- Page 1 SFW/SRW/SW SUBWOOFER...
- Page 2 Congratulations, you have just purchased one of the most refined products Clarion has ever produced. The SFW/SRW/SW line of subwoofers offers benchmark levels of performance, reliability and style. We highly recommend that an Authorized Clarion dealer construct an application specific enclosure. This will ensure that the speaker offers the best possible performance for your application, while consuming the least amount of space in the your vehicle.
-
Page 3: Table Of Contents
Content 1. Thiele Small Parameters ... 2 2. Mounting Information ... 3 3. Subwoofer Break-In Period ... 3 4. Subwoofer Enclosure Applications SFW1051 Single 4 Ohm Voice Coil Shallow Mount 10” Subwoofer ... 4 SRW1051/SRW1052 10” Subwoofers ... 5 SRW1251/SRW1252 12” Subwoofers ... 6 SW1051 Single Voice Coil 10”... -
Page 4: Thiele Small Parameters
0.3133 0.311 85.101 86.96 86.92 0.045 0.06 0.06 SW1051 SW1251 3.66 30.811 29.891 0.034636 0.053913 35.598 67.924 208.971 164.568 124.517 157.877 131.930 172.273 13.245 13.150 5.287 6.573 0.530 0.685 0.482 0.620 1.600 1.845 0.181 0.256 84.592 86.103 0.045 0.06 SFW/SRW/SW... -
Page 5: Mounting Information
Diameter Mounting 3” Depth • Total 3-3/4” Height NOTES: • T his is the exact mounting depth of the driver, and does not include provisions for air flow from the vented pole piece. Clarion recommends at least 1” of clearance behind the driver to facilitate air flow and proper cooling. 3. Subwoofer Break-In Period All new speakers require some amount of time to break in. Depending on the applica- tion, this may take between one and four weeks. To accelerate this process, you can manually ‘break in’ your subwoofer before installing it. With the subwoofer sitting on a scratch-resistant surface, connect it to an amplifier and play a 5Hz sine wave at a level of 10V (8V for SFW) for a period of four to six hours. If you have any questions or concerns, please do not hesitate to contact your Authorized Clarion Dealer. SFW/SRW/SW 10-5/16” 12-9/32” 9-1/32” 10-31/32” 4-25/32” 5” 5-1/32” 5-1/4” SW1051 SW1251 10-5/16” 12-9/32” 9-1/8” 11-1/16”... -
Page 6: Subwoofer Enclosure Applications
SEALED ENCLOSURE * Limit power levels to 160W in this application Net Volume 0.45 cubic feet 55.7 Hz Qtc 0.71 Subsonic Filter 5Hz Nitrile-butadiene rubber surround Paper Dust Cap Kapton Voice Coil Fromer SFW1051 1/4" 3" Paper with Fiber Glass Cone Poly-Cotton Spider Spider landing Ring Dual Copper Voice Coil Magnet Bottom Plate SFW/SRW/SW... -
Page 7: 10" Subwoofer
1.0 Cubic feet Port 0.75” x 1” x 6” Subsonic Filter 5Hz 0.5 Hz DUAL PORTED ENCLOSURE - SPL Net Volume: 1.75 Cubic Feet Port 4” x 1-/8” Subsonic Filter: 5Hz Hz SFW/SRW/SW 1/4” Nitrile-butadiene rubber surround Paper Dust Cap Kapton Voice Coil Former SRW1051 4-25/32” Paper with Fiber Glass Cone Poly-Cotton Spider Spider landing Ring... -
Page 8: Srw1251/Srw1252 12" Subwoofers
.5 Cubic Feet Port: 4” x 7-1/” Subsonic Filter: 0Hz F: 9Hz 1/4" Nitrile-butadiene rubber surround Paper Dust Cap Kapton Voice Coil Former SRW1251 5" Paper with Fiber Glass Cone Poly-Cotton Spider Spider Landing Ring Dual Copper Voice Coil Dual Stacked Magnet Bottom Plate SFW/SRW/SW... -
Page 9: Sw1051 Single Voice Coil 10" Subwoofer
Sw1051 PORTED ENCLOSURE - SOUND QUALiTy Net Volume: 0.65 Cubic Feet Vent ” x 16” F: 8.56Hz Sw1051 DUAL PORTED ENCLOSURE - SPL Net Volume: 1.5 Cubic Feet Vent: 4” x 11-1/8” F: 9.79 Hz SFW/SRW/SW 1/4” Nitrile-butadiene rubber surround Chromed Dust cap Kapton Voice Coil Former SW1051 5-3/4” Inject Plastic Cone Steel Basket Poly-Cotton Spider... -
Page 10: Sw1251 Single Voice Coil 12" Subwoofer
Sw1251 DUAL PORTED ENCLOSURE - SPL Net Volume: .5 Cubic Feet Vent” 4” x 7.5” F: 6.51 Hz Nitrile-butadiene rubber surround Chromed Dust cap Terminal Kapton Voice Coil Former Tope Plate SW1251 6-7/16” 1/4” Inject Plastic Cone Steel Basket Poly-Cotton Spider Dual Copper Voice Coil Dual Stacked Magnet Bottom Plate SFW/SRW/SW... -
Page 11: Subwoofer Application Comparison
