KEF REFERENCE 201/2 Reference page 26

MODEL 206/2ds MODEL 209
Design : Design :
Closed box three-way dipole loudspeaker,
magnetically shielded.
Drive Unit Array : Drive Unit Array :
1 x 200mm (8in.) LF, 2 x 165mm (6.5in.) Uni-Q MF
including 2 x 25mm (1in.) titanium HF
Frequency Response : Frequency Response :
65Hz - 60kHz
(@ 15° horizontally off axis ± 3dB) (@ 15° horizontally off axis ± 3dB)
Crossover Frequencies : Crossover Frequencies :
250Hz, 2.3kHz
Amplifier Requirements : Amplifier Requirements :
50 - 200W
Sensitivity : Sensitivity :
(2.83V / 1m) 88dB (2.83V / 1m)
Maximum Output : Maximum Output :
110dB
Impedance : Impedance :
8Ω (3.2Ω min)
Bass Extension : Bass Extension :
55Hz (-6dB)
Weight : Weight :
11.6kg (25.5lbs)
Dimensions (H x W x D) : Dimensions (H x W x D) :
324 x 400 x 200 mm
12.7 x 15.7 x 7.9 in.
Finishes : Finishes :
Piano Black, High Gloss American Walnut, Piano Black, High Gloss American Walnut,
High Gloss Cherry and Satin Sycamore real wood veneers High Gloss Cherry and Satin Sycamore real wood veneers
MODEL 208
Design :
Closed Box, Bass reflex,
magnetically shielded. magnetically shielded.
Drive Unit Array :
1 x 450mm (18in.) long-throw LF 1 x 300mm (12in.) long-throw LF
Frequency Response :
15Hz - 250Hz 25Hz - 200Hz
(@ 15° horizontally off axis ± 3dB)
Crossover Frequencies :
N/A
Amplifier Requirements :
1000W built in 500W built in
Sensitivity :
Active system (2.83V / 1m) Active system
Maximum Output :
120dB 117dB
Impedance :
Active system Active system
Bass Extension :
12Hz (-6dB) 22Hz (-6dB)
Weight :
51.9kg (114.4lbs) 37.5kg (82.7lbs)
Dimensions (H x W x D) :
530 x 629 x 629 mm 465 x 576 x 579 mm
20.9 x 24.8 x 24.8 in. 18.3 x 22.7 x 22.8 in.
Finishes :
Piano Black, High Gloss American Walnut,
High Gloss Cherry and Satin Sycamore real wood veneers
HIGH GLOSS AMERICAN WALNUT
N/A
PIANO BLACK
HIGH GLOSS CHERRY
SATIN SYCAMORE
Light to dark chocolate brown, occasionally
with a purplish cast and darker streaks, growing
more lustrous with age. The deep shine brings
out the rich character of the slightly open,
generally straight grain.
Like the deeply lacquered mirror shine of a
concert grand, the seductively smooth high gloss
jet black finish accentuates the gentle curves of
the new Reference Series cabinets.
Prized for fine cabinet work and musical
instruments because of its smooth texture,
fine uniform grain and deep colour, cherry
heartwood ranges from a warm burnt orange
to rich red with occasional dark flecks.
Creamy white to palest yellow, sycamore has a
close, even texture with subtly interlocked grain
and natural lustre. The preferred wood for violin
backs, its natural lustre is brought out by a
distinctive satin sheen.
VENEERS
