- Page 1 Home Dehumidifier Please read the manual carefully before using the unit D023H USER MANUAL www.sleavon.com...
- Page 3 Sleavon room's humidity and bring you a healthy and comfortable life. TO ACCESS CUSTOMER SUPPORT FASTER If there is any problem of the product, please contact Sleavon Customer Service support@sleavon.com with your Purchase Order ID to help you address the...
- Page 4 BEFORE FIRST USE: To prevent any internal damage, it is very important to keep refrigeration units (like this one) upright throughout their journey. Please leave it standing upright and outside the box for 24 HOURS before plugging it in.
-
Page 5: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ............1 FEATURES & SPECIFICATIONS..........2 PRODUCT DRAWINGS ............3 MACHINE SETUP & OPERATION ........4 WATER DRAINAGE ..............7 MAINTENANCE & STORAGE..........10 TROUBLE SHOOTING............11 SPECIAL NOTES..............12 WARRANTY & CONTACT US ..........13... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT NOTICE FOR FIRST USE: For your safety, please read the manual carefully and keep the manual for future reference. Please use this product according to the instructions of installation and operation of this manual. Don't try to repair, dismantle or modify this appliance, or it may cause damage. Install the unit on flat and hard floor to diminish vibration or noise. -
Page 7: Features & Specifications
40 pints per day, efficient dehumidification ● Three optional modes (AUTO,CNT,SLEEP) ● Compact and modern design ● Extremely quiet operation(36dB(A)) ● Auto defrosting SPECIFICATIONS Model No. D023H Power Source AC115V 60Hz Rated Power(86˚F,80%RH) 195W Rated Current(86˚F,80%RH) 2.0A Moisture Removal(65˚F,60%RH) 9 Pints/Day(4.2L/Day) Moisture Removal(80˚F,60%RH) 13 Pints/Day(6.1L/Day) Moisture Removal(86˚F,80%RH) -
Page 8: Product Drawings
PRODUCT DRAWINGS Front Control Panel Air Outlet Display Lamp Front Shell Universal Castor Back Back Shell Air Inlet Power Cord Continuous Drainage Outlet Visible Water Level Water Tank... -
Page 9: Machine Setup & Operation
MACHINE SETUP & OPERATION DIGITIAL DISPLAY Blue Green humidity<45% 45%≤humidity≤65% humidity>65% OPERATRIONS 8.8. Button Function Power After plugging the power, the “POWER” indicator will light up, the machine is in standby mode. In this mode, press the “POWER” button to turn on the machine, it will enter the Auto Mode automatically , the “HUM SET”... - Page 10 MACHINE SETUP & OPERATION ● Auto Mode Both the fan speed and the humidity value can be adjusted under Auto Mode, and the “HUM SET” indicator will light up at this mode. When environmental humidity ≥ set humidity by 3%RH, the fan will start to work and compressor will start 3 seconds afterwards.
- Page 11 MACHINE SETUP & OPERATION Humidity Setting Press the humidity button you can check the current environment humidity, and press again you can set the humidity. The range of target humidity is: 30%- 35% - 40% - 45% - 50% - 55%- 60% - 65% -70% - 75%- 80%. After setting for 3 seconds, the system will confirm the input value, then the machine will exit the setting status, and return the current humidity.
-
Page 12: Water Drainage
WATER DRAINAGE Water Tank Full Alarm When the tank is full for 5 seconds, it activates the Full Tank Alarm. The Full Tank indicator will turn red and the unit will buzz for 5 times. Clear the alarm When the buzz is on, press any button to stop it. The compressor and fan will shut down, and all the functions will freeze until the tank is emptied and put back in right position. - Page 13 WATER DRAINAGE PRECAUTIONS Ensure the water tank is in right Do not remove the float out of the position when putting it back, tank otherwise the dehumidifier otherwise the dehumidifier can can not start up. not start up. If the tank is dirty, wash it with cool/warm water. Do not use detergent, steel balls, chemically treated dustproof cloth, gasoline, benzene, thinners or other chemical solvents in case damage and leakage.
- Page 14 WATER DRAINAGE CONTINUOUS DRAINAGE Take out the water tank Water Tank Use a water hose to connect the water outlet. Dress the water hose through the cutting hole in the tank and push the tank back to the machine. For continuous drainage, the drainage end of the hose should not be submerged in water in case being blocked or damaged.
-
Page 15: Maintenance & Storage
MAINTENANCE MAINTENANCE & STORAGE MAINTENANCE Body Cleaning Use a soft and slightly wet cloth to clean the dehumidifier body. Filter Cleaning 1. Take off the filter mesh. 2. Use a vacuum cleaner to gently absorb the dust on the surface. If the filter is very dirty, wash it with water and a soft cloth and dry it thoroughly afterwards. -
Page 16: Trouble Shooting
TROUBLE SHOOTING FUNCTIONING TEMP. 41℉ ≤ Ambient Temp. ≤95 ℉ When the ambient temp. is lower or higher than the functioning temp., the dehumidifier will stop operating. When the machine is working between the ambient temperature of 41℉ and 60.8℉, the compressor will automatically defrost at intervals.When defrosting, the compressor will stop and the fan will keep running. -
Page 17: Special Notes
SPECIAL NOTES Do not insert thin rods and hard objects into the machine body to avoid malfunction and danger. Please clean the filter every two When cleaning the dehumidifier, weeks (do not use hot water please use the wet textile to above 104°F, alcohol, gasoline wipe gently, do not shoot the or toluene.) -
Page 18: Warranty & Contact Us
There are our general terms for the warranty service, but we always encourage our customers to contact us if any issues, regardless of warranty terms. If you are experiencing an issue with Sleavon product, you can reach out to us at support@sleavon.com, we will dedicate our efforts to resolve it for you. - Page 20 Sleavon Sleavon For FAQs and more information please visit: Sleavon www.sleavon.com Sleavon (Scan the QR Code for Live Chat) We are expecting to see our products fulfill your life and hear your voice. Your satisfaction means a lot to us.
