- Page 1 PREANALYTICAL TOOLS FOR MODERN MICROBIOLOGY AirPrep™ Cub Sampler User Guide Models ACD210 and ACD200...
-
Page 2: Table Of Contents
Contents Product Overview…………………………………………………….. 3 Product Description……………………………………………………3 Collection Capability…………………………………………………..3 Materials Provided:…………………………………………………….3 Materials Required But Not Provided………………………….4 Method of Operation………………………………………………….5 Sample Collection on an Electret Filter………………………..5 Instant Wet Foam Elution™…………………………………………5 Sampler Components…………………………………………………7 AirPrep Cub Sampler Components………………………………7 Procedures………………………………………………………………. 8 Setting Up the AirPrep Cub Sampler for Collection………8 Installing the Filter………………………………………………………8 Control Panel Introduction………………………………………….8 4.3.1... -
Page 3: Product Overview
*Upon receipt, always inspect components when unpacking. If damage is observed, do not use and contact InnovaPrep or local distributor immediately. Please use the original box and foam packaging in the event a return shipment is necessary. -
Page 4: Materials Required But Not Provided
The AirPrep Filter & Elution Kit includes: 1. Elution Fluid Canister 2. Elutor Cap 3. Filter 4. Sample Cup 5. Sample Cup Lid (not shown) The kits are available for purchase on the InnovaPrep website https://www.innovaprep.com/store FIGURE 1 AIRPREP FILTER & ELUTION KIT... -
Page 5: Method Of Operation
The foam immediately collapses back into a liquid and is ready for sample processing and analysis. InnovaPrep’s patented Wet Foam Elution process (https://www.innovaprep.com/patents) is much more efficient than liquid... - Page 6 Bubble Dynamics - The micro-bubbles in the foam behave as deformable • solids. As they travel through the filter they move as a rigid body. Exfoliating Action - As the micro-bubbles in the foam impact against each • other and burst, the turbulence and energy produced helps to lift particles that are adhering to the filter fibers.
-
Page 7: Sampler Components
AMPLER OMPONENTS AMPLER OMPONENTS 1. Omni-Directional Inlet Cap – protects from water ingress 2. Inlet - screws off left to open for loading or recovering the filter cartridge. Screws on right to close 3. Front Panel - Power on and Mode selections (see section 4 for instructions) 4. -
Page 8: Procedures
ROCEDURES This section includes some of the basic instructions for operation. ETTING P THE AMPLER FOR OLLECTION Push the barrel plug of the power supply (Figure 2) into the power jack on the bottom of the instrument. Plug the AC Power Cord into the power supply and plug the other end into an appropriate wall outlet. -
Page 9: Power On
Timer LED Indicator Light • The timer LED Indicator light will flash slowly as they countdown, as they approach the expiration they will increase in frequency until the unit times out and shuts down. The light will remain solid for the last 10% of the timer. -
Page 10: Powering Off Manually Before Time Expires
4.3.3 OWERING OFF ANUALLY BEFORE TIME XPIRES To power-off the Air Sampler before the time expires, hold the Hold/Mode button for 2 seconds, the unit will power-off. 4.3.4 OWER UE TO ATTERY Model 210 only FIGURE 5. POWER-OFF DUE TO LOW BATTERY (MODEL 210) 4.3.5 ELECTING THE FLOW RATE 1. -
Page 11: How To Select A Timed Run Mode
3. momentarily press the Hold/Mode button again The 100LPM LED indicator light will flash. If desired, stop to select. Additional momentary presses will continue to cycle through the 50, 100 and 200 LPM LEDs 4. Press the Hold/Mode button for 2 seconds to save. Selected flowrate mode is saved, and LED indicator light illuminates steadily;... -
Page 12: Eluting The Sample From The Filter
LUTING THE AMPLE FROM THE ILTER To extract the captured particles from the filter: 1. Place the sample cup, filter, and elutor cap, as shown in Figure 6, on a stable surface. 2. Firmly press the elution fluid canister into the elutor cap. -
Page 13: Airprep Cub Sampler- Model Acd210 Battery Safety Information
ACD210 B AMPLER ODEL ATTERY SAFETY INFORMATION 14.4V 3350mAh Operating temperature: Charge: 10 - 45°C • • Discharge: -20 - 6O°C Storage temperature: Recommended 25+/-5°C at 50% state of charge • Do not immerse the AirPrep Cub Sampler in liquid. Exposure to liquid may damage the battery or the circuits. -
Page 14: Specifications
Long Term Storage 20 – 30°C, 45-85% RH, @ 50% Charge (> 3 (Recommended) Months) Please contact InnovaPrep or an official InnovaPrep distributor for technical assistance and troubleshooting. InnovaPrep, LLC 132 East Main Street, Box 68, Drexel, MO 64742 Phone: 816-619-3375 info@innovaprep.com and...
