Summary of Contents for INSE E3
-
Page 2: Table Of Contents
All the pictures in the manual are for the reference only, please refer to the actual object in the box. Table of Contents Safety Notes Product Components Host and accessories Host scheme Host button Remote control Product Operation Charging Start/stop Sweeping mode Product maintenance Cleaning of side brushes... -
Page 3: Safety Notes
Safety Notes Please read the following safety notes carefully and abide by all routine preventive measures for safety. Please read this manual carefully. Please keep this manual well. This product may be damaged due to any operation inconformity to this manual. Expressions Symbols &... - Page 4 Safety Notes It is forbidden to damage and process the Do not touch. power cable. Do not put a weight on the power When the product is operating and sweeping, cable or heat, drag or bend the power cable please pay attention to the safety of babies, forcefully.
- Page 5 Safety Notes Notes on using rechargeable batteries Danger Do not use other battery adapters. Neither short-circuit nor damage the battery Otherwise, leakage, heating or cracking rudely. may be caused. Otherwise, leakage, heating or cracking may be caused. Prohibition Prohibition Do not deliver or save it together with metal Do not throw the battery into fire or heat it up.
-
Page 6: Product Components
Product Components Host and accessories Quantity Name 1 pcs. Host 1 pcs. Battery adapter 1 pcs. Remote control 2 (one on the left and Side brush right respectively） 1 pcs. User manual 1 pcs. Dustbin Respond Start Pause FOCUS RANDOM AUTO... -
Page 7: Host Button
Product Components Illustration of Host Signal receiving head Bumper Button Swivelling cover Sensor Universal wheel Left brush Right brush Sensor Sensor Battery cover Air suction channel Right side Left side wheel wheel Blade Bottom case Dustbin Preliminary Swivelling strainer cover Dustbin Efficient strainer Efficient strainer... -
Page 8: Remote Control
Product Components Remote control 1.“Start/pause” button Under the “standby mode” or “operating mode”, the machine enters the random sweeping mode. Under the “standby mode” or “operating mode”, the machine moves forward by pressing this button. Down Under the “standby mode” or “operating mode”, the machine moves backward by pressing this button. - Page 9 Product Components 3.“Focus” button Under the “operating mode” or “standby mode”, the machine will enter the focus mode after you Respond press this button. Start Pause 4.“Random” button Under the “operating mode” or “standby mode”, FOCUS RANDOM the machine will enter the random mode after you press this button.
-
Page 10: Product Operation
Product Operation 1. Charging After switching off the power switch of the machine, connect the power adapter to power supply and insert the other end into the charging interface of the machine. See the diagram below. In case of low power, the red light of the button “start/suspend” will flicker. In the charging process, the green light of the button “start/suspend”... -
Page 11: Sweeping Mode
Product Operation 3. Sweeping mode A. Auto sweeping Under the “operating mode”, the machine will enter the auto mode after you press this button. B. Focus sweeping Under the “operating mode” or “standby mode”, the machine will enter the focus mode after you press this button. C. -
Page 12: Product Maintenance
Product maintenance Cleaning of side brushes If side brushes are dirty, please wash them with clean water and then use them after they get dry naturally. If they are damaged and cannot work normally, please change them. ! Note: When changing side brushes, please correspond the sign “L” and “R” on the side brushes to the position “L”... -
Page 13: Cleaning Of Sensor Lens
Product maintenance 3.Cleaning of sensor lens Use a cleaning tool or a piece of soft cloth to wipe the sensor slightly. See positions indicated in the diagram below: Sensor Sensor... -
Page 14: Common Faults
Common faults Alarm code table When common faults happen to the machine, refer to the table below for solutions. Common faults and solution Fault Solution The red light Earth inspection Put the host on the floor flickers and the fault. again. -
Page 15: Battery Replacement
Battery replacement Battery replacement Battery cover Screws of the battery cover Figure 2. Figure 3. The power switch Figure 1. Figure 4. Figure 5. Turn off the power switch at the bottom of the product. (figure 1) Use a screwdriver to remove screws of the battery cover at the bottom of the machine. -
Page 16: Product Parameters
Product parameters Classification Item Parameter Diameter 290mm Structural class Net weight 2.0kg Voltage 11.1V Electronic class Battery capacity Li-ion battery 1500mAh Charging mode Manual charging Focus sweeping, Sweeping Sweeping mode Random sweeping, Auto sweeping, parameters One-time charging time 180-300min One-time sweeping time 70-80min Host button type Mechanical button... - Page 17 Restricted use sign sheet of hazardous substances in products Name and content sheet of hazardous substances Hazardous substance Chromiu Polybro Polybrom minated inated Part name (Cr(VI)) biphenyl diphenyl Plumbu Hydrargy Cadmiu s (PBB) ethers m (Pb) rum (Hg) m (Cd) (PBDE) Metal 〇...
