• Power save lowers the current drawn when system volume is reduced ABOUT THE MANUAL AND WARRANTY To start enjoying your new Clarion two-channel amplifier, please read the instructions listed in this manual. Keep all instructions for future reference. Please fill out and send in the enclosed warranty card to protect your purchase and aid in warranty service.
Protection circuits safeguard the amplifier when overheating and speaker shorts or improper load conditions occur. All connections and controls of the APX1000.2 are on the end panels and are easy to understand. We use gold-plated RCA and barrier connectors to ensure the best electrical connection for your system.
Page 4
• Gain Control - This allows you to set the nominal operating level of the amplifier. The amplifier’s range, 250mV to 2.5V for RCA inputs, can accommodate input levels from virtually any brand of source unit. • Bass Boost Control- The amplifier also features a “high-Q” (i.e. narrow frequency band) Bass Boost circuit.
CONNECTIONS FOR POWER AND SPEAKERS The rear panel of the APX1000.2 contains power and speaker connections as shown below. Figure 2- 1. Power Save Selector Switch 2. Left Speaker Output 3. Right Speaker Output 4. Ground Input 5. Remote Turn-on Input...
APPLICATIONS The Clarion APX1000.2 2-channel car audio amplifier can be used in a variety of system applications. Here are some examples to help plan your own installation. Bridged- Mono Subwoofer System Set X-Over Mode to LP and adjust FREQ to speaker specifications.
Page 7
2-Channel Full-Range, Satellite, or Subwoofer Stereo System (Set INPUT SELECT Switch to STEREO) Set X-Over Mode as shown. Set X-Over Mode as shown; adjust FREQ to speaker specifications. Set X-Over Mode as shown; adjust FREQ to speaker specifications. Figure 4 - In this application, the amplifier is used in stereo and drives two full-range (or satellite or subwoofer) speakers.
Page 8
Mixed-Mode Satellite and Subwoofer System (Set INPUT SELECT Switch to STEREO) FREQ (hz) L (mH) NOTE: Chart values based on 4 ohm speakers. Figure 5 - The amplifier can be configured for a mixed-mode operation. The table provides component values to create a 6dB per octave crossover at specified frequencies.
INSTALLATION This section lists Mounting and Wiring Precautions for installing a Clarion APX1000.2. Combined with the experience of a professional installer, these safeguards provide enough detail to successfully complete an installation. If you do not have the necessary skills, do not install the amplifier yourself.
Page 10
If you are planning a multi-amplifier system, you may need to add a second battery and possibly upgrade the alternator with a higher-output rated model. Consult your authorized Clarion dealer for recommendations. 10. To avoid noise problems, run the amplifier’s positive (+) power lead along one side of the vehicle to the battery.
Page 11
Figure 6. - Electrical connections for the APX1000.2...
4. Slowly increase the Gain Control. Stop when you hear a slight distortion of audio. SETTING THE CROSSOVER The Clarion APX1000.2 features a fully adjustable crossover. To set the crossover, follow these steps. 1. Set the X-Over Bypass switch to ON.
Speakers not connected or are blown. Check speaker connections at amplifier, measure coil impedance. Problem Audio cycles on and off. Solution Thermal protection circuits are shutting amplifier off. Check location for adequate ventilation; consult an authorized Clarion Audio Dealer.
Input Sensitivity Low Level Cont. Power Output 2-Ohm Stereo Output Bridged Power Dimensions Current Consumption at output @ max power APX1000.2 20Hz ~ 20kHz >105db .05% all channels driven 250mV ~ 2.5 V 500w (250w x 2) @.05% THD 250 x 2 @ .5% THD 1000x 1 @ .5% THD...