SFW ENCLOSURE DESIGN NOTE: When constructing an enclosure for the SFW1051, please ensure the subwoofer is mounted in so the cone does not come into contact with any object (back of seat) when in use. This may require the installation of a grill or recessing the subwoofer into the enclosure. The subwoofer may be damaged if it comes into contact with any surface while in operation. ENCLOSURE DESIGN NOTES: • A ll enclosures should be constructed of at least /4” MDF. Particle board is not suitable for any enclosure and may result in the subwoofer system offering poor performance or the driver may be damaged. • A ll panel joints should be sealed with appropriate caulking (latex or rope caulk). Do not use Silicone. • A ll joints must be secured with screws or nails. • A ny panel exceeding 4 square feet in area (’x’ or 1’x4’ for example) should be braced internally for resistance to flexing • A ll enclosure volumes are net and do not include the displacement of the sub- woofer, ports or bracing. Please include these items in your enclosure calculations • C larion does not recommend the use of passive crossover networks with our subwoofers (inductors, chokes). Use an amp with an electronic crossover for the... -
Page 12: Calculating Enclosure Dimensions
Maximum Trunk Width Maximum Trunk Height Net Enclosure Volume Material Thickness Driver Displacement Port Dimensions Step 1: Measure the trunk width and height. Take note of seat belt mechanisms, strut tower protrusions and trunk opening size when measuring. Eg: 5” wide by 15” tall Step : Calculate the gross enclosure volume. This includes the net enclosure volume, plus the displacement of the drivers, port(s) and any bracing. There is no bracing being used in this example, however Clarion recommends an enclosure of this size be properly braced. Eg: .5 ft net volume, 0.06 ft Gross Volume: .5 + 0.06 + 0.06 + 0.049 = .665 ft Step : after subtracting the material thickness from the maximum width and maximum height, we can calculate the depth of the enclosure. Eg: 4605.1 ÷ ((5-0.75-0.75) x (15-0.75-0.75) = 10.18 inches. Step 4: Add the material thickness to the inside depth calculation and you have the outside dimensions of you enclosure. Eg: 10.18 + 0.75 + 0.75 = 11.68 inches. Width = 5” Height = 15” Depth = 11.68” Step 5: You can now cut and assemble the panels for your enclosure. Make sure all joints are perfectly sealed and there are no air leaks anywhere. If you choose not to wrap the enclosure in carpet, use foam gaskets when installing the woofers to ensure an air-tight seal against bare wood. Example: 5 inches 15 inches .5 cubic feet 0.75 inches 0.06 cubic feet 4” x 7.5” long per speaker, 0.049 ft port. or 4605.1 cubic inches. SFW/SRW/SW... - Page 13 Converting cubic inches to cubic feet To convert cubic inches to cubic feet, divide by 178 To convert cubic feet to cubic inches, multiply by 178 Port Volume Calculation The equation to calculate the volume of a round port is: Radius x Radius x Pi x Net Depth. The net depth is the total depth of the port minus the thickness of the wood it is mounted in. For our example using a 4” port, 7.5” long, the equation would be: x x .1416 x (7.5-.075) = 84.85 cubic inches or 0.049 cubic feet. Wedge Style Enclosures To further maximize the available storage space in your vehicle, you may choose to have the back panel of the enclosure follow the angle of the rear seat back. To calculate the volume of the enclosure, we need to find the average depth of the enclosure. In our example, we had an enclosure depth of 11.68 inches. To calculate the top and bottom panel depths of a wedge enclosure, we need to know how much deeper the bottom is than the top. Follow these steps Step 1: Place a board on the trunk floor and slide it to the base of the rear seats. Step : Cut a small board that when combined with the thickness of the first board, is the total height of the enclosure. In our example with would be 15 inches, so the board would be 14.5 inches. Step : Stand this board up on the first board and slide it toward the back of the trunk until it runs into the top of the seat back. Mark a line at the rear edge of the board. Step 4: Measure from the line to the end of the bottom board. This is how much longer the bottom board is than the top. For this example, we will say it is 5 inches. We now need to calculate the new depth of the enclosure, knowing the bottom is 5 inches deeper than the top. The average new depth of the enclosure is half of 5 inches, or .5 inches. The top of the enclosure will need to be 11.68 – .5 = 9.18 inches The bottom of the enclosure will need to be 11.68 + .5 = 14.18 inches SFW/SRW/SW...
-
Page 14: Limited Warranty Information
GREATER DURATION THAN THE WARRANTY PERIOD SET FORTH ABOVE. UNDER NO CIRCUMSTANCES SHALL CLARION BE LIABLE FOR ANY LOSS OR DAMAGE, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INABILITY TO USE THE PRODUCT. BECAUSE SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR EXCLUSIONS OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. - Page 16 Clarion Corporation of America All Rights Reserved. Copyright © 006: Clarion Corp. of America Printed in China...
