W e strive to ensure that our produc t s are of the highest quality
and free of manufacturing defec t s or missing p ar t s. Howeve r , if
you have any problems with your new product,
gameroom@escaladesports.com
Mailing Address: (Correspondence Only)
Escalade Sports
PO Box 889
Evansville, Indiana 47706-0889
Please have your model number when inquiring about parts.
When con t ac ting Escalade S por t s please provide your model numbe r , date code (i f
appli cable ), and pa rt nu mbe r i f reque sting a repla c e men t pa rt. The s e nu mbe rs a re
lo c a ted on the p rodu ct, pa ckaging , and in thi s owne rs manual .
Y our Model Number :
2-AL7100F-
Date Code:
Purchase Date:
PLEASE RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
All Rights Reserved
© 2019 Escalade S por t s
DO NOT RETURN IT T O THE S T OR E
please contact us toll free @:
1-88 8 - 9 9 6 - 2 7 2 9
F AX: 1-866-873-3535
AL7100F
-JL
1
,
Physical Location:
Escalade Sports
817 Maxwell Ave.
Evansville, Indiana 47711
For Customer Service Call 1-888-996-2729
Advertisement
Table of Contents
Related Manuals for Triumph AL7100F
Summary of Contents for Triumph AL7100F
- Page 1 ), and pa rt nu mbe r i f reque sting a repla c e men t pa rt. The s e nu mbe rs a re lo c a ted on the p rodu ct, pa ckaging , and in thi s owne rs manual . AL7100F Y our Model Number :...
- Page 2 IMPORTANT! READ EACH STEP IN THIS MANUAL BEFORE YOU BEGIN THE ASSEMBLY. TWO (2) ADU L TS ARE REQUIRED T O ASSEMBLE THIS AMERICAN LEGEND ARCADE BASKETBALL Tools Needed: T1 Allen Wrench (provided) Phillips Screwdriver Plyers Make sure you understand the following tips before you begin to assemble your basketball shootout.
-
Page 3: Hardware Identifier
HARDWARE IDENTIFIER (To Scale) H1 - M6 x 35mm H2 - M6 x 90mm Allen Head Bolt Allen Head Bolt (1 pc) (2 pcs) H3 - M6 x 25mm H4 - M6 x 15mm H6 - Plastic H5 - M6 Allen Head Bolt Flat Washer Wing Nut... - Page 4 PARTS IDENTIFIER (Not to Scale) P1 - Left Lower P2 - Right Lower P3 - Left Middle P4 - Right Middle Tube Assembly Tube Assembly Tube Assembly Tube Assembly (1 pc) (1 pc) (1 pc) (1 pc) P5 - Front P6 - Upper Tube Assembly Tube (2 pcs)
- Page 5 PARTS IDENTIFIER (Not to Scale) P11 - Mechanical P12 - Rim (2 pcs) P9 - Electronic P10 - Electronic Scoring Arm Note: This is a special rim Scorer (1 pc) Scorer Face Plate designed to avoid entanglement (2 pcs) (1 pc) 3 pcs AA Batteries Required , with the mechanical scoring arm.
- Page 6 Remove all the parts from the box and verify that you have all of the listed parts as shown on the Parts List. NOTE: STEP 1, 2 AND 3 requires a second adult to help “hold” the assemblies as being assembled NOTE: When unfolding assemblies, be careful not to bend any parts.
- Page 7 PARTS REQUIRED: 1 pc - H1 M6 x 35 mm Allen Head Bolt 1 pc - H4 Flat Washer NOTE: Lastly, these six points can now 1 pc - H5 Wing Nut be tightened using a phillips screwdriver or Phillips Allen Wrench (T1) provided STEP 3 and plyers.
- Page 8 PARTS REQUIRED: 2 pcs - H2 M6 x 90 mm 2 pcs - H6 Plastic Bushing Allen Head Bolt 2 pcs - H4 Flat Washer 1 pc - P5 Front Tube Assembly 2 pcs - H5 Wing Nut 2 pcs - P15 Locking Pin STEP 4 Connect P5 Front Tube Assembly using Spring Lock as shown in FIGURE 4.
