- Page 1 Home Dehumidifier Please read the manual carefully before using the unit D001F USER MANUAL www.sleavon.com...
- Page 3 Sleavon room's humidity and bring you a healthy and comfortable life. TO ACCESS CUSTOMER SUPPORT FASTER If there is any problem of the product, please contact Sleavon Customer Service support@sleavon.com with your Purchase Order ID to help you address the...
- Page 4 BEFORE FIRST USE: To prevent any internal damage, it is very important to keep refrigeration units (like this one) upright throughout their journey. Please leave it standing upright and outside the box for 24 HOURS before plugging it in.
-
Page 5: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS .............01 FEATURES & SPECIFICATIONS ........02 PRODUCT DRAWINGS ............03 MACHINE SETUP & OPERATION ........04 WATER DRAINAGE ..............06 MAINTENANCE & STORAGE..........09 TROUBLE SHOOTING............10 SPECIAL NOTES ..............11 WARRANTY & CONTACT US ..........12... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT NOTICE FOR FIRST USE: For your safety, please read the manual carefully and keep the manual for future reference. Please use this product according to the instructions of installation and operation of this manual. Don't try to repair, dismantle or modify this appliance, or it may cause damage. Install the unit on flat and hard floor to diminish vibration or noise. -
Page 7: Features & Specifications
Three optional modes (AUTO, CNT, SLEEP) ● Compact and modern design ● Extremely quiet operation (36dB (A)) ● Auto defrosting ● SPECIFICATIONS Model No. D001F AC115V 60Hz Power Source Power Consumption / Current(80°F,60%RH) 175W/1.9A Power Consumption / Current(86°F,80%RH) 205W/2.1A 9 Pints/Day(4.2L/Day) Moisture Removal(65˚F,60%RH) 13 Pints/Day(6.1L/Day) Moisture Removal(80˚F,60%RH) -
Page 8: Product Drawings
PRODUCT DRAWINGS Front Control Panel Air Outlet Display Screen Back Air Inlet Continuous Drainage Outlet Universal Castor Water Tank... -
Page 9: Machine Setup & Operation
MACHINE SETUP & OPERATION DIGITIAL DISPLAY Blue Green humidity<46% 44%≤humidity≤66% humidity>64% OPERATRIONS Button Function Power In the standby status, press the "POWER" button to turn on the machine, the operation indicator lights up, the default fan speed is high and the default humidity is 50%. - Page 10 MACHINE SETUP & OPERATION Auto Mode: Machine will operate under the default humidity of 50% RH. Both fan speed and humidity value can be adjusted under Auto Mode. Continuous Drying Mode: The machine will continue to run, but the humidity value can not be adjusted.
-
Page 11: Water Drainage
WATER DRAINAGE Water Tank Full Alarm Water Tank Indicator When the tank is full for 5 seconds, it will activate the alarm, the water tank indicator “ ” will turn red and the unit will buzz for 15 times. Clear the alarm When the alarm buzz is on, press any button to stop it. - Page 12 WATER DRAINAGE PRECAUTIONS Ensure the water tank is in right Do not remove the float out of the position when putting it back, tank otherwise the dehumidifier otherwise the dehumidifier can can not start up. not start up. If the tank is dirty, wash it with cool/warm water. Do not use detergent, steel balls, chemically treated dustproof cloth, gasoline, benzene, thinners or other chemical solvents in case damage and leakage.
- Page 13 WATER DRAINAGE CONTINUOUS DRAINAGE Take out the water tank Water Tank Use a water hose (diameter=9.5mm) to connect the water outlet. Dress the water hose through the cutting hole of the tank and put the tank back in place. When continuous drainage, the end of the hose should not be submerged in the water in case being blocked or damaged.
-
Page 14: Maintenance & Storage
MAINTENANCE & STORAGE MAINTENANCE Body Cleaning Use a soft and slightly wet cloth to clean the dehumidifier body. Filter Cleaning 1. Take off the filter mesh. 2. Use a vacuum cleaner to gently absorb the dust on the surface. If the filter is very dirty, wash it with water and a soft cloth and dry it thoroughly afterwards. -
Page 15: Trouble Shooting
TROUBLE SHOOTING FUNCTIONING TEMP. 41℉ ≤ Ambient Temp. ≤100 ℉ When the ambient temp. is lower or higher than the functioning temp., the dehumidifier will stop operating. When the machine is working between the ambient temperature of 41℉ and 61℉，the compressor will automatically defrost at intervals.When defrosting, the compressor will stop and the fan will keep running. -
Page 16: Special Notes
SPECIAL NOTES Do not insert thin rods and hard objects into the machine body to avoid malfunction and danger. Please clean the filter every two When cleaning the dehumidifier, weeks (do not use hot water please use the wet textile to above 104°F, alcohol, gasoline wipe gently, do not shoot the or toluene.) -
Page 17: Warranty & Contact Us
There are our general terms for the warranty service, but we always encourage our customers to contact us if any issues, regardless of warranty terms. If you are experiencing an issue with Sleavon product, you can reach out to us at support@sleavon.com, we will dedicate our efforts to resolve it for you. - Page 20 Sleavon Sleavon For FAQs and more information please visit: Sleavon www.sleavon.com Sleavon (Scan the QR Code for Live Chat) We are expecting to see our products fulfill your life and hear your voice. Your satisfaction means a lot to us.
