Everlz 7707VR-4 Manual

Quad sdi fiber receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1.
OVERVIEW.......................................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 2
2.1. CARE AND HANDLING OF OPTICAL FIBER............................................................................ 3
3.
SPECIFICATIONS............................................................................................................................... 4
3.1. OPTICAL INPUT......................................................................................................................... 4
3.2. SERIAL VIDEO OUTPUTS ......................................................................................................... 4
3.3. ELECTRICAL ............................................................................................................................. 4
3.4. PHYSICAL .................................................................................................................................. 4
4.
STATUS INDICATORS AND DISPLAYS ........................................................................................... 5
4.1. STATUS INDICATOR LEDS....................................................................................................... 5
4.2. DOT-MATRIX DISPLAY ............................................................................................................. 7
4.2.1. Displaying the Optical Power .......................................................................................... 8
4.2.2. Displaying the Output Video Standard ............................................................................ 9
4.2.3. Video Output On Loss ..................................................................................................... 9
4.2.4. Signal BLOCK Configuration......................................................................................... 10
4.2.6. Displaying the Firmware Version................................................................................... 11
4.2.7. Upgrade Mode............................................................................................................... 11
5.
JUMPERS AND LOCAL CONTROLS .............................................................................................. 12
BY THE GLOBAL FRAME STATUS ........................................................................................ 12
5.3. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES .............................................. 12
6.
®
6.2. V
®
®
®

TABLE OF CONTENTS

? ............................................................................................................. 13
®
MONITORED PARAMETERS .............................................................................. 13
CONTROLLED PARAMETERS ........................................................................... 14
TRAPS .................................................................................................................. 14
®
Revision 1.3
7700 MultiFrame Manual
7707VR-4 Quad SDI Fiber Receiver
