- Page 1 ATP2B15 User Manual [Ver. 1.0] Just Touch autobaseTouch Intelligent Touch Panel Computer http://www.autobase.biz...
- Page 2 User Manual Ver.1.0...
- Page 3 This user manual, and all about copyright of Autobase ATP series panel computer © Autobase, Inc. All rights reserved < Notice > Information in this document is subject to change without prior notice. Printed, December 20, 2012...
-
Page 4: Table Of Contents
1. ATP2B15 CONFIGURATION ··············································· 5 1.1 ATP2B15 Hardware Specifications ····································· 5 1.2 Part Names and Description ·············································· 6 1.3 ATP2B15 Dimensions and Panel Cut-out ····························· 7 2. SERIAL COMMUNICATION PORT ······································· 8 2.1 Serial communication port ················································· 8 2.1.1 RS-232C Port ··································································· 8 3. - Page 5 4.1.2 Audio driver setup ···························································· 16 4.1.3 Graphic driver setup ························································· 19 4.1.4 Touch screen driver setup ················································· 21 4.1.5 Ethernet driver setup ························································ 24 4.3 Programs for Autobase Touch Pro Pack ····························· 26 4.2.1 Autobase SCADA Program installation ······························· 26 CUSTOMER SERVICE ························································ 27...
-
Page 6: Atp2B15 Configuration
Dual Gigabit Ethernet (10/100/1000Mbits/s) LAN Ports Keyboard/ Mouse USB Type CD-ROM Windows XP Embedded POSReady 2009 Utility Rescue (Recovery Tools Included) Voltage DC 12V Power Weight 5.28 kg Service life of LCD Backlight 40,000h or more <Table 1-1> AUTOBASE Touch hardware specifications... -
Page 7: Part Names And Description
1.2 Part Names and Description <Figure 1-1> Input/output ports of ATP series ❶ Power ON/OFF : Power On/OFF switch ❷ Audio IN/OUT : Microphone input/output ports ❸ USB : USB 4 ports ❹ LAN 1 : 10/100/1000 Base-T Ethernet port ❺... -
Page 8: Atp2B15 Dimensions And Panel Cut-Out
1.3 ATP2B15 Dimensions and Panel Cut-out <Figure 1-2> ATP2B15 dimensions(unit : mm) <Figure 1-3> ATP2B15 Panel cut-out dimensions(unit : mm) -
Page 9: Serial Communication Port
2. Serial Communication port 2.1 Serial communication port ATP2B15 has 3 serial ports for communication. Serial ports COM1/COM2/COM3 are RS-232C dedicated port so they can be used as RS-232C only. 핀 Female) Connector Type 2.1.1 RS-232C Port COM1/COM2/COM3 serial ports support the RS-232C only. -
Page 10: Automated System Recovery
Autobase Touch Panel. 3.1 System recovery External keyboard is required when you have to reset Autobase Touch Panel as factory state or repair to the recent recovery point, for reasons such as the damage of operating system or loss of important data. -
Page 11: Restore Point Update
When you complete the commissioning and project in the field, you can update the optimal restore point for preparing of problem occurrence to the system. After booting up Autobase Touch Panel system normally, double click the icon at the bottom right corner of the screen then the logon dialog box will be appeared as shown in <Figure 3-3>... - Page 12 <Figure 3-4> Restore settings dialog box And then if you select button, the restore point will be updated. If the restore point is updated successfully, Restore point update complete dialog box will be displayed as <Figure 3-5>. <Figure 3-5> Restore point update complete dialog box Generally, it is recommended to choose the disable restore option in the bottom of the dialog box.
-
Page 13: Manual System Recovery
4. Manual System Recovery 4.1 Device driver setup Install the device driver of Autobase Touch Panel after the Windows OS setup. You can install device drivers from Touch System Software DVD or the Internet downloading. Touch System Software DVD is included in the product package. - Page 14 You can find ‘infinst911autol.exe’ file as shown in <Figure 4-1> when you select ‘Driver\ATP2B15\Chipset’ folder from Touch System Software DVD. And run ‘infinst911autol.exe’, <Figure 4-2> initial screen will be displayed. Then select from <figure 4-2>, <Figure 4-3> license agreement dialog box will be displayed.