- Page 9 PARTS REQUIRED: H3 M6 x 25 mm Allen Head Bolt 1 pc - P7 Backboard 16 pcs - H5 Wing Nut 2 pcs - P11 Mechanical Scoring Arm 16 pcs - 16 pcs - H7 Lock Washer 2 pcs - P12 Rim 1 pc - T1 Allen Wrench 2 pcs - P14 Rim Support Plate...
- Page 10 PARTS REQUIRED: 2 pcs - P6 Upper Tube STEP 8 Attach Backboard assembly from STEP 7 to Frame assembly from STEP 5 as shown in FIGURE 8. Attach P6 Upper Tubes to P7 Backboard assembly using Spring Lock as shown in FIGURE 8. Spring Lock Spring Lock NOTE :...
- Page 11 PARTS REQUIRED: 1 pc - P8 Ramp Chute STEP 9 Slide elastic loops and the sleeve of P8 Ramp Chute onto P6 Upper Tubes as shown in FIGURE 9 and DETAIL C. At the front of P8 Ramp Chute, bring the ramp down and secure using Hook and Loop Straps as shown in FIGURE 9. Secure all Hook and Loop Straps on the shootout as shown in FIGURE 9.
- Page 12 PARTS REQUIRED: 1 pc - H8 Wing Bolt 1 pc - P17 Control Box 1 pc - P16 Scoring Control Box Wire A/C Adapter 1 pc - A3 STEP 10 Connect P11 Mechanical Scoring Arm sensor wires to P9 Electronic Scorer as shown in FIGURE 10. Secure Elastic Loops from P8 Ramp Chute to the back of P7 Backboard attached Wing Nuts as shown in FIGURE 10.
-
Page 13: Product Parts List
Congratulations! You have now assembled your Double Shootout. Please note the Care and Use instructions below. CARE AND USE OF YOUR SHOOTOUT 1. Product can be used in the dry OUTDOORS - but must be stored INDOORS. 2. DO NOT sit, climb or lean on the unit. DO NOT drag the unit when moving it, This will damage the legs. -
Page 14: Troubleshooting
Trouble Shooting: Game won't turn on 1.Make sure switch on scorer is in the on position (located on back of backboard). 2.Make sure switch mechanical scoring arm wires are in the home and visitor slots on the scorer. 3.Make sure the control box wire is in the control slot on the scorer. 4.Press/hold down the on/off bottom on the scorer for 2 seconds to turn game on. -
Page 15: Game Options
Game Options 1. Beat the time Clock Press "PLAY" to enter game 1. Press "UP or Down" to select single/multiple players (P1/P2/P3/P4). Press "PLAY" after the number of player is selected. Press "UP/Down" to select playing time, 30/45/60 seconds. Press "PLAY" to begin the game. Scoreboard "HOME"... -
Page 16: Check Point
5. Check Point Press "PLAY" to enter game 5. Press "UP or Down" to select single/multiple players (P1/P2/P3/P4). Press "PLAY" to begin the game. "HOME" displays "player", "VISITOR" displays "24" points, pre-set 40 seconds playing time. Points scored will display on scoreboard "HOME" Before time is out, once 24/52/68/86 points is scored, playing time increases 10/20/10/20 seconds respectively. - Page 17 First Time Battery Installation: Locate battery compartment for this product . Use alkaline batteries for maximum performance . Using a small Phillips head screwdriver – loosen and remove the battery compartment cover screw(s). Remove battery compartment cover . Install new batteries only after reading the “ Battery Information NOTICE“ ! Replace compartment cover and secure cover with the cover screw .
-
Page 18: 90-Day Limited Warranty
90 DAY LIMITED WARRANTY This consumer warranty extends to the original consumer purchase of any ESCALADESPORTS Product (hereinafter referred as the "Product"). WARRANTY DURATION: This Product is warranted to the original consumer purchase of a pe- riod of 90 days from the original purchase. WARRANTY COVERAGE: ESCALADE SPORTS warrants to the original Consumer Purchaser that any Product of its manufacture is free from defects in material and workmanship when used for the intended purpose under normal use and conditions.
