Sealed/Acoustic Suspension
OPTIMUM
Enclosure Airspace (Unfilled) = 1.81ft
Enclosure Airspace (Filled) = 1.60 ft
F c = 31.7 Hz
Vented/Bass Reflex
Clarion Sales Corporation 661 W. Redondo Beach Blvd., Gardena, CA 90247
Phone: 1-800-GO-CLARION FAX: (310) 327-1999
Model: XW-1500
• Polypropylene Cone
• Rubber Surround
• Dual 4 Ohm Heat Resistant Voice Coil
• Rear Vented Pole Piece
• Large Strontium Ferrite Magnet
• Rubber Magnet Cover
• For Small Sealed or Small Vented Design
Maximum Power Handling (Coils in Series) ...1200W
Continuous Power (Coils in Series) ...............600W
SPL (Coils in Series) .....................................88dB@ 1W/1M
Frequency Response .................................. 20HZ~1.5KHZ
Woofer Cone Material ................................Polypropylene
Woofer Magnet ..........................................Ferrite
Woofer Basket ..........................................Alumina
Woofer Surround ......................................Rubber
3
Thiele Small Parameters
3
Outside Dia
Mounting Hole
Mounting Depth
Sensitivity
Max. Peak Music
Continuous Power
Nominal Impedance
Re DC Imp (± 10%)
Le
V.C. Diameter
V.C. Length
Air Gap
Piston Diameter
Sd
Vas
Fs
Qts
Qes
Mms
Mmd
Rms
BI
Speaker Displacement
Xmax
Magnet Weight
15"
370mm
196mm
88dB
600W*2
300W*2
1.9 Ohm (paralleled)
3.7 Ohm
1.36mH@1kHz
2.5"
33mm
8 mm
330 mm
0.0855 sqM
134.084 L (paralleled)
27.7 HZ (paralleled)
0.5434 (paralleled)
0.6186 (paralleled)
235.5258 g (paralleled)
241.1505 g (paralleled)
9.394kgs-1 (paralleled)
1.6877 TM (paralleled)
06.87 CM
(paralleled)
3
12.5mm
85.5 oz
