SG 1011
PRODUCT INFORMATION
– Operation: hand
– Range: S
– Fitting: recess (center SG 7550)
– Colours: white RAL 9016 or anodised aluminum, special colours possible
– Fabrics: refer to Silent Gliss fabric collection
Features:
– Pre-drilled profile
– Bendable
– Fitting tool center SG 7550
09/2022/V1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for silentgliss SG 1011
Summary of Contents for silentgliss SG 1011
- Page 1 SG 1011 PRODUCT INFORMATION – Operation: hand – Range: S – Fitting: recess (center SG 7550) – Colours: white RAL 9016 or anodised aluminum, special colours possible – Fabrics: refer to Silent Gliss fabric collection Features: – Pre-drilled profile –...
- Page 2 C: Distance between floor and fabric FITTING A. FITTING For detailed fitting information, visit the Silent Gliss website. INFORMATION Fixing points A: Center SG 7550 Fitting Tool B: Special screw SG 3019 / 12 mm C: Special screw SG 3025 / 18 mm SG 1011...
- Page 3 A: Profile Protector SG 7002 B: Special screw SG 3019 / 12 mm C: Special screw SG 3025 / 18 mm B. RECESS FITTING Direct into wood Recess channel: 6 x 9 mm SG 1011...
- Page 4 Draw rod 150 cm SG 3533 SG 3534 SG 11335 Glider Glider 3533 on strip End stop SG 3599 SG 3535 Hook Glider SG 3537 Glider SG 3547 Glider SG 3548 Glider SG 3549 Click glider with hook SG 3582 Hook SG 3598 Eyelet SG 7002 Profile protector SG 10430 Draw rod 50 cm SG 1011...
