- Page 1 DUSTTRAK AEROSOL MONITOR ™ SOLAR POWER KIT MODEL 854060 (FOR DUSTTRAK™ II AND DRX AEROSOL MONITOR MODELS 8540 AND 8543) OPERATION AND MAINTENANCE MANUAL P/N 6008416, REVISION B JUNE 2016...
- Page 3 Copyright© TSI Incorporated / 2015–2016 / All rights reserved. Part Number 6008416A / Revision B / June 2016 Address TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA Fax No. (651) 490-3824 LIMITATION OF WARRANTY AND LIABILITY (effective February 2015) (For country-specific terms and conditions outside of the USA, please visit www.tsi.com.) Seller warrants the goods, excluding software sold hereunder, under normal use and service as described in the operator's manual, shall be free from defects in workmanship...
- Page 4 TO THE EXTENT PERMITTED BY LAW, THE EXCLUSIVE REMEDY OF THE USER OR BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES, INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL BE THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE PRICE, OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE GOODS.
-
Page 5: Table Of Contents
Contents Contents ....................1 Safety Information ................1 Description of Caution/Warning Symbols ..........3 Caution and Warning Symbols ..............3 Reusing and Recycling ................4 Product Overview ................4 Setting Up ................... 4 Operation ..................16 Overview ....................16 Specifications ................... 17... -
Page 6: Safety Information
Safety Information W A R N I N G S Use of components other than those specified by TSI may impair the safety features provided by the equipment. The instrument has been design to be used with batteries supplied by TSI. Do not use a substitute Old batteries must be properly recycled in accordance with the local environmental regulations. -
Page 7: Description Of Caution/Warning Symbols
Description of Caution/Warning Symbols Appropriate caution/warning statements are used throughout the manual and on the instrument that require you to take cautionary measures when working with the instrument. Caution C a u t i o n Failure to follow the procedures prescribed in this manual might result in irreparable equipment damage. -
Page 8: Reusing And Recycling
Reusing and Recycling As part of TSI Incorporated’s effort to have a minimal negative impact on the communities in which its products are manufactured and used: Do not dispose of used batteries in the trash. Follow local environmental requirements for battery recycling. - Page 9 The full Solar Cell Power System is shown in Figure 1. The following section details the setup of this system. I m p o r t a n t Make all Solar Cell Power System electrical connections in the order outlined below. Damage to the system can occur if connections are not made in this order.
- Page 10 Figure 2: Install the Solar Battery and Connect to Controller 2. The next step is to attach the provided power cables with waterproof connectors to each Solar Cell. Remove the Solar Cell from its packaging and access the junction box on the end of the panel. Remove the screws and sealing strip from inside the box and set aside.
- Page 11 3. Next, attach the power cable to the Solar Cell screw terminals as shown in Figure 4 and Figure 5. Note Make sure the wires are connected as shown below. Connecting the wires incorrectly can cause severe damage to the Solar Power System. Refer to the Solar Cell manufacturer’s specification sheet for additional details.
- Page 12 4. With the wires tightened, secure the terminal block in its retaining clips, and tighten the strain relief connections to the power cable as shown in Figure 6. Figure 6: Secure Terminal Block and Tighten Strain Relief 5. Next, attach the sealing strip to the inside of the...
- Page 13 6. Then attach the cover to the junction box using the supplied screws, as shown in Figure 8. Figure 8: Attach Junction Box Cover 7. Now attach the two Solar Cells to the adjustable angle Mounting Frame using the supplied bolts, as shown in Figure 9. Figure 9: Assemble the Solar Cells on the Mounting Frame Operation and Maintenance Manual...
- Page 14 8. The support bar may also be attached to each side of the Mounting Frame, as shown in Figure 10. Figure 10: Assemble the Support Bar to the Mounting Frame For best results, mount the Solar Cells at an angle directly pointed at the path of the sun, allowing the maximum power to be collected by the Solar Cells.
- Page 15 Figure 11: Connect Solar Cells to Battery Enclosure Box 10. Connect the Solar Battery Enclosure to the provided outdoor DC power cable with weatherproof connectors, as shown in Figure 12. Figure 12: Connect Power from the Solar Cell Power System to the Environmental Enclosure Operation and Maintenance Manual...
- Page 16 11. Insert the cable into the cable assembly as shown in Figure 13. Figure 13: DC Cable Preparation 12. Remove bottom left plastic plug from the DustTrak Environment Enclosure and insert the cable through the hole as shown in Figure 14. Figure 14: DC Cable Preparation DustTrak Aerosol Monitor Solar Power Kit Model 854060...
- Page 17 13. Using a small screwdriver, connect the bare wires to the front panel connector outside of the enclosure as shown in Figure 15. The blue wire to terminal “N” and the brown wire to terminal “L”. Figure 15: DC Cable Preparation 14.
- Page 18 15. While holding the connecter in the enclosure notch, tighten the back- shell onto the connector as shown in Figure 17. Figure 17: DC Cable Backshell 16. Tighten the gland nut into the back- shell as shown in Figure 18. Figure 18: DC Cable Gland Nut DustTrak Aerosol Monitor Solar Power Kit Model 854060...
- Page 19 17. Connect phoenix grey connector to the power input on the DIN rail as shown in Figure 19. Figure 19: DC Cable to DIN rail 18. Affix DC label next to DC input connector as shown in Figure 20. Figure 20:DC Power Label Operation and Maintenance Manual...
-
Page 20: Operation
19. Connect DC power cord from solar enclosure as shown in Figure 21. Figure 21: DC Cable from Solar Battery to Environmental Enclosure Operation Overview Prior to using the Solar Cell Power System for the first time, a full recharge of the Solar Battery is recommended. Simply allow the Solar Battery to charge for a day with sunlight power from the connected Solar Cells The Solar Charge Controller has built-in low voltage cutout protection... -
Page 21: Specifications
Specifications Specifications are subject to change without notice. Power Requirements Solar System Run- Continuous (with adequate sunlight) time Rated Maximum Cell 80 watts (per Cell) Power Power Tolerance ±5% Nominal Voltage 12 Volts Solar System Battery 12 VDC, 100 Ah Battery Run-time 90 to 120 hours (typical, full-charge to power cutoff, when no sunlight for charging) - Page 22 TSI Incorporated – Visit our website www.tsi.com for more information. Tel: +1 800 874 2811 India Tel: +91 80 67877200 Tel: +44 149 4 459200 China Tel: +86 10 8219 7688 France Tel: +33 1 41 19 21 99 Singapore Tel: +65 6595 6388 Germany Tel: +49 241 523030 P/N 6008416 Rev.
