea leave 20g ) It is exclusively used only for green tea. ( dried tea leave ) Other tea leave are not operative. All other food materials except dried green tea may cause the troubles. ...
- Page 3 Names and features of each part Ceramic blade Upper cover Handle Middle cover Used stone mortar typed ceramic b lade which can keep the Shaft natural flavor of tea. Granularity Body adjustment screw Adjustment ring fine coarse You can choose the Ceramic blade thickness / fineness upper blade of whatever you are lower blade grinding. Fixed pin With stopper Granularity screw ※In case of setting,four Stopper points of the projection are expected to be put down side.
- Page 4 Please read before use How to grind ・ The mill is set to fine grinding when shipped. green tea ・ Make adjustments to the powder roughness after trying the initial setting. shaft ・ Turning the handle with no tea leaves added Upper cover can damage the ceramic blade. with handle Hexagonal hole at back side Hexagonal hole Middle cover at back side Container Take out the upper Close the middle cover. By setting hexagonal hole of handle to and middle cover,put hexagonal part at the tea leave by spoon Set the smaller cover tip of s haft, u pper cover or likewise.
- Page 5 About use The function of granularity adjustment Coarse Fine Coarse Fine If y ou turn to the left, If y ou turn to the left, you can grind coarse you can grind the granularity. fine granularity. If you turn the granularity adjustment screw to the end of the right s ide, then return one round, you can grind the middle class granularity of coffee beans. How to use granularity adjustment screw Handle Granularity adjustment Screw Set the upper cover with handle, then by controlling it, turn the granularity adjustment screw If you turn the granularity adjustment screw too right, the turning will become heavy, because of rubbing by ceramic blades each other. T his may cause the troubles. If you can hear the sound by rubbing of blades, try ...
- Page 6 To take body and ceramicblade apart tapping tapping screw tip screw tip Tap the tip of the screw Take the granularity Remove the fixing pin part lightly on a cloth adjustment screw out. and the lower blade and remove the while pressing the ( c ounter clockwise ) upper blade. fixing pin. How to take care After grounding the tea, take out the powder by tooth brush or likewise. If you do not use it for a long time, wash it well. Tea powder may stick to up and down side ceramic blades. Take out the adjustment screw. Caution 1. Ensure that there are no objects around when disassembling the mill. 2. When removing the ceramic blade, do not drop it or hit it against hard objects, as this can cause cracking or chipping.
- Page 7 About care The way of assembling of body and ceramic blade Dimples at Dimples at Side with lines Side with lines three places three places Overhang part Overhang part at three places at three places Set the adjustment ring Try to adjust 3 hollows in Set the lower blade the b ody to t he projection with the side with to the body.