- Page 15 <Figure 4-3> License Agreement dialog box of mainboard chipset driver setup If you select from <Figure 4-3>, the driver installation process will be continued. During the driver installation, if it needed an OS file, <Figure 4-4> screen will be appeared and then select the needed file in ‘\Driver\WindowsXP_POSReady2009_SystemFiles’...
- Page 16 <Figure 4-5> Mainboard chipset driver installation complete screen...
-
Page 17: Audio Driver Setup
4.1.2 Audio driver setup <Figure 4-6> Audio driver folder You can find the setup file in‘Driver\ATP2B15\Audio’ folder of Touch system Software DVD. And if you run ‘WDM_R270.exe’ from <Figure 4-6>, the initial screen will be displayed as shown in <Figure 4-7>. Then, if you select in <Figure 4-7>... - Page 18 <Figure 4-7> Audio driver setup initial screen <Figure 4-8> Related system file location setting dialog box After the related system file location setting if you select button, the audio driver installation will be completed and Windows restart setting dialog box will be displayed as shown in <Figure 4-9>.
- Page 19 <Figure 4-9> Windows restart setting dialog box...
-
Page 20: Graphic Driver Setup
4.1.3 Graphic driver setup <Figure 4-10> Graphic driver folder If you select the provided Touch System software DVD ‘Driver\ATP2B15\Graphic’ folder, the files will be displayed as <Figure 4-10>. And run ‘Setup.exe’ in <Figure 4-10>, the graphic driver setup initial screen will be appeared as <Figure 4-11>. - Page 21 When the graphic driver setup completed <Figure 4-12> dialog box will be displayed and you can set whether to restart the computer or not. After installing the graphic driver, adjust the proper screen resolution (ATP2B15 : 1024 * 768). <Figure 4-12> Graphic driver setup complete dialog box...
-
Page 22: Touch Screen Driver Setup
4.1.4 Touch screen driver setup <Figure 4-13> Touch screen driver folder If you select ‘Driver\ATP2B15\TouchScreen’ folder from Touch System Software DVD, you can find ‘TouchKit_2KXP_5.6.0.6806.exe’ as shown in <Figure 4-13>. And if you run ‘TouchKit_2KXP_5.6.0.6806.exe’, you can see the initial screen for setting as shown in <Figure 4-14>. - Page 23 <Figure 4-14> Touch screen driver setup initial screen <Figure 4-15> Touch screen driver setup complete dialog box...
- Page 24 <Figure 4-16> Touch screen calibration <Figure 4-17> Tools tab of Configure utility...
-
Page 25: Ethernet Driver Setup
4.1.5 Ethernet driver setup <Figure 4-18> Ethernet driver folder When you open ‘Driver\ATP2B15\Ethernet’ folder of ‘Touch System Software DVD’, you can find files as shown in <Figure 4-18>. And if you run ‘Setup.exe’ file from ‘Driver\ATP2B15\Ethernet’ folder, installShield wizard will be started as shown in <Figure... - Page 26 <Figure 4-19> InstallShield Wizard for graphic driver setup Then select , installShield Wizard will start graphic driver setup. After the graphic driver installation is completed, <Figure 4-20> will be appeared. <Figure 4-20> InstallShield Wizard Complete dialog box...
-
Page 27: Programs For Autobase Touch Pro Pack
4.2.1 Autobase SCADA Program installation Autobase Touch Pro Pack required Microsoft DotNet Framework, Autobase SCADA Program and Autobase SCADA license by default. For more details about the installable Autobase SCADA version and how to install the license, contact Autobase technical support team. -
Page 28: Customer Service
Even during the warranty period, we will provide repair services with reasonable charges for problems due to customer’s negligence and natural disasters. Paid service Autobase, Inc. does not warrant in the following cases. ❶ Malfunction by foreign substances(water, soda, coffee, toys, etc.) spills into the product. - Page 29 Safety Information ❶ For any reason, damage caused by disassembling the equipment will not be covered under the warranty. ❷ Do not open the cabinet to avoid electric shock. Please request service to qualified technicians. ❸ Sound or images might be distorted because to place this product near devices, emit electromagnetic waves.
- Page 30 1201, Biz Center, SKnTechno Park, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Phone : +82.31.776.0800 / Fax : +82.31.776.0802 http://www.autobase.biz...
