KENT Champion 28 Parts List

Kent euroclean champion 28: supplementary guide
Hide thumbs Also See for Champion 28:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Use Manual , Operator's Manual
Champion
28
™
PARTS LIST
Kent MODEL 56648330
This manual is for machines after SN1588572.
Simple. Clean.
5/02 revised 4/06 FORM NO. 56042434

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Champion 28 and is the answer not in the manual?

Questions and answers

Related Manuals for KENT Champion 28

Summary of Contents for KENT Champion 28

  • Page 1 Champion ™ PARTS LIST Kent MODEL 56648330 This manual is for machines after SN1588572. Simple. Clean. 5/02 revised 4/06 FORM NO. 56042434...

  • Page 3: Table Of Contents

    02-5 TABLE OF CONTENTS 05-9 Champion ™ DESCRIPTION Base Housing ... 2-3 Brush Motor / Brush Assembly ... 4-5 Decal System ... 6-7 Handle System-1 (Before SN1887477) ... 8-9 Handle System-2 (Before SN1887477) ... 10-11 Handle System-1 (After SN1887476) ... 12-13 Handle System-2 (After SN1887476) ...

  • Page 4: Base Housing

    02-5 BASE HOUSING Champion ™ FORM NO. 56042434...

  • Page 5: Base Housing

    02-5 BASE HOUSING 05-4 Champion ™ Item Ref. No. Description 56002098 Wsh, Flt SAE 1/4 56002145 Scr, Pan Phil 1/4-20 x .50 56002147 Scr, Pan Phil (UNF) 10-32 x .20 56009097 Nut, Push Cap 56002220 Wsh, Flt Std 5/16 56002507 Scr, Pan Phil 1/4-20 x .75 56055213 Hinge, Butt...

  • Page 6: Brush Motor / Brush Assembly

    02-5 BRUSH MOTOR / BRUSH ASSEMBLY 05-4 Champion ™ FORM NO. 56042434...
  • Page 7 02-5 BRUSH MOTOR / BRUSH ASSEMBLY 05-4 Champion ™ Item Ref. No. Description 56330012 Brush, Motor Assy (#1-18, 38) 56001819 Scr, Hex Hd 3/8-16 x 4.00 56001823 Scr, Soc Set Loc 10-24 x .38 56002021 Scr, Soc Set Loc 5/16-18 x .38 56002035 Scr, Hex Hd 5/16-18 x .62 56002220...

  • Page 8: Decal System

    02-5 DECAL SYSTEM 05-4 Champion ™ FORM NO. 56042434...

  • Page 9: Decal System

    Ref. No. Description 56015188 Decal, Knob 56016472 Decal, Wiring 56016619 Decal, Wand (After SN1887476) 56057686 Label, Height Adjust 56630714 Label, Warning 56016329 Decal, Champion 28 56016475 Decal, Wand (Before SN1887477) 56014119 Decal, Ground Symbol * = Not Shown FORM NO. 56042434...

  • Page 10: Handle System-1 (Before Sn1887477)

    02-5 HANDLE SYSTEM-1 (Before SN1887477) 05-9 Champion ™ FORM NO. 56042434...

  • Page 11: Handle System-1 (Before Sn1887477)

    Wsh, Bowed .375 x .578 x .060 56009056 Wsh, Int SHPRF #6 56331312 Gasket 56331313 Housing 56331345 Plate 56331356 Lever Weld’t. 56442445 Swivel Wire 56331155 Seal 56630714 Label, Warning 56016475 Decal, Wand 56323296 Vacuum Tool Kit ** = Optional FORM NO. 56042434...

  • Page 12: Handle System-2 (Before Sn1887477)

    02-5 HANDLE SYSTEM-2 (Before SN1887477) 05-9 Champion ™ FORM NO. 56042434...

  • Page 13: Handle System-2 (Before Sn1887477)

    Door Assembly (#10-14) 56055050 Latch, Twist 56639110 Weldment, Door 56055053 Gasket 56009247 Scr, Pan Phil Plastite 10-14 x .38 56330033 Gasket 56330007 Vacuum Motors Assy (#15-27) 56384898 Filter 56325096 Vacuum Motor 56209325 Gasket 56055042 Gasket, Foam 56055041 Gasket, Foam 56055023...

  • Page 14: Handle System-1 (After Sn1887476)

    02-5 HANDLE SYSTEM-1 (After SN1887476) 05-9 Champion ™ FORM NO. 56042434...

  • Page 15: Handle System-1 (After Sn1887476)

    Guard, Bag 56055182 Gasket, Foam 56055218 Gasket, Foam 56111384 Rubber Bushing 56330005 Handle Assembly 56330006 Door Assembly 56330007 Vacuum Motors Assembly 56330008 Muffl er Assembly 56330589 Bag, Collector 56330608 Clip, Bag 56330821 Lever 56330822 Gasket, Base 56330823 Base, Lever Mount...

  • Page 16: Handle System-2 (After Sn1887476)

    02-5 HANDLE SYSTEM-2 (After SN1887476) 06-4 Champion ™ FORM NO. 56042434...
  • Page 17 56055117 Gasket, Foam 56055118 Gasket, Foam Item Ref. No. Description 56330830 Vacuum Diverter Assy (#83-95, 105) 56002192 Scr, Pan Phil 10-24 x .75 56002438 Scr, Hex Thd Form 8-32 x .50 56003093 Scr, Pan Phil Plastite 8-16 x .50 56003269 Ring, Ret Ext Type E Reinf.

  • Page 18: Wiring Diagram

    02-5 WIRING DIAGRAM Champion ™ FORM NO. 56042434...
  • Page 19 56330013 56755056 56026973 56026412 MOTOR, BRUSH Description Circuit Breaker, 10 Amp Cord Set, 120V Vacuum Motor Carbon Brush Set for 56325096 Vacuum Motor Carbon Brush Set for 56325096 Brush Motor, 1/3hp Replacement Capacitor for 56330013 Main Switch Brush Switch BRUSH SWITCH 10 A CIRCUIT BKR.
  • Page 20 Simple. Clean.
