  • Page 1 ATP15/15P/17/19 User Manual Just Touch autobaseTouch Intelligent Touch Panel Computer http://www.autobase.biz...
  • Page 2 ATP15 / ATP17 / ATP19...
  • Page 3 This user manual and all about copyright of Autobase ATP series panel computer © Autobase, Inc. All rights reserved < Notice > Information in this document is subject to change without prior notice. Printed, November 26, 2012...

  • Page 4: Table Of Contents

    1. ATP Configurations ·························································· 5 1.1 ATP Hardware Specifications ············································ 5 1.2 Part Names and Description ·············································· 6 1.3 ATP15 Dimensions and Panel Cut-out ································· 7 1.4 ATP15P Dimensions and Panel Cut-out ······························· 8 1.5 ATP17 Dimensions and Panel Cut-out ································· 9 1.6 ATP19 Dimensions and Panel Cut-out ································...
  • Page 5 4.1.2 Audio driver setup··················································· 23 4.1.3 Graphic driver setup ················································ 26 4.1.4 Touch screen driver setup ········································ 29 4.1.5 Ethernet driver setup ··············································· 32 4.2 Programs for Autobase Touch Pro Pack ····························· 34 4.2.1 AutoBase Touch SCADA Program installation ·············· 34...

  • Page 6: Atp Configurations

    CD-ROM Windows XP Embedded Standard Utility Rescue (Recovery Tools Included) Voltage AC 115 ~230V Power Weight 5.85 kg 5.91 kg 7.69 kg 8.91 kg Waterproof Front Service life of LCD 40,000h or more backlight <Table 1-1> AUTOBASE Touch hardware specifications...

  • Page 7: Part Names And Description

    1.2 Part Names and Description <Figure 1-1> Input/output ports of ATP series ❶ AC IN : Power input connector ❷ Power ON/OFF : Power On/OFF switch ❸ Audio OUT : Stereo speaker output port ❹ MIC IN : Microphone input port ❺...

  • Page 8: Atp15 Dimensions And Panel Cut-Out

    1.3 ATP15 Dimensions and Panel Cut-out <Figure 1-2> ATP15 dimensions(unit : mm) <Figure 1-3> ATP15 panel cut-out dimensions(unit : mm)

  • Page 9: Atp15P Dimensions And Panel Cut-Out

    1.4 ATP15P Dimensions and Panel Cut-out <Figure 1-4> ATP15P dimensions(unit:mm) <Figure 1-5> ATP15P panel cut-out dimensions(unit : mm)

  • Page 10: Atp17 Dimensions And Panel Cut-Out

    1.5 ATP17 Dimensions and Panel Cut-out <Figure 1-6> ATP17 dimensions(unit : mm) <Figure 1-7> ATP17 panel cut-out dimensions(unit : mm)

  • Page 11: Atp19 Dimensions And Panel Cut-Out

    1.6 ATP19 Dimensions and Panel Cut-out <Figure1-8> ATP19 dimensions(unit : mm) <Figure 1-9> ATP19 panel cut-out dimensions(unit : mm)
  • Page 12 < Empty Page >...

  • Page 13: Serial Communication Port

    2. Serial Communication Port 2.1 Serial Communication port ATP15, ATP17, ATP19 have 4 serial ports for communications. And COM1/COM3/COM4 Serial ports, except COM2, are RS-232C dedicated port and they are able to be used only as RS-232C. RS232C/RS422 setting for COM2 is possible to use the board jumper switch.

  • Page 14: Rs-232C/Rs-422 Mode Settings

    2.2 RS-232C/RS-422 Mode Settings In the case of ATP series, COM2 serial port only can be changed RS-232/RS422 mode settings. 2.2.1 RS-232C Mode ATP series is factory set to RS-232C by default. <Figure 2-1> A board of ATP Series...

  • Page 15: Rs-422 Mode

    <Figure 2-2> RS-232C mode change DIp switch of ATP series board Using JP1 Dip switch in <Figure 2-2>, it is possible to change RS-232C/RS-422. And <Figure 2-3> is JP1 Dip switch setting to use COM2 serial port as RS-232C mode. <Figure 2-3>...
  • Page 16 Connector type – D-SUB 9 pin Female Definition RS-232C RS-422 <Table 2-2> Connector and Pin Definition of COM2 serial port...

  • Page 17: Automated System Recovery

    Autobase Touch Panel. 3.1 System Recovery External keyboard is required when you have to reset Autobase Touch Panel as factory state or repair to the recent recovery point, for reasons such as the damage of operating system or loss of important data.

  • Page 18: Restore Point Update

    When you complete the commissioning and project in the field, you can update the optimal restore point for preparing of problem occurrence to the system. After booting up Autobase Touch Panel system normally, double click the icon at the bottom right corner of the screen then the logon dialog box will be appeared as shown in <Figure 3-3>...
  • Page 19 After log on if you select ‘Restore settings’ on the left side of dialog box, <Figure 3-4> dialog box will be appeared. <Figure 3-4> Restore settings dialog box And then if you select button, the restore point will be updated. If the restore point is updated successfully, restore point update complete dialog box will be displayed as <Figure 3-5>.

