Sharp LC-32SV21L Service Manual

Sharp LC-32SV21L Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SHARP
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
[1] SPECIFICATIONS ............................................................4
[2] OPERATION MANUAL .....................................................5
[3] DIMENSIONS .................................................................11
[1] ASSY/PANEL REMOVAL................................................12
[2] SET RE-ASSEMBLY.......................................................23
[1] ADJUSTMENT PROCEDURE ........................................24
[2] SOFTWARE UPGRADE PRODUCE ..............................29
[1] TROUBLESHOOTING TABLE .......................................37
[1] MAJOR IC INFORMATION .............................................43
[2] DETAIL ICs INFORMATION ...........................................53
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
SHARP CORPORATION
SERVICE MANUAL
LCD COLOUR TELEVISION
MODEL
CONTENTS
[1] BLOCK DIAGRAM ..........................................................62
[2] WIRIGN DIAGRAM ........................................................64
[1] MAIN UNIT PRINT WIRING BOARD .........................66
[2] POWER UNIT PRINT WIRING BOARD .........................68
[3] KEY UNIT PRINTED WIRINGBOARD ............................72
[4] IR UNIT PRINTED WIRING BOARD ..............................72
[1] MAIN SCHEMATIC DIGRAM .........................................73
[2] POWER SCHEMATIC DIGRAM .....................................90
[3] KEY SCHEMATIC DIGRAM ........................................92
[4] IR SCHEMATIC DIGRAM ..........................
CHAPTER 9. PARTS GAUILD
[1] SPARE PARTS LIST .........................
[2] CABINET PARTS .........................................
[3] PACKING PARTS .................................................99
1
LC-32SV21L&LC-42SV31L
LC-32SV21L
LC-42SV31L
...........................
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
..................
...93
..94
................
..96
