Black Mobile TV Cart
Instruction Manual
SKU: STAND-TV04M
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv04m
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV04MW
Summary of Contents for Vivo STAND-TV04MW
- Page 1 Black Mobile TV Cart Instruction Manual SKU: STAND-TV04M Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv04m GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 55lbs Failure to do so may result in serious injury. (24.95kg) Phillips Screwdriver WARNING: CHOKING HAZARD SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED. ASSEMBLY STEPS STEP 1 Attach wheels (9) to the long and Use Tool kit(21) short square tubing (1,2) using the...
- Page 4 STEP 3 Insert pole cover (8) into top of pole (6). Attach poles (5,6) using pole connector (7). Carefully thread the pole connector in perfectly straight to avoid cross-threading. If you feel resistance, back the connector out and restart. Once you are certain the connector is going in straight, use additional force to tighten.
- Page 5 STEP 5 STEP 6 Attach shelf support connecting plate (13) to Attach shelf supports (15) to shelf (14) using M6 pole (5) using M6x10 allen head bolts (12). nuts (16). 240mm 12 13 STEP 7 STEP 8 Mount shelf (14) onto shelf support Slide square plate connector and rubber pad connecting plate (13) using M6x10 allen head (17) over top of pole (6) and tighten grub...
- Page 6 STEP 9 Attach square plate (18) to square plate connector using M6x10 allen head bolts (12) and M6 washers (19). STEP 10 10-1: 10-2: Secure the TV arm set (20) to back of If necessary, use spacers (28,29). television using bolts (22-24) and washers (25-27).
- Page 7 STEP 12 STEP 11 Tighten safety bolt using phillips head Attach television to square plate as shown in screwdriver. diagram. Safety bolt STEP 13 Adjust height and tilt angle for best viewing. Route cables as needed. ±15˚...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
