Integral LED ILEMTS033 Installation Instruction Sheet

Model
ILEMTS033
Thank you for purchasing and Integral Led product. When installed correctly this unit will
provide years of service with no lamp changes required. For support or warranty information
please visit www.integral-led.com/warranty. Always turn off power at the distribution unit before
any maintenance or installation. Please ensure the power cannot be re-connected inadvertently.

General Safety Instructions

1. Never look directly into the LED light source. The light emitted can contain the colour blue.
2. To clean: Ensure that the floodlight is disconnected from the mains and cannot be
unintentionally reconnected.
3. Place only upon level and stable surfaces.
4. Do not use in rooms in which there is a danger of explosion.
5. Do not place in water or other liquids.
6. Never operate with wet hands.
7. Never attempt to repair this unit yourself. Repairs should only be carried out by the
manufacturer or their authorised service personnel.
8. If the supply cable is damaged, it must be replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a hazard.
9. The distance between the item and the objects must be more than 1M.

Installation Instructions

1. Isolate the mains supply prior to wiring.
2. To open the twin spot unclip the front cover.
3. Feed the mains cable through the appropriate knock out and mark the screw positions on the
wall.
4. Fix the back plate to the wall.
5. Connect the mains supply to the screw terminal block on the back plate. L = live, N = neutral.
6. Connect the battery to the PCB and write installation date on the battery.
7. Locate the front cover and secure it with the clips provided.
Installation Instruction Sheet
for Integral Twin Spot Emergency Floodlight
3 Year Warranty
Description
4.5W Twin Spot
Emergency Floodlight
with Self-Test
Lumens Dimensions
255mm x 55mm x
400
287mm
Weight
0.9Kg
(Gross)