  • Page 20: Manual System Recovery

    4. Manual System Recovery 4.1 Device Driver Setup Install the device driver of Autobase Touch Panel after the Windows Embedded Standard OS setup. You can install device drivers from Touch System Software DVD or the Internet downloading. Touch System Software DVD is included in the product package.
  • Page 21 ‘infinst911autol.exe’, <Figure 4-2> initial screen will be displayed. Then select from <figure 4-2>, <Figure 4-3> license agreement dialog box will be displayed. <Figure 4-2> Initial screen of the mainboard chipset driver setup...
  • Page 22 <Figure 4-3> License Agreement dialog box of mainboard chipset driver setup If you select in <Figure 4-3>, the driver installation process will be continued. During the driver installation, if it needed an OS file, <Figure 4-4> screen will be appeared and then select the needed file in ‘\Driver\WindowsXP_POSReady2009_SystemFiles’...
  • Page 23 When the installation is complete, reboot system information screen will be appeared as shown in <Figure 4-5> and proceed to reboot. <Figure 4-5> Mainboard chipset driver installation complete screen...

  • Page 24: Audio Driver Setup

    4.1.2 Audio driver setup <Figure 4-6> Audio driver folder You can find the setup file in ‘Driver\ATP15\Audio’ folder of Touch system Software DVD. And if you run ‘Setup.exe’ from <Figure 4-6>, the initial screen will be displayed as shown in <Figure 4-7>. Then, if you select in <Figure 4-7>...
  • Page 25 <Figure 4-7> Audio driver setup initial screen <Figure 4-8> Related system file location setting dialog box...
  • Page 26 After the related system file location setting if you select button, the audio driver installation will be completed and Windows restart settings dialog box will be displayed as shown in <Figure 4-9> <Figure 4-9> Windows restart settings dialog box...

  • Page 27: Graphic Driver Setup

    4.1.3 Graphic driver setup <Figure 4-10> Graphic driver folder If you select the provided Touch System software DVD ‘Driver\ATP15\VGA’ folder, the files will be displayed as <Figure 4-10>. And run ‘Setup.exe’ in <Figure 4-10>, the graphic driver setup initial screen will be appeared as <Figure 4-11>...
  • Page 28 <Figure 4-11>, the graphic driver setup will be started. When the graphic driver setup completed <Figure 4-12> dialog box will be displayed and you can set whether to restart the computer or not. After installing the graphic driver, adjust the proper screen resolution (ATP15:1024 * 768, ATP17/19:1280*1024).
  • Page 29 <Figure 4-12> Graphic driver setup complete dialog box...

  • Page 30: Touch Screen Driver Setup

    4.1.4 Touch screen driver setup <Figure 4-13> Touch screen driver folder If you select ‘Driver\ATP15\TouchScreen’ folder from Touch System Software DVD, you can find ‘TouchKit_2KXP_5.0.1.5310.exe’ as shown in <Figure 4-13>. And if you run ‘TouchKit_2KXP_5.0.1.5310.exe’, you can see the initial screen for setting as shown in <Figure 4-14>.
  • Page 31 <Figure 4-14> Touch screen driver setup initial screen <Figure 4-15> Touch screen driver setup complete dialog box...
  • Page 32 <Figure 4-16> Touch screen calibration <Figure 4-17> Tools tab of configure utility...

  • Page 33: Ethernet Driver Setup

    4.1.5 Ethernet driver setup <Figure 4-18> Ethernet driver folder When you open ‘Driver\ATP15\Ethernet’ folder of ‘Touch System Software DVD’, you can find files as shown in <Figure 4-18>. And if you run ‘Setup.exe’ file, installShield wizard will be started as shown in <Figure 4-19>.
  • Page 34 <Figure 4-19> InstallShield Wizard <Figure 4-20> Screen to run the Ethernet driver installation Select in <Figure 4-20>, the Ethernet driver setup will be started.

  • Page 35: Programs For Autobase Touch Pro Pack

    4.2.1 AutoBase Touch SCADA Program installation Autobase Touch Pro Pack required Microsoft DotNet Framework, Autobase SCADA Program and Autobase SCADA license by default. For more details about the installable Autobase SCADA version and how to install the license, contact Autobase technical support team.
  • Page 36 Even during the warranty period, we will provide repair services with reasonable charges for problems due to customer’s negligence and natural disasters. Paid service Autobase, Inc. does not warrant in the following cases. ❶  Malfunction by foreign substances(water, soda, coffee, toys, etc.) spills into the product.
  • Page 37 Safety Information ❶ For any reason, damage caused by disassembling the equipment will not be covered under the warranty. ❷ Do not open the cabinet to avoid electric shock. Please request service to qualified technicians. ❸ Sound or images might be distorted because to place this product near devices, emit electromagnetic waves.
  • Page 38 1201, Biz Center, SKnTechno Park, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Phone : +82.31.776.0800 / Fax : +82.31.776.0802 http://www.autobase.biz...
