- Page 1 Gallagher SMB Demonstration Suitcase User Guide Gallagher SMB Demonstration Suitcase NZ/AU: C500900 Edition 1 | December 2021...
- Page 2 Introduction Thank you for choosing Gallagher SMB. The Gallagher SMB Demonstration Suitcase has been specifically designed as a sales and training tool to enable you to demonstrate the Gallagher SMB solution. Contents Check the suitcase contains the following items: •...
- Page 3 Configuration The suitcase has the following factory configuration: Door simulation • Door Open: Switch position Door closed Switch position Door open • Forced Door: Switch position Door lock is closed Switch position I Door lock is open • Request to Exit: Switch position Door REX is closed (request to exit) Switch position...
- Page 4 Site Use the image below to provide context when configuring and demonstrating the solution. T15 Access Reader Office 360 OFFICE AREA STORE ROOM AREA Roller Door Reed Switch User You will be required to use your mobile phone to demonstrate the Customer App. You can invite users to your fictional site, and allocate roles, so they can experience the product.
- Page 5 Power on Connect an IEC power cord (not supplied) from the 3.5 A Power Supply to an AC power outlet. Switch ON. The controller and router will receive power. You will need to perform a one-activation of the router. Once activated, ensure your location has an adequate cellular signal.
- Page 6 3. Enter a name for the site. For example 'Sample Site - Demo'. Append the word 'Demo' to the site name. Note: Demo sites will not be charged subscription fees. Gallagher will audit the number of demo sites per partner.
-
Page 7: Controller Assignment
Controller assignment 1. Select Scan controller QR code. 2. Capture an image of the controller's QR Code using your phone and present the image to the laptop. The 'Physical ID' pop-up displays. Select OK to confirm the controller's ID. The controller will download the latest firmware and update its default configuration. 3. -
Page 8: Area Configuration
Area configuration 1. Select the AREAS tab, then select Area 1. The 'Area 1' lightbox displays. 2. Rename to "Office". 3. Select Assign Outputs and select Siren as an Alarm Output. The siren will activate when an alarm is triggered. 4. -
Page 9: Door Configuration
Door configuration 1. Select the HARDWARE tab. 2. Select Add New. Select Door. The 'New Door' lightbox displays. 3. Rename to "Office Door". 4. From the Open Sensor drop-down, select the "Door Open Sensor" input. 5. From the Lock Sensor drop-down, select the "Door Lock Sensor" input. 6. - Page 10 Publish changes Select Publish to publish your configuration to the controller. Commission site 1. Select Commission site. You will then be requested to complete the system tests, marking each item test result as "Passed" before you can activate your site. Note: This step in the installation process is where the technician will need to walk-test the site to check wiring and configuration is all correct.
- Page 11 Demo script Use the following script as a guide when demonstrating the Customer App. Two-factor logon The Customer App supports two-factor logon for Site Managers and Site Admins. This feature is provided by FIDO. These users must authenticate themselves before using the app. Alarm Arm and disarm the site.
-
Page 12: Additional Resources
Disclaimer: Please note that information contained in this document is intended for general information only. While every effort has been taken to ensure accuracy at the date of the document, there may be errors or inaccuracies and specific details may be subject to change without notice. Copyright © Gallagher Group Ltd.
