- Page 1 5611300 V1.0 This appliance complies with the requirements of SANS 1539 UGH02S 2 Burner Gas Hob - Instruction Manual - IN ORDER TO OBTAIN THE GREATEST SATISFACTION FROM YOUR COOKWARE APPLIANCE, IT IS RECOMMENDED YOU READ THE INSTRUCTIONS CAREFULLY.
-
Page 2: Table Of Contents
INTRODUCTION Dear Customer Thank you for choosing this quality Univa Built-in Gas Hob. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. This gas hob can only use L.P.G. (Liquid Petroleum Gas) Please take the time to read this User Manual before using your appliance and keep this book for future reference. -
Page 3: Safety Warnings
Where a flexible hose is used the hose must comply with the requirements of SANS 1156-2. The hose must be clamped with a suitable hose clamp at both ends. Note: The hose and regulator are not supplied with the Univa Hobs. Contact your local gas dealer to purchase the correct hose and regulator. -
Page 4: Unpacking
cylinder first and then the appliance valve. Check that all the connections are securely tightened. Re-check with soapy water. If a gas leak persists, return the product to your gas dealer for inspection and/or repair. In the event of a gas leak or gas smell in the house or room in which the appliance is installed, close the isolation or emergency, shut off valve and open all the doors and windows to ventilate the area. -
Page 5: Specifications
Information on appropriate disposal centers for used devices can be provided by your local authority. SPECIFICATIONS Model UGH02S Gas Type: LP Gas Operating pressure 2,8kPa Total gas consumption: 424 g/H Semi Rapid Burner 2.0KW... - Page 6 IMPORTANT INFORMATION FOR THE INSTALLER This appliance may only be installed by a LP Gas installer registered by SAQCC Gas, the government appointed registering body for all gas installers. The appliance must be installed in accordance with the requirements of SANS 10087-1 and any fire department regulations and/or local bylaws applicable to the area.
-
Page 7: Operating Instructions
• The gas connection may be either: 1. A mechanical compression gas fitting using a rigid pipe. Note that water fittings are not allowed. 2. A mechanical fitting using a flared fitting using a rigid pipe 3. A hose connection using a flexible hose clamped to the LPG Inlet Pipe (See Fig 2) 4. - Page 8 Burner cap Burner body Flame failure Device Burner Ignition Injector Figure.3 Figure.4 Fig. 3 and Fig 4. Burner assembly shows a burner located over the jet assembly and next to the insulated igniter post and thermos-coupler sensor (Flame Failure device). When removing and replacing the burner, ensure not to damage igniters or thermo- couplers.
- Page 9 This will ensure that you will achieve the best cooking efficiency. If the flame appears to extend up the sides of the pot, either place the pot on a larger burner, or reduce the flame height by adjusting the required burner control knob. The rapid burner is ideal for simmering.
-
Page 10: Cleaning & Maintenance
Should the flame not appear to be burning correctly, close off gas supply at the cylinder and seek advice from the dealer or service center Ventilation in the room is vital for the effective performance and safety of Univa gas appliances... -
Page 11: Guarantee
Univa authorized service Agent or consultant. 3. The liability of Univa shall be limited to the repair or replacement by a Univa authorized service dealer in its sole discretion of the defective parts of the appliance at its sole cost. - Page 12 Univa authorized service agent or if no fault or defects are found in the appliance, a Univa authorized service agent shall be entitled to charge for the work done and travelling expenses incurred.
